GRAMMER Actimo Evolution

MSG95EL/722

Replaces: 1388494KOBA-11

Technical data:

• Seat contact switch: Optional
• • Air suspension with integrated compressor • Including low-frequency suspension and active weight adjustment (50 - 130 kg) • Continuous height adjustment 80 mm • Suspension travel 100 mm • 4-way adjustable damper for vertical suspension • Fore/aft isolator • Longitudinal adjustment 210 mm • Backrest and tilt adjustment • Seat switch • Seat cushion depth and tilt adjustment • Seat heater • Climate control system with active ventilation • Pneumatic lumbar support and side contour adjustment • Storage pocket • Seat cushion width 550 mm • Folding and height/tilt adjustable, fabric-covered armrests Joysticks not included
• Seat heater: Yes
• Length (mm): 706
• Armrest: Yes
• To fit as models: Komatsu
• Seat type: MSG95EL/722
• To fit: Komatsu
• Seat width (mm): 496
• Side horizontal suspension: Optional
• Fore/aft isolator: Yes
• Lordosenstütze: Pneumatic
• Joystick console: Optional
• Height (mm): 1089
• On-board voltage (V): 12
• Suspension: Air suspension
• Equipment: With control lever bracket
• Track gauge (mm): 260
• Restraint system: Optional
• Rückenverlängerung: Yes
• Upholstery type: Fabric / new design
