LINAK Actuator 12V P 100 mm 300 N

Replaces: 121P00-21001220

Technical data:

• Additional information: Installation length: 245 mm Cable length: 930 mm straight Cable end: open wire ends Piston head: slotted, O 10.2 mm, plastic Rear attachment: slotted, O 10.2 mm, plastic, 0° Feedback: Potentiometer Colour: black End position shutdown: integrated
• Areas of application: LA12
• Stroke: 100 mm
• Nominal voltage (V): 12
• Protection class: IP66
• Compressive force (N): 300
• Length (mm): 245
• Tensile force (N): 300
