LINAK Actuator 24V P 70 mm 750 N

Replaces: 121P00-10702420

Technical data:

• Protection class: IP66
• Stroke: 70 mm
• Compressive force (N): 750
• Nominal voltage (V): 24
• Additional information: Installation length: 245 mm Cable length: 930 mm straight Cable end: open wire ends Piston head: slotted, O 10.2 mm, plastic Rear attachment: slotted, O 10.2 mm, plastic, 0° Feedback: Potentiometer Colour: black End position shutdown: integrated
• Length (mm): 245
• Areas of application: LA12
• Tensile force (N): 750
