GRANIT Alternator 14 V / 35 A, flange 68,0 mm Kubota, Schäffer | F032111195, 111195, LS16303, 15253-64010, 15606-6401-0

€144,79
€131,80 Incl. 21% VAT
€108,93 Excl. VAT
In stock

Belt tension hole Ø / R (mm): M8 / 78,0 | Additional information: Connections B+ (M6), external regulator | Installation angle (°): 0 | Charging current (A): 35 | Direction of rotation: ↻ | Pulley spacing (mm): 27,5 | Flange size (mm): 68,0 | Form: A | Mo Read more.

Found in category:
Tractor & vehicle› Electrics› Alternators

Larger quantity required?



Any questions about this product?
Or do you need any help ordering? Feel free to get in touch with our support department at [email protected]. We're happy to help!

Product description

GRANIT Alternator 14V 35A

Replaces: F032111195, 111195, LS16303

Technical data:

  • Belt tension hole Ø / R (mm): M8 / 78,0
  • Additional information: Connections B+ (M6), external regulator
  • Installation angle (°): 0
  • Charging current (A): 35
  • Direction of rotation: ↻
  • Pulley spacing (mm): 27,5
  • Flange size (mm): 68,0
  • Form: A
  • Mounting L / d / R (mm): 68,0 / 8,5 / 78,0
  • Nominal values (V / A): 14 / 35
  • Pulley Ø (mm): 70.0
  • Belt width (mm) / type: 9,7
  • Nominal voltage (V): 14
  • Mounting hole Ø / R (mm): 8,5 / 78,0

Suitable for:

Kubota: KX101, KX151, B 4200, L 2250, L 2550, L 2550 DT, L 2850 DT, L 3250 DT, L 3750, L 4150, L 5450 DT, M 4030, M 4950, M 5030

Schäffer: 860

Further information

Article number
378C111195
EAN Code
4059139408801
SKU
378C111195
