CTEK Charger CS One EU

Replaces: 40-330

Technical data:

• Battery type: WET, MF, Ca/Ca, AGM, EFB, GEL, LiFePO4
• Frequency (Hz): 47 - 63
• Display: Kontrollleuchten
• Dimensions L x W x H (mm): 235 x 88 x 52
• Voltage (V): 12
• Input: 120 - 240 VAC, 47 - 63 Hz, 1.2 A
• Battery capacity (Ah): 3 - 180
• Charging voltage (V): 12
• Charging current (A): 8
• Protection class: IP65
• • Charging category: AC charging • Battery chemistry: lead-acid, lithium-ion • Battery types: 12 V, wet cell, MF, Ca/Ca, AGM, EFB, gel, LiFePO₄ • Back discharge current: less than 1.5 Ah/month • Cooling: natural convection • Starting voltage: 1.5 V lead batteries / 1.5 V LiFePO₄ • Ripple: less than 4% • Connectivity: BLUETOOTH® LE 5.1 • Temperature compensation: built-in adaptation of the charging voltage to the ambient temperature • Approval: ETSI EN 300 328, RED, EN 61000-6-3, EN 61000-6-1, ETSI EN 301 489-1, ETSI EN 301 489-17, EN 60 335-2-29, EN 60335-1, SS-EN ISO 13732-1:2008 • App support: CTEK app for Android and IOS • User interface: LED symbols, smartphone display (free choice) • Warranty: 5 years • Plug type: type F
• Description: The APTO™ technology automatically detects the battery type and then activates the appropriate charging programme, which displays the remaining charging time until the battery is ready for use. No buttons, no modes - simply connect the CS ONE to any 12 V battery and start charging. The polarity-free terminals save you having to think about where each terminal needs to be connected. No more incorrect connections. The terminals are also protected against sparks. If they do accidentally touch, nothing will happen. Additional functions can be activated via Bluetooth® using the CTEK app. Select RECOND to restore and recondition the battery. Select WAKE UP for lithium-ion batteries with undervoltage protection, or bring deeply discharged lead-acid batteries back to life. Select SUPPLY to turn the CS ONE into a convenient 12 V power source. The voltage and current supplied by the charger can also be monitored. • RECOND for restoring and reconditioning lead-acid batteries. • WAKE UP for reviving seemingly dead lead-acid and lithium-ion batteries. • 12 V SUPPLY for supporting the battery during maintenance and for providing continuous power when removing/replacing the battery. • ADVANCED SETTINGS for monitoring the voltage and current of the charger. • Can remain safely connected for long periods during trickle charging. • New and robust design for easy handling and unique mounting system on the back for quick connection of CS accessories.
• Mains voltage (V): 230
• Ambient temperature (°C): -30 - +50°C
• Reference no.: 40-330
• Area of application: mobil
