GRAMMER Compacto Comfort S
MSG93/511
Technical data:
- Seat heater: Optional
- Armrest: Optional
- Restraint system: Optional
- Seat type: MSG93/511
- Suspension: Air suspension
- Fore/aft isolator: Optional
- To fit: Fendt
- Lordosenstütze: Mechanical
- Height (mm): 692
- Rückenverlängerung: Optional
- Upholstery type: Fabric
- Track gauge (mm): 225
- Seat width (mm): 400
- • Comfort seat with air suspension and 12V compressor • Suspension travel 80 mm • Height adjustment 60 mm, continuous (air-assisted) • Weight adjustment, adjustment range 50 - 130 kg • Longitudinal adjustment 180 mm • Mechanical lumbar support • Backrest and tilt adjustment • Seat cushion width 400 mm • With fore/aft isolator
- Version: The Compacto Comfort S combines GRAMMER's typical suspension, seating and operating comfort in a very small space. The seat can be adjusted with one hand. The air suspension is equipped with combined weight and height adjustment. An easy-to-read display band guarantees that the remaining suspension travel is within the green range regardless of the driver's weight.
- Length (mm): 532
- On-board voltage (V): 12
- Seat contact switch: Yes
