Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02
Scharmüller 9,4688 reviews
(0)
-10%
Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02
-10%
Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02
Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02
Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02

Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm, 145 x 145 mm, working length 295 mm | 0.654.43.0-A02, 00.654.43.0-A02

€657,20
€589,53 Incl. 21% VAT
€487,21 Excl. VAT
In stock

Version: Pick-up hitch. D-value: 102,4 kN. Hole pattern: 145 x 145 mm. Towing eye Ø: 50 mm. Load capacity: 3000 kg. Colour: Black. Lock: Ring, rotatable. No. of holes: 8. Overhang: 295 mm. Hole: M20 mm. Flange: Vertical. EC certification mark: ABG Allgeme Read more.

  • Worldwide shipping*
  • Customer rating 9,3/10
  • 30-day return policy
  • 98,000+ technical products

Larger quantity required?



Any questions about this product?
Or do you need any help ordering? Feel free to get in touch with our support department at [email protected]. We're happy to help!

Product description

Drawbar eye by Scharmüller, version Pick-up hitch, with a diameter of 50 mm. The hole pattern is 145 x 145 mm, with 8 holes and M20 bore. The overhang is 295 mm, the D-value 102,4 kN and the load capacity 3000 kg. It is black, has a rotatable ring as lock and a vertical flange. The EC certification mark is an ABG (Allgemeine Bauartgenehmigung). Assembly according to DIN 9678 and ISO20019.

Specifications Scharmüller Drawbar eye Pick-Up Hitch Ø 50 mm

Article number77700654430
Weight24 kg
VersionPick-up hitch
D-value102,4 kN
Hole pattern145 x 145 mm
Towing eye Ø50 mm
Load capacity3000 kg
ColourBlack
LockRing, rotatable
No. of holes8
Overhang295 mm
Hole (mm)M20
FlangeVertical
EC certification markABG Allgemeine Bauartgenehmigung
Assembly notesDIN 9678, ISO20019
