Manuli Hydraulic hose R15 Goldeniso/42 Xtraflex DN 10 (3/8"), 420 bar

MANULI hydraulic hose

Replaces: H10097010MBC9

Technical data:

• Type testing: CU-TR; MSHA; FRAS; B; ABS; BV; LR; RINA; DNV-GL(MED);DNV-GL; MA
• Hose type: GOLDENISO
• Version: 4 steel wire spiral inserts
• Press fitting (skive): 815M00910-06
• Burst pressure (bar): 1680
• Weight (g/m): 688
• Operating pressure max. (bar): 420
• Bending radius (mm): 100
• Outer Ø (mm): 20
• Comparison no.: H10097010MBC9
• Description: R15
• Nominal width: DN 10 - 3/8"
