Manuli Hydraulic hose R15 Goldeniso/42 Xtraflex DN 32 (1 1/4"), 420 bar

MANULI hydraulic hose

Replaces: H10097031MRC9

Technical data:

• Hose type: GOLDENISO
• Version: 4 steel wire spiral inserts
• Press fitting (non-skive): 11394710
• Comparison no.: H10097031MRC9
• Outer Ø (mm): 49.5
• Description: R15
• Operating pressure max. (bar): 420
• Bending radius (mm): 260
• Press fitting (skive): 815M01600-20
• Nominal width: DN 32 - 1 1/4"
• Type testing: CU-TR; MSHA; FRAS; B; ABS; BV; LR; RINA; DNV-GL(MED);DNV-GL; MA
• Burst pressure (bar): 1680
• Weight (g/m): 3663
