Name: MAHLE Starter motor with reduction 12 V, 6,5 kW, 12 teeth, mounting angle l 60
Brand: MAHLE
SKU: 379IS1182
Price: 949.52 EUR

MAHLE Starter motor with reduction 12 V, 6,5 kW, 12 teeth, mounting angle l 60

MAHLE Starter motor with reduction gear 12V 6.5 kW 12 teeth clockwise

Replaces: MS 76

Technical data:

Nominal voltage (V): 12
Nominal power (kW): 6.5
No. of pinion teeth: 12
Holes / PCD (mm): 3 x 16.7 / 146.0
Spacing flange to flywheel (mm): 51.0
Fitting Ø (mm): 92.0
Installation angle (°): l 60
Direction of rotation: clockwise

Suitable for:

Case IH: 2470, 2870, 2090, 2290, 2390, 4490, 4690, 4890, Steiger 9110 (12/86-6/89), Steiger 9130 (12/86-6/89), Steiger 9150 (12/86-6/89)

Hyster: Diverse

John Deere: 9410R, 9420R, 9460R, 9460RT, 9470R, 9470RT, 9470RX, 9510R, 9510RT, 9520R, 9520RT, 9520RX, 9560R, 9560RT, 9570R, 9570RT, 9570RX, 5010, 5020, 6030, 8630, 8640, 8650, 8760, 8770, 8870, 5200, 5400, 5820, 5830, 5440, 5460, 6610, 6710, 6650, 6750, 6850, 7300, 7400, 7500, 7700, 7350, 7450, 7550, 7750, 7380, 7480, 7580, 7780, 8300, 8400, 8500, 8600, 9200, 9300, 9300T, 9400, 9400T, 9120, 9220, 9320, 9320T, 9420, 9420T, 9520, 9520T, 9620, 9620T, 9330, 9430, 9430T, 9530, 9530T, 9630, 9630T, S 680, S 685, S 690, STS 9860, STS 9880
