Manuli Swage fitting Interlock CAT SAE flange 1 1/2", 30°, DN 38

Swage fitting INTERLOCK / INTERLOCK PLUS

Replaces: M43930-24-24

Technical data:

• A (mm): 135
• D (inches): 1 1/2”
• Flange: 1 1/2”
• S (mm): 14.3
• Description: SAE flange, heavy, 30°
• Nominal width: DN 38 - 1 1/2"
• Comparison no.: M43930-24-24
• Series: 9000 PSI
• B (mm): 32
• O-ring: 47.2 x 3.5
• D (mm): 63.7
• Type formula: SFS 30°
• E (mm): 28
