Manuli Swage fitting Interlock CAT SAE flange 1", 30°, DN 19

Swage fitting INTERLOCK / INTERLOCK PLUS

Replaces: M43930-12-16

Technical data:

• Type formula: SFS 30°
• Series: 9000 PSI
• O-ring: 32.9 x 3.5
• Nominal width: DN 19 - 3/4"
• B (mm): 20
• E (mm): 22.5
• Comparison no.: M43930-12-16
• Description: SAE flange, heavy, 30°
• D (mm): 47.7
• S (mm): 14.3
• Flange: 1"
• A (mm): 99
• D (inches): 1"
