Manuli Swage fitting Interlock CAT SAE flange 1 1/2", 67.5°, DN 31

Swage fitting INTERLOCK / INTERLOCK PLUS

Replaces: M43970-20-24

Technical data:

• Nominal width: DN 31 - 1 1/4"
• D (inches): 1 1/2”
• Type formula: SFS 67.5°
• Series: 9000 PSI
• D (mm): 63.6
• Flange: 1 1/2”
• O-ring: 47.2 x 3.5
• S (mm): 14.3
• A (mm): 139.5
• Description: SAE flange, heavy, 67.5°
• Comparison no.: M43970-20-24
• E (mm): 78
• B (mm): 32
