S1 (mm): 27 | E (mm): 25 | C (mm): 2.3 | A (mm): 73 | T: M22 x 1.5 | Thread: M22 x 1.5 | Ø D2 (mm): 9.7 | Nominal width: DN 12 - 1/2" | Ø D1 (mm): 15 | L2 (mm): 24 | H2 (mm): 27 | Tube Ø (mm): 15 | L1 (mm): 56 | B (mm): 15 L | Hose: DN12- 1/2" Read more.
Swage fitting stainless DKOL M22 x 1.5, tube Ø 15 mm, 45°, DN 12
Swaged hosetail stainless
Replaces: DKOL-15-45°-DN 12, 202340
Technical data:
