GRAMMER Compacto Comfort M

MSG93/521

Technical data:

• Seat heater: Optional
• Upholstery type: Fabric
• Fore/aft isolator: Yes
• Seat contact switch: Optional
• Height (mm): 700
• Suspension: Air suspension
• Version: The Compacto Comfort M combines GRAMMER's typical suspension, seating and operating comfort in a very small space. The seat can be adjusted with one hand. The air suspension is equipped with combined weight and height adjustment. An easy-to-read display band guarantees that the remaining suspension travel is within the green range regardless of the driver's weight.
• Restraint system: Yes
• Armrest: Optional
• Rückenverlängerung: Optional
• Lordosenstütze: Mechanical
• Track gauge (mm): 225
• • Comfort seat with air suspension and 12V compressor • Suspension travel 80 mm • Weight adjustment, adjustment range of 50 - 130 kg • Height adjustment 60 mm, continuous (air-assisted) • Longitudinal adjustment 180 mm • Mechanical lumbar support • Backrest and tilt adjustment • Seat cushion width 450 mm
• Seat width (mm): 450
• Seat type: MSG93/521
• Length (mm): 552
• On-board voltage (V): 12
