Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
9,4688 reviews
(0)
-8%
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
-8%
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
-8%
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
-8%
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper
Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper

Hydraulic top link cat. 2/25,4, Ø 45/70 mm, stroke 185 mm, upper

€1.452,03
€1.335,87 Incl. 21% VAT
€1.104,02 Excl. VAT
In stock

Piston rod Ø D (mm): 45 | F (mm): 529 / 714 | Max. power kW (PS): 92 (125) | Stroke (mm): 185 | B cat.: 2 / 25,4 | Version: With damping | Included in delivery: Nitrogen drain screw. The screw must be removed as the nitrogen must be drained before disposi Read more.

  • Worldwide shipping*
  • Customer rating 9,3/10
  • 30-day return policy
  • 98,000+ technical products

Larger quantity required?



Any questions about this product?
Or do you need any help ordering? Feel free to get in touch with our support department at [email protected]. We're happy to help!

Product description

Hydraulic top link category 2/25,4 with inner cylinder Ø 70 mm, piston rod Ø 45 mm, stroke 185 mm, F dimension 529/714 mm and maximum power 92 kW (125 PS). Version with damping, type tail hook/clevis joint, check valve at the top. A nitrogen drain screw is included; this must be removed, as the nitrogen must be drained before disposing of the cylinder.

Specifications Hydraulic top link cat. 2/25,4

Article number36123628
Weight15,47 kg
Piston rod Ø D45 mm
F529 / 714 mm
Max. power kW (PS)92 (125)
Stroke185 mm
B cat.2 / 25,4
VersionWith damping
Included in deliveryNitrogen drain screw. <b> The screw must be removed as the nitrogen must be drained before disposing of the cylinder. </b>
A cat.2 / 25,4
Description<b> The most important advantages at a glance: </b> Reduced material stress on the tractor and implement Higher comfort when driving and working Longer mechanical component life Higher occupational safety thanks to minimised impact loads Hydraulic top links with damping are used for demanding applications where varying loads occur such as transport, grassland maintenance or arable farming
Check valveTop
Cylinder Ø inner E70 mm
TypeTail hook/clevis joint
Top link typehydraulic
