Manuli Swage fitting Spiralfit heavy SAE flange 1", 60°, DN 25

Swage fitting SPIRALFIT

Replaces: M83661-16-16

Technical data:

• A (mm): 92
• Comparison no.: M83661-16-16
• Type formula: SFS 60°
• D (inches): 1"
• Description: SAE flange, heavy, 60°
• B (mm): 19.5
• Nominal width: DN 25 - 1"
• Flange: 1"
• D (mm): 47.7
• Series: 6000 PSI
• E (mm): 45
