Seat

• Height (mm): 480
• Length (mm): 491 → 508
• Technical data: ● Fastening points for retrofitting lap belts
  ● Sprung seat with suspension adjustment for weights from 50 kg to 130 kg
  ● Longitudinal adjustment with guide rails 250 mm
  ● Adjustment range 150 mm in steps of 15 mm
  ● Backrest tilt adjustment 0°-13°
• Suspension: mechanical
• Track gauge (mm): variable
• Gauge: Variable
• Upholstery type: PVC
• Seat contact switch: Yes
• Rotation: No
• Seat width (mm): 480
• Joystick console: No
• Side horizontal suspension: No
• Restraint system: Optional
• Seat heater: No

Passend voor:

• Still: 0657936, 50734331006, 0613698, R20, R20-14 (2017-2024), R20-15 (2008, 2009, 2010, 2014), R20-15 (2017-2024), R20-15i (2015i), R20-16 (2008, 2009, 2010, 2014), R20-16 (2017-2024), R20-18 (2008, 2009, 2010, 2014), R20-18 (2017-2024), R20-20 (2008, 2009, 2010, 2014), R20-20 (2017-2024), R50, R50-10 (5041-5044), R50-12 (5041-5044), R50-15 (5041-5044), R50-16 (5041-5044), R60, R60-22 (6036-6039), R60-22 (6042-6045), R60-25 (6036-6039), R60-25 (6042-6045), R60-30 (6042-6045), R70, R70-16CT (7097-7099), R70-16D (7094-7096), R70-18CT (7097-7099), R70-18D (7094-7096), R70-20CD (7094-7096), R70-20CT (7097-7099), RX20, # New RX20 14-20 (6209-6217), RX20-14 (6210-6217), RX20-15 (6210-6217), RX20-16 (6210-6217), RX20-18 (6210-6217), RX20-20 (6210-6217), RX50, # New RX50 10-16 (5051-5055), # New RX50 10-16 (5060-5066), RX50-10 (5051-5055), RX50-10 (5061-5066), RX50-10 compact (5061-5066), RX50-13 (5051-5055), RX50-13 (5061-5066), RX50-15 (5051-5055), RX50-15 (5061-5066), RX50-16 (5051-5055), RX50-16 (5061-5066), RX60, # New RX60 25-35 (6345-6348, 6353-6356), RX60-16 6311, 6313, 6315), RX60-18 (6311, 6313, 6315), RX60-20 (6311, 6313, 6315), RX60-25 (6321-6325), RX60-25 (6345-6348, 6353-6356), RX60-25/600 (6321-6325), RX60-25/600 (6345-6348, 6353-6356), RX60-25L/600 (6321-6325), RX60-25L/600 (6345-6348, 6353-6356), RX60-30 (6321-6325), RX60-30 (6345-6348, 6353-6356), RX60-30/600 (6321-6325), RX60-30/600 (6345-6348, 6353-6356), RX60-30L/600 (6321-6325), RX60-30L/600 (6345-6348, 6353-6356), RX60-35 (6321-6325), RX60-35 (6345-6348, 6353-6356), RX70, # New RX70 22-35 (7321-7324, 7329, 7330), RX70-22 (7321-7324, 7329, 7330), RX70-22T (7325-7328), RX70-25 (7321-7324, 7329, 7330), RX70-25T (7325-7328), RX70-30 (7321-7324, 7329, 7330), RX70-30T (7325-7328), RX70-35 (7321-7324, 7329, 7330), RX70-35T (7325-7328)
