Ford 5640 tractor parts & technical data

Working on a Ford 5640? This page has more than 160 matching parts for this 40 series tractor, with electrics, lighting and trailer couplings up front.

165 parts found for Ford 5640
Show:
Mirror with holder, left Ford, Fiat, New Holland
Installation location: Left. Additional information: With holder. More
Installation location: Left. Additional information: With holder.
€175,25 €144,83 €161,23 €133,25
You save 8%
Scharmüller Drawbar automatic rail width 320 mm, coupling pin 38 mm
Scharmüller
Rail width: 320 mm. Detent pin Ø: 30 mm. Guide width: 20 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 89,3 kN. Colour: Black. Descript... More
Rail width: 320 mm. Detent pin Ø: 30 mm. Guide width: 20 mm. Connecti...
€1.256,32 €1.038,28 €1.155,81 €955,22
You save 8%
Direction switch steering wheel mounting, forwards - forwards
Version: Forwards/neutral/reverse, lock, Connection cable with plug. More
Version: Forwards/neutral/reverse, lock, Connection cable with plug.
€254,45 €210,29 €234,09 €193,47
You save 8%
Rear light, brake light, indicator 200 x 70 x 62 mm, 12/24 V
Bulb: 12V21WK / P21W, 12V21/5WK / P21/5W. Width: 200 mm. Form: Rectangular. Height: 70 mm. Hole spacing: 90 mm. Dimensions W x H x D: 200 x 70 x 62 mm... More
Bulb: 12V21WK / P21W, 12V21/5WK / P21/5W. Width: 200 mm. Form: Rectang...
€75,76 €62,61 €69,70 €57,60
You save 8%
Relays make contact 12 V, 20 A, without bracket, 4-pin
Version: 12 V / 20 A, Without holder, 4-pin, flat plug connection. More
Version: 12 V / 20 A, Without holder, 4-pin, flat plug connection.
€40,43 €33,41
Brake hose Ford 5640-8340, New Holland series TS, TV
€110,20 €91,07 €101,38 €83,79
You save 8%
Water pump Ford 5640-8340
€293,63 €242,67 €270,14 €223,26
You save 8%
Borg Warner Fan clutch Ford, Case IH, Steyr, New Holland
€343,31 €283,73 €288,79 €238,67
You save 16%
Tube 1180 mm, inner-Ø 70 mm
Version: Length: 1180 mm, Inner Ø: 70 mm. Inner Ø: 70 mm. Length: 1180 mm. More
Version: Length: 1180 mm, Inner Ø: 70 mm. Inner Ø: 70 mm. Length: 11...
€201,14 €166,23 €185,05 €152,93
You save 8%
Oil pressure switch transmission oil pressure, 2 blade connections
Version: With sealing ring and 2 blade terminals. More
Version: With sealing ring and 2 blade terminals.
€137,00 €113,22 €126,04 €104,17
You save 8%
Signal transmitter engine oil pressure
Version: Engine oil pressure. More
Version: Engine oil pressure.
€434,27 €358,90 €399,53 €330,19
You save 8%
Hand brake cable right 1820 mm, thread M8 Ford, New Holland
Length: 1820 mm. Thread: M8. Dimensions: Length = 1820 mm, Thread M8. More
Length: 1820 mm. Thread: M8. Dimensions: Length = 1820 mm, Thread M8.
€69,19 €57,18 €63,65 €52,61
You save 8%
Hand brake cable 595 mm Ford 5110-8340, New Holland TS90-TS110
Length: 595 mm. Dimensions: Length = 595 mm. More
Length: 595 mm. Dimensions: Length = 595 mm.
€534,22 €441,50 €491,48 €406,18
You save 8%
Turbocharger retrofit kit engine 4,4 l/5,0 l Ford TH-680, Series 40-6640
€5.003,20 €4.134,88 €4.844,64 €4.003,83
You save 3%
Gas strut rear window 200 N, 585 mm
Newtons: 200. A: 585 mm. B: 290 mm. C: 10 mm. D: 10 mm. To fit: rear screen. Form: 6. More
Newtons: 200. A: 585 mm. B: 290 mm. C: 10 mm. D: 10 mm. To fit: rear s...
€33,51 €27,70
Cover for switch cut-off / controls
Version: For switch cut-out (fittings). More
Version: For switch cut-out (fittings).
€18,38 €15,19
Replacement key plastic-coated, blue
Version: To fit: Fiat, Ford. More
Version: To fit: Fiat, Ford.
€10,41 €8,61
Flasher unit electronic 12 V, 5 blade connections
Version: 12 V, without bracket, 5 blade terminals. More
Version: 12 V, without bracket, 5 blade terminals.
€124,66 €103,02 €114,69 €94,78
You save 8%
Showing 145 - 165 of 165

Ford 5640 tractor parts

Does the front of your Ford 5640 wander on the road, or do you keep correcting the wheel to hold a straight line? The cause is often in the ball joints or axial joints. This page covers more than 160 parts that fit the 5640, from steering joints to starter motors, made by GRANIT and by brands such as MAHLE, Eaton, Cobo and LUK.

Steering and front axle

For the steering there are ball joints and axial joints. To find play, jack up the front axle and rock the wheel at front and rear while someone else watches the joints. Always fit a new ball joint with a new nut and split pin, seat the taper clean and dry in the arm, and tighten the nut before you fit the split pin. Have the toe-in reset afterwards, otherwise the front tyres will wear unevenly. Inner plates for the front axle are listed on this page too.

Engine, clutch and PTO

  • Starter motors and alternators for the starting and charging circuit.
  • Clutch plates, including LUK.
  • Gaskets for the exhaust and water pump, and silencers.
  • PTO shaft end pieces for the rear.
  • Tank caps for the fuel tank.

A tank cap looks like a minor part, but it can cause real trouble. If the breather is blocked, the lift pump pulls a vacuum in the tank and the engine dies under heavy load. If the seal is worn, dirt and water find their way into the diesel. Either way, a new cap sorts it out quickly.

Cab, lights and drawbar

For the cab and bodywork there are rear window gas struts, mirrors, indicator and position lights, and hand brake cables. At the rear you will find drawbars. A hand brake cable that has gone stiff is best replaced straight away rather than freed off with penetrating oil, so the brake still holds on a slope.

Getting the fit right

The type plate on the 5640 and the reference number on the old part are your best guide. With ball joints, also check the thread direction and the taper, because left and right joints look very much alike. Ford placed the 5640 in its 40 series. The Ford 8240 from the same series has its own page with the parts that fit that model, which is useful if you look after both tractors. Looking after a different Ford tractor? Start from Ford parts.
