Ford TW 15 tractor parts & technical data

Ford TW 15 parts in one overview: more than 100 items for this TW series tractor, with lighting, electrics and trailer couplings as the main product groups.

107 parts found for Ford TW 15
Show:
Cobo Indicator/position light 196 x 86 x 74 mm left yellow, white P21W, R5W
Cobo
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 196 mm. Form: Rectangular. Height: 86 mm. Dimensions W x H x D: 196 x 86 x 74 mm. De... More
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 196 ...
€70,08 €57,92 €64,47 €53,28
You save 8%
Indicator/position light 199 x 85 x 145 mm, P21W, R5W left
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 199 mm. Form: Rectangular. Height: 85 mm. Dimensions W x H x D: 199 x 85 x 145 mm. D... More
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 199 ...
€72,48 €59,90 €66,68 €55,11
You save 8%
Rear light left 199 x 85 x 145 mm, 12 V
Bulb: 12V21WK / P21W, 12V21 / 5WK / P21 / 5W. Width: 199 mm. Form: Rectangular, short sides rounded. Height: 85 mm. Dimensions W x H x D: 199 x 85 x 1... More
Bulb: 12V21WK / P21W, 12V21 / 5WK / P21 / 5W. Width: 199 mm. Form: Rec...
€55,71 €46,04 €51,25 €42,36
You save 8%
Cobo Glass lamp left, right
Cobo
Installation location: Right, left. More
Installation location: Right, left.
€25,01 €20,67
Heating element engine preheater Ford, Fiat, New Holland
€228,03 €188,45 €209,79 €173,38
You save 8%
Scharmüller Flange hitch manual 31 mm, 140 x 80 mm, M17, 2500 kg, 82,4 kN
Scharmüller
Lock: Manual pin. Hole pattern: 140 x 80 mm. Load capacity: 2500 kg. D-value: 82,4 kN. Hole: M17 mm. No. of holes: 4. Colour: Black. Connecting pin: 3... More
Lock: Manual pin. Hole pattern: 140 x 80 mm. Load capacity: 2500 kg. D...
€384,16 €317,49 €374,27 €309,31
You save 3%
Cobo Rear light left 184 x 76 x 155 mm, 12 V, hole spacing 111 mm
Cobo
Nominal voltage: 12 V. Installation location: Left. Bulb: 12V21WK / P21W, 12V21/5WK / P21/5W. Bulbs included: No. Light function: Indicator light, rea... More
Nominal voltage: 12 V. Installation location: Left. Bulb: 12V21WK / P2...
€79,55 €65,74 €73,19 €60,48
You save 8%
Cover for switch cut-off / controls
Version: For switch cut-out (fittings). More
Version: For switch cut-out (fittings).
€18,38 €15,19
Lamp glass right, left
Installation location: Right, left. More
Installation location: Right, left.
€29,10 €24,05
Cobo Lamp glass right, left
Cobo
Installation location: Right, left. Menke no.: 55060. More
Installation location: Right, left. Menke no.: 55060.
€26,13 €21,59
Showing 97 - 107 of 107

Ford TW 15 parts, cab parts and electrics

A Ford TW 15 that has spent decades on the same farm tends to need the same handful of things: a clutch that has started to slip, an alternator that no longer keeps the battery up, a door that will not stay open on a slope. This page brings together more than 100 parts for the TW 15, made by GRANIT, Cobo, LUK, HELLA and Eaton.

Cab parts for the TW 15

For the cab there are gas struts that hold the door open, along with headlights, rear lights and lamp glass. A tired strut is one of the easiest fixes on the tractor and makes getting in and out a lot safer. Indicator position lights complete the lighting, and a single lamp glass is available where only the lens has cracked.

Driveline, steering and charging

Clutch plates and inner plates deal with a slipping or dragging clutch. While the tractor is split, look closely at the flywheel face. Heat marks or deep scoring will shorten the life of a new plate, so it pays to sort that out first. Ball joints take the slack out of the steering, and flange hitches renew the coupling point at the back. For charging and starting there are alternators and starter motors. Check the earth strap and belt tension before condemning an alternator, since both can mimic a failed unit.

Cooling and sealing

The fan clutch on this engine is a common wear item. With the engine cold, spin the fan by hand. If it freewheels for several turns or there is oil on the front of the clutch, it is time to replace it. An engine that runs hot during heavy summer work is often the first hint. Gaskets and seals include the joint between the exhaust manifold and turbocharger and the seal for the feed pump.

Getting the right part first time

The type plate confirms that the tractor is a TW 15 and not another model from the TW series. Alternators and starter motors usually carry a number on the housing. Compare that with the reference number shown with the product, and check the mounting points and pulley as well. With ball joints, the thread and taper of the old part decide the match. With lights, note if you need the left or the right side.

Older Ford series and the other TW models have their own pages, all reachable through Ford parts. Each tractor there has its own list, which keeps orders for a mixed fleet straightforward.
