Manuli Swage fitting Spiralfit CAT SAE flange 1", 45°, DN 19

Swage fitting SPIRALFIT

Replaces: M83941-12-16

Technical data:

• Flange: 1"
• Series: 9000 PSI
• A (mm): 92
• S (mm): 14.3
• Description: SAE flange, heavy, 45°
• B (mm): 19.5
• Nominal width: DN 19 - 3/4"
• Comparison no.: M83941-12-16
• D (mm): 47.7
• E (mm): 35.5
• Type formula: SFS 45°
• D (inches): 1"
