Fendt 209 Vario (Typ 332) tractor parts & technical data

Got a Fendt 209 Vario with Typ 332 on the type plate? More than 250 parts on this page fit it, including lighting, trailer couplings and electrics.

300 parts found for Fendt 209 Vario
Show:
PROBOSS Passenger seat long with seat cushion, additional rotation Fendt
PROBOSS
Technical data: • With additional rotation, • Seat cushion, • Meets all legal requirements, • Can be stored compactly in the cab, • Does not... More
Technical data: • With additional rotation, • Seat cushion, • Me...
€834,29 €689,50 €659,59 €545,11
You save 21%
Fender attachment Fendt
FUCHS LUBRITECH High pressure grease Lagermeister XXL -20 up to 160 °C - 500 gram
€59,19 €48,92 €54,45 €45,00
You save 8%
Wabco Solenoid valve 3/2-way, 12 V, 1,41 A, M16 x 1,5, standard closed
Wabco
Eligible: Environmental protection and safety (formerly de minimis) More
Eligible: Environmental protection and safety (formerly de minimis)
€408,59 €337,68 €375,90 €310,66
You save 8%
Indicator-width bulb LED 12 / 24 V, 84 x 84 x 51 mm, cable 4000 mm
Connection: Nylon 6.3 | Bulbs included: Yes | Fixing: Screwed | Light function: Indicator, position light | Nominal voltage (V): 12 / 24 | Additional ... More
Connection: Nylon 6.3 | Bulbs included: Yes | Fixing: Screwed | Light ...
€54,98 €45,44 €50,58 €41,80
You save 8%
LED main headlight square 183 x 102 x 73 mm, H4, 12/24 V
Light colour (K): 5.700 - 6.500 | Test mark: ECE R10, R148, R149, CE UKCA, ROHS | Power consumption (W): Abblendlicht: 22 W Fernlicht: 20 W Tagfahrlic... More
Light colour (K): 5.700 - 6.500 | Test mark: ECE R10, R148, R149, CE U...
€167,17 €138,16 €153,80 €127,10
You save 8%
Wabco Connector head M22 x 1,5 black aluminum with valve, 8 bar
Wabco
Operating pressure max. (bar): 8 | Version: Black, aluminium, with valve, for vehicles | Vehicle/application: For single-line brake, towing vehicle | ... More
Operating pressure max. (bar): 8 | Version: Black, aluminium, with val...
€96,48 €79,74 €88,76 €73,36
You save 8%
Wabco Antifreeze pump 13 bar, 0,2 cm³, without control connection 4
Wabco
Connection: 1x M12 x 1.5 / 3x M22 x 1.5. Operating pressure max.: 13 bar. Delivery volume: 0.2 cm³. Contents: 500 ml. Version: • Prevents equipment... More
Connection: 1x M12 x 1.5 / 3x M22 x 1.5. Operating pressure max.: 13 b...
€301,21 €248,93 €277,11 €229,02
You save 8%
Pump screenwash tank 12 V, intake-Ø 6,3 mm, press-Ø 6,3 mm
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system. Voltage: 12 V. Connection type: 2 x 6,3. Operating mode: electric. More
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system...
€35,49 €29,33 €32,65 €26,98
You save 8%
Knorr Bremse Antifreeze pump air pressure- / brake system, 684 g
€280,12 €231,50 €257,71 €212,98
You save 8%
Force sensor pin 40 kN, 158,3 mm, Ø 36,8 mm Fendt
Dimensions: Length = 158.3, Ø = 36.8 mm. Ø: 36,8 mm. Length: 158,3 mm. More
Dimensions: Length = 158.3, Ø = 36.8 mm. Ø: 36,8 mm. Length: 158,3 m
€595,58 €492,21 €547,93 €452,84
You save 8%
HELLA Headlight left / right 12 / 24 V, H4, 182 x 102 x 88 mm, built-in Fendt
HELLA
Bulb: 12V60/55W / H4, 24V75/70W / H4. Colour: Surround: black. Width: 182 mm. Height: 102 mm. Material: Plastic. Dimensions W x H x D: 182 x 102 x 88 ... More
Bulb: 12V60/55W / H4, 24V75/70W / H4. Colour: Surround: black. Width: ...
€66,79 €55,20 €64,32 €53,16
You save 4%
Wabco Trailer control valve 0 - 0,5 bar activation, 14 bar final pressure, 2 m³
Wabco
Set pressure (bar): 0-0,5 | Displacement (m³): 2 | End pressure (bar): 14 More
Set pressure (bar): 0-0,5 | Displacement (m³): 2 | End pressure (bar)...
€1.834,61 €1.516,21 €1.687,84 €1.394,91
You save 8%
Connector head M22 x 1,5 red, supply line, vehicle
Additional information: - For dual-line brake systems for vehicles - Connect the air brake system of the truck or tractor unit with the brake system o... More
Additional information: - For dual-line brake systems for vehicles - C...
€25,70 €21,24
HELLA Symbol beacon light yellow
HELLA
Version: Yellow, rotating beacon. Colour: gelb. To fit: HELLA Schalter Serien 4570 und 7832. Symbol: Rundumleuchte 1. More
Version: Yellow, rotating beacon. Colour: gelb. To fit: HELLA Schalter...
€3,00 €2,48
Scharmüller Bottom drawbar ball 80, 3000 kg, 306 x 443 mm, 1 center bolt
Scharmüller
Lock: ball 80. Load capacity: 3000 kg. D-value: 65,7 kN. Length: 306 mm. Width: 443 mm. Thickness: 50 mm. Number of heart pins: 1. Colour: AGCO grey. ... More
Lock: ball 80. Load capacity: 3000 kg. D-value: 65,7 kN. Length: 306 m...
€1.567,30 €1.295,29 €1.491,92 €1.232,99
You save 5%
DANA Spicer Wheel bolt M18 x 1,5, 60 mm final drive front axle 730
DANA Spicer
Length (mm): 60 | Thread: M18 X 1,5 More
Length (mm): 60 | Thread: M18 X 1,5
€16,23 €13,41
HELLA Indicator/position light 12 V, R21W/C5W, yellow/white - 2 pieces
HELLA
Bulb: 12V5WS / C5W 12V21WK / R21W | Version: For front mounting, horizontal, yellow indicator light, white position light, with 2 holes for M4 fixing ... More
Bulb: 12V5WS / C5W 12V21WK / R21W | Version: For front mounting, horiz...
€47,11 €38,94
LED headlight 12/24 V, 117.4 x 125 x 112.3 mm, left/right
Protection class: IP66, IP6K9K | Form: Round | Nominal voltage (V): 12 / 24 | Housing material: Aluminum | Connection: 9005, AMP | Installation locati... More
Protection class: IP66, IP6K9K | Form: Round | Nominal voltage (V): 12...
€145,96 €120,63 €134,28 €110,98
You save 8%
BOSCH High-pressure pump CP1H Fendt, Massey Ferguson, Valtra-Valmet
€1.964,66 €1.623,69 €1.665,11 €1.376,13
You save 15%
Button Fendt, Case IH
€39,04 €32,26 €35,92 €29,68
You save 8%
HELLA Headlight left / right 12 V, H4, 182 x 102 x 94 mm, built-in
HELLA
Bulb: 12V60/55W / H4. Colour: Lens: white/transparent. Width: 182 mm. Height: 102 mm. Material: Plastic. Housing: Plastic. Dimensions W x H x D: 182 x... More
Bulb: 12V60/55W / H4. Colour: Lens: white/transparent. Width: 182 mm. ...
€88,26 €72,94 €84,99 €70,24
You save 4%
Walterscheid Drawbar support rail 311 mm, 92 kN, nose weight 3500 kg, Fendt gray
Walterscheid
F (mm): 220 | E (mm): 75 | Description: The drawbar supports are height-adjustable sliding plates that can only be operated in hitch supports with loc... More
F (mm): 220 | E (mm): 75 | Description: The drawbar supports are heigh...
€1.935,62 €1.599,69 €1.530,32 €1.264,73
You save 21%
Walterscheid Inner part ball 80 rail width 311 mm, pin Ø 22 mm, 3000 kg
Walterscheid
Description: This product is a ball support with two locking bolts. The hitch ball 80 dimensions and areas of application comply with ISO 24347, VO (E... More
Description: This product is a ball support with two locking bolts. Th...
€2.222,24 €1.836,56 €1.756,92 €1.452,00
You save 21%
Scharmüller Retrofit kit drawbar 965 mm, 60 x 40 mm, pin 31,5 mm, 20 kN, position 3
Scharmüller
Version: Retrofit kits | Width x height (mm): 60 x 40 | Colour: Black | Mounting position: 3 | D-value (kN): 20 | Load capacity (kg): 500 | Length (mm... More
Version: Retrofit kits | Width x height (mm): 60 x 40 | Colour: Black ...
€1.020,90 €843,72 €989,23 €817,55
You save 3%
Connector head M16 x 1,5 red, supply line, vehicle
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, supply line | Menke no.: 55927 | Additional information: - For dual-line brake sys... More
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, su...
€24,88 €20,56
Sauermann Wear plate trailer coupling HS 1710-1KUD/3KUD
€179,80 €148,60 €165,42 €136,71
You save 8%
MAHLE Alternator 14 V, 120 A, flange 56 mm, compact, dust-tight
MAHLE
Direction of rotation: ↻ | Installation angle (°): l 30 | Pulley Ø (mm): - | Additional information: Compact alternator, dust-tight | Mounting L /... More
Direction of rotation: ↻ | Installation angle (°): l 30 | Pulley Ø...
€388,90 €321,41 €232,93 €192,50
You save 40%
Expansion tank radiator Fendt 207 - 211, 310 - 314, 927 - 939
€77,25 €63,84 €71,07 €58,74
You save 8%
HELLA Headlight left / right 12 V, H7, built-in, glass Ø 90 mm Fendt
HELLA
Bulb: 12V55W / H7. Dimensions: 108 x 181.7 mm. Connection: AMP. Form: Round. Height: 108 mm. Material: Diffusing lens: glass. Depth: 181,7 mm. Install... More
Bulb: 12V55W / H7. Dimensions: 108 x 181.7 mm. Connection: AMP. Form: ...
€157,83 €130,44 €152,01 €125,63
You save 4%
Scharmüller Drawbar frame standard ball 80, 89,3 kN, 3000 kg, rail 311 mm
Scharmüller
Version: Standard | D-value (kN): 89,3 | Guide width (mm): 30 | Load capacity (kg): 3000 | Rail width (mm): 311 | Category: Bearing supports | Detent ... More
Version: Standard | D-value (kN): 89,3 | Guide width (mm): 30 | Load c...
€2.018,74 €1.668,38 €1.907,24 €1.576,23
You save 6%
Interval relays windshield wiser 12 V, 5 A, 6-pin blade terminal Fendt
Connection type: Blade terminal | Nominal voltage (V): 12 | Current (A): 5 | Number of pins: 6 More
Connection type: Blade terminal | Nominal voltage (V): 12 | Current (A...
€46,03 €38,04
Scharmüller Adapter plate rail width 311 mm, hole pattern 140 x 80 mm, M20
Scharmüller
Load capacity: 2000 kg. D-value: 83,9 kN. Rail width: 311 mm. Hole pattern: 140 x 80 mm. Guide width: 30 mm. Plate height: 175 mm. Thread: M20. Colour... More
Load capacity: 2000 kg. D-value: 83,9 kN. Rail width: 311 mm. Hole pat...
€673,94 €556,97
Cobo Reversing warning system 12 / 24 V, 85 dB, 2900 Hz, continuous or pulsating
Cobo
Nominal voltage: 12 / 24 V. Volume: 85 dB. Frequency: 2900 Hz. Connection: Blade terminal. Cable length: - m. Protection class: IP65. Dimensions L x W... More
Nominal voltage: 12 / 24 V. Volume: 85 dB. Frequency: 2900 Hz. Connect...
€64,32 €53,16 €59,17 €48,90
You save 8%
Replacement key plastic-coated black, lock number 14607
Version: Locking no. 14607 | To fit: New Holland, Steyr More
Version: Locking no. 14607 | To fit: New Holland, Steyr
€7,59 €6,27
Walterscheid Adapter plate rail width 311 mm, hole pattern 140 x 80 mm, M20
Walterscheid
Hole pattern (mm): 140 x 80 | Colour: Black | D-value (kN): 89,3 | Guide width (mm): 30 | Hole (mm): M20 | Assembly notes: The vehicle part support di... More
Hole pattern (mm): 140 x 80 | Colour: Black | D-value (kN): 89,3 | Gui...
€785,67 €649,31 €621,15 €513,35
You save 21%
Seal kit hydraulic pump G297941010010 Fendt, Massey Ferguson
€88,38 €73,04 €81,31 €67,20
You save 8%
Scharmüller Hitch automatic 82,4 kN, rail 311 mm, locking pin Ø 22 mm
Scharmüller
Description: Height adjustable with handle | Load capacity (t): 2 | Detent pin Ø (mm): 22 | D-value (kN): 82,4 | Plate height (mm): 120 | Guide width... More
Description: Height adjustable with handle | Load capacity (t): 2 | De...
€1.171,76 €968,40 €1.078,02 €890,93
You save 8%
Wabco Trailer control valve 8 bar, M22 x 1,5, screw distance 117 x 117 mm
€809,41 €668,93 €744,66 €615,42
You save 8%
DANA Spicer Wheel hub final drive front axle 730
€408,30 €337,44
Holder right width 75 mm, height 165 mm, material thickness 3 mm Fendt
Width: 75 mm. Material thickness: 3 mm. H: 165 mm. More
Width: 75 mm. Material thickness: 3 mm. H: 165 mm.
€23,99 €19,82
Bearing bush lift cylinder 35 x 39,2 x 30 mm Fendt
Dimensions: 35 x 39.2 x 30 mm. More
Dimensions: 35 x 39.2 x 30 mm.
€29,49 €24,37
Buffer hood Fendt
Maintenance switch air filter, plug connection
Version: Differential pressure switch, Plug connection. More
Version: Differential pressure switch, Plug connection.
€35,70 €29,50
Showing 1 - 48 of 300

Parts for the Fendt 209 Vario Typ 332

A work lamp that has packed up, a switch that sticks, a top link weeping oil. For a Fendt 209 Vario with Typ 332 on its type plate, the replacements are on this page: more than 250 parts selected for this version only. Running a different version? Head to the Fendt 209 Vario Typ 302 page or the overview for the Fendt 209 Vario.

What you can replace on a Typ 332

  • Electrics: push button switches such as the red hazard switch with lock, pressure switches including one for the fuel filter head, rocker switches and symbol inserts for the windscreen switches.
  • Lighting: work lamps with a spotlight beam, left and right headlights and rotating beacons, plus the spring for the beacon holder.
  • Linkage: a hydraulic top link with check valve block, along with pins and bushes.
  • Cab and bodywork: discs for the rear window hinge, covers and a holder for the wheel chock.
  • Trailer: connector heads for the air supply line.

The brands behind these parts are GRANIT, HELLA, Wabco, Scharmüller and Walterscheid.

Matching the right part

Typ 332 is your starting point, but with electrical parts it pays to look at the connector and housing of the old part as well. Take a switch or pressure switch out before ordering and look for a reference number to compare with the details on the product. For a top link, do not go by eye. Compare the category of the ball ends with what the tractor and the implement use.

Looking after work lamps and the top link

With halogen work lamps the old rule still stands: never touch the bulb glass with bare fingers. Skin oil creates a hot spot on the glass and shortens the bulb's life considerably. Use a cloth or gloves, and while you are at it check that the plug is dry and shows no green corrosion. A flickering lamp is often a connection problem rather than a lamp problem.

A hydraulic top link with a check valve holds its length as long as the valve is closed. If an implement slowly drops, look for leaks at the hose fittings first. Grease the ball ends regularly and route the hoses so they never pull tight when the linkage lifts.

Other members of the Fendt 200 series with their own page are the Fendt 207 Vario, Fendt 208 Vario, Fendt 210 Vario and Fendt 211 Vario, useful when more than one Fendt works on the farm. The rest of the brand is on the Fendt parts page.
