Fendt 313 Vario tractor parts & technical data

All in one place: more than 550 parts for the Fendt 313 Vario, a 300 series tractor, including lighting and electrics, plus seats and accessories.

599 parts found for Fendt 313 Vario
Show:
Wabco Repair set trailer brake valve Fendt Farmer 103 - 311
€413,01 €341,33 €379,97 €314,02
You save 8%
Wabco Overflow valve 6 bar, M22 x 1,5 Fendt Farmer, Favorit
Wabco
Connection: M22 x 1.5 | Working pressure (bar): 13 | Overflow pressure (bar): 6 More
Connection: M22 x 1.5 | Working pressure (bar): 13 | Overflow pressure...
€120,58 €99,65 €110,93 €91,68
You save 8%
Connector head M16 x 1,5 yellow, brake line, vehicle
Connection thread: M16 x 1.5 | Version: Yellow, brake line | Menke no.: 55929 More
Connection thread: M16 x 1.5 | Version: Yellow, brake line | Menke no....
€23,54 €19,45
Sauermann Bolts trailer coupling 38,2 x 31 x 126 mm
€301,01 €248,77 €276,93 €228,87
You save 8%
Lip ring vane connection 40 x 51 x 2,5 mm Fendt, Massey Ferguson
Dimensions (mm): 40x51x2.5 More
Dimensions (mm): 40x51x2.5
€19,83 €16,38
Expansion valve 3/8 - 1/2 inch o-ring Fendt, John Deere, Renault
Connection thread E: # 6, 3/8"" O-ring | Connection thread A: # 8, 1/2"" O-ring | Equipment: O-ring | Weight (g): 182 More
Connection thread E: # 6, 3/8"" O-ring | Connection thread A: # 8, 1/2...
€90,25 €74,59 €83,03 €68,62
You save 8%
LUK Pilot bearing PTO shaft 45 x 75 x 16 mm Fendt, John Deere
€90,40 €74,71 €83,17 €68,73
You save 8%
HELLA Work lamp flood beam Ultra beam H3, 12 V, 112 x 102 x 94 mm
HELLA
Bulb: H3 | Bulbs included: No | Test mark: ADR/GGVS tested | Form: Square | Dimensions W x H x D (mm): 112 x 102 x 94 | Mounting type: Vertical | Ligh... More
Bulb: H3 | Bulbs included: No | Test mark: ADR/GGVS tested | Form: Squ...
€32,83 €27,13 €31,62 €26,13
You save 4%
Pilot bearing 20 x 42 x 12 mm
Dimensions (mm): 20 x 42 x 12 More
Dimensions (mm): 20 x 42 x 12
€7,63 €6,30
Walterscheid Locking pawl set lift arm category 3, 3L Fendt 310 - 313, 512, 514
Walterscheid
Category: 3, 3L | Kategorie: 3 ZN/C More
Category: 3, 3L | Kategorie: 3 ZN/C
€104,04 €85,98 €77,94 €64,41
You save 25%
Alternator 14 V, 150 A, flange 55,8 mm
Charging current (A): 150 | Belt width (mm) / type: - | Flange size (mm): 55,8 | Nominal voltage (V): 14 | Form: B | Pulley Ø (mm): - | Nominal value... More
Charging current (A): 150 | Belt width (mm) / type: - | Flange size (m...
€215,54 €178,13 €198,30 €163,88
You save 8%
Elring Seal glow plug
€15,73 €13,00
GRAMMER Handle swivel adaptor 20° seat 7-series Fendt, Massey Ferguson
GRAMMER
Description: Handle for swivel adaptor 20° | Sitzoberteil: 721, 722, 731, 732, 741, 742 | Version: Handle More
Description: Handle for swivel adaptor 20° | Sitzoberteil: 721, 722, ...
€32,61 €26,95 €30,00 €24,79
You save 8%
GRAMMER Kleine replacement parts level control MSG 95 A - MSG 97 EL
GRAMMER
Version: Small parts, level control | To fit: MSG 95 A, MSG 95 AL, MSG 95 EAC, MSG 97 A, MSG 97 AL, MSG 97 EAC, MSG 97 EL More
Version: Small parts, level control | To fit: MSG 95 A, MSG 95 AL, MSG...
€34,03 €28,12
Blue Print Wiper blade, metal bracket system 525 mm / 21 inch Fendt
Blue Print
Version: Standard More
Version: Standard
€11,05 €9,13 €4,86 €4,02
You save 56%
FEBI Engine oil filter HU931/6X
€14,47 €11,96 €5,79 €4,79
You save 60%
FEBI Engine oil filter Ø 108 mm, height 144,2 mm, thread M24 x 1,5
€34,35 €28,39 €14,07 €11,63
You save 59%
Knott Industrietechnik Brake lining Fendt 309-314
Knott Industrietechnik
€227,83 €188,29 €209,60 €173,23
You save 8%
V-belt air conditioning 1050 mm Fendt
Length: 1050 mm. Version: For air conditioning system. More
Length: 1050 mm. Version: For air conditioning system.
€16,75 €13,84
Fuel filter Ø 35 mm, height 105 mm, 2x straight, 6 / 8 mm
C: 30 mm. D: 35 mm. F: 6 / 8 mm. G: 6 / 8 mm. H: 105 mm. Connection: 2x straight, 6 / 8 mm. Connection: 2x gerade, 6/8 mm. Outer Ø: 35 mm. Height: 10... More
C: 30 mm. D: 35 mm. F: 6 / 8 mm. G: 6 / 8 mm. H: 105 mm. Connection: 2...
€3,93 €3,24
Handle Fendt, Case IH
€40,91 €33,81 €37,64 €31,11
You save 8%
Walterscheid Piton Fix rail width 311 mm, locking pin Ø 22 mm, 3000 kg, 89,3 kN
Walterscheid
Rail width: 311 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 3000 kg. D-value: 89.3 kN. Colour: Black. Description: This product is a ... More
Rail width: 311 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.832,08 €1.514,12 €1.448,46 €1.197,08
You save 21%
HELLA LED work light Modul 90 flood beam, 1100 lm, Ø 103 x 108 mm
HELLA
Nominal voltage: 12 / 24 V. Form: Round. Dimensions W x H x D: Ø 103 x 108 mm. Light function: Close-range illumination. Effective luminous flux: ≈... More
Nominal voltage: 12 / 24 V. Form: Round. Dimensions W x H x D: Ø 103 ...
€363,64 €300,53 €350,22 €289,44
You save 4%
Cobo Indicator/position light 84 x 84 x 51 mm, P21W, C5W left / right
Cobo
Bulb: 12V21WK / P21W, 12V5WS / C5W. Colour: Yellow, white. Connection: Blade terminal connection. Width: 84 mm. Form: Square. Height: 84 mm. Dimension... More
Bulb: 12V21WK / P21W, 12V5WS / C5W. Colour: Yellow, white. Connection:...
€34,28 €28,33 €31,54 €26,06
You save 8%
Fender plastic 1315 x 420 mm, radius 720 mm, edge height 50 mm
For tyres 375/75-20. Quarter, without bracket. For agricultural vehicles. Width B (mm): 420 (+/- 10). Length L (mm): 1315 (+/- 10). Radius (mm): 7... More
For tyres 375/75-20. Quarter, without bracket. For agricultural vehic...
€41,09 €33,96 €37,80 €31,24
You save 8%
AKS-Dasis Evaporator 685 x 130 x 95 mm Fendt Farmer 307 - Favorit 926
AKS-Dasis
Equipment: Mesh length: 685 mm Mesh width: 130 mm Mesh depth: 95 mm Inlet Ø: 15 mm Outlet Ø: 12 mm More
Equipment: Mesh length: 685 mm Mesh width: 130 mm Mesh depth: 95 mm In...
€662,50 €547,52 €609,50 €503,72
You save 8%
HELLA Ballast 12 V, 396 mm Fendt 309 - 930
HELLA
Length (mm): 396 | Nominal voltage (V): 12 More
Length (mm): 396 | Nominal voltage (V): 12
€364,90 €301,57 €351,44 €290,45
You save 4%
Temperature sensor exhaust aftertreatment
€233,28 €192,79 €214,62 €177,37
You save 8%
Elring Cylinder head gasket 1,3 mm engine TCD 4,1 L04 Deutz-Fahr, Fendt
€236,49 €195,45 €217,57 €179,81
You save 8%
GRAMMER Bowden cable demperinstelling MSG 95, 95 A, 95 AL, 95 EL, 95 G
GRAMMER
Description: For damper adjustment | To fit: MSG 95, MSG 95 A, MSG 95 AL, MSG 95 AL / 722, MSG 95 EL, MSG 95 G | Version: Bowden cable More
Description: For damper adjustment | To fit: MSG 95, MSG 95 A, MSG 95 ...
€48,32 €39,93 €44,45 €36,74
You save 8%
Wabco Silencer 72 dB, 13 bar, Ø 69 mm, M22 x 1,5 Fendt 207 - 514
Wabco
Inlet connection: M22 x 1,5 | To fit as models: a.o. - SOLARIS: Urbino | Max. sound level (dB): 72 dB(A) bei 13 bar und 7m | Operating pressure max. (... More
Inlet connection: M22 x 1,5 | To fit as models: a.o. - SOLARIS: Urbino...
€24,86 €20,55
Scharmüller Adapter plate rail width 311 mm, hole pattern 140 x 80 mm, M16
Scharmüller
Hole (mm): M16 | Rail width (mm): 311 | Detent pin Ø (mm): 22 | Width (mm): 311 | Load capacity (kg): 2000 | Guide width (mm): 30 | D-value (kN): 83,... More
Hole (mm): M16 | Rail width (mm): 311 | Detent pin Ø (mm): 22 | Width...
€1.197,60 €989,75
Sauermann Cast iron cover set with bolts Ø 8,2 mm Fendt 207 - 822
€168,56 €139,31 €155,08 €128,16
You save 8%
Internal plate PTO shaft 3 mm, 80,5 mm, 140 mm Fendt
Version: thickness = 3 mm inner = 80,5 mm outer = 140 mm More
Version: thickness = 3 mm inner = 80,5 mm outer = 140 mm
€38,61 €31,91 €35,52 €29,36
You save 8%
External plate PTO shaft 3,3 mm, inner 98 mm, outer 154,8 mm Fendt
Version: Thickness: 3.3 mm Inner: 98 mm Outer: 154.8 mm More
Version: Thickness: 3.3 mm Inner: 98 mm Outer: 154.8 mm
€37,15 €30,70
GRAMMER Lumbar support mechanical lumbar support, 721, 722, 731, 732, 741
GRAMMER
Sitzoberteil: 721, 722, 731, 732, 741 | Version: Lumbar support | Description: Mechanical lumbar support More
Sitzoberteil: 721, 722, 731, 732, 741 | Version: Lumbar support | Desc...
€112,19 €92,72 €107,51 €88,85
You save 4%
GRAMMER Lever backrest adjustment left bovenzitgedeelte 721, 731, 741
GRAMMER
Sitzoberteil: 721, 731, 741 | Version: Lever | Description: Backrest adjustment suitable for 7 series seat upper part With left-hand side lever Includ... More
Sitzoberteil: 721, 731, 741 | Version: Lever | Description: Backrest a...
€45,87 €37,91 €42,20 €34,88
You save 8%
GRAMMER Switch zitverwarming seat cushion 721 - 742
GRAMMER
Sitzoberteil: 721, 722, 731, 732, 741, 742 | Version: Switch | Description: For heater More
Sitzoberteil: 721, 722, 731, 732, 741, 742 | Version: Switch | Descrip...
€37,64 €31,11
GRAMMER Operation height- and kantelverstelling seat cushion 722 - 742
GRAMMER
Description: Seat cushion height adjustment & seat cushion tilt adjustment control unit for 7 series seat upper part (not for Evolution) | Sitzobertei... More
Description: Seat cushion height adjustment & seat cushion tilt adjust...
€67,61 €55,88 €62,20 €51,41
You save 8%
HELLA Alternator 14 V / 150 A, without belt pulley, 7,33 kg
HELLA
Nominal voltage (V): 14 | Additional information: Without pulley | Nominal values (V / A): 14 / 150 | Charging current (A): 150 More
Nominal voltage (V): 14 | Additional information: Without pulley | Nom...
€749,79 €619,66 €577,70 €477,44
You save 23%
FEBI Hydraulics- / getriebeöl filters HD722, HF35320
€127,72 €105,55 €34,83 €28,79
You save 73%
FEBI Mirror 465 x 231 x 143 mm, rod Ø 18 - 22 mm Fendt
€145,68 €120,40 €121,86 €100,71
You save 16%
FEBI Alternator 14 V / 150 A, form B, flange 56,0 mm
FEBI
To fit as: Fendt, Hürlimann, Lamborghini, Same More
To fit as: Fendt, Hürlimann, Lamborghini, Same
€435,60 €360,00 €247,81 €204,80
You save 43%
MAHLE Gear reduction starter 3,2 kW, 11 teeth clockwise, 204,3 mm, Ø 89 mm
€548,46 €453,27 €328,50 €271,49
You save 40%
Showing 97 - 144 of 599

Fendt 313 Vario parts: a walk around the tractor

Before the Fendt 313 Vario heads out on the road with a trailer, it is worth a quick walk around. Are all the lights working, are the mirrors set right, are the air couplings properly connected? On that walk you come across exactly the parts on this page: more than 550 of them for the 313 Vario, from brands such as GRANIT, HELLA, Wabco, GRAMMER and Walterscheid.

Front to back

At the front and on the roof are the LED work lamps. Along the sides you have mirrors and grab handles, and at the step the rubber floor coverings and mats. The windscreen frame is held up by gas struts. Inside the cab there are push button switches, for example the green lighting switch. Under the bonnet the list covers alternators, temperature sensors and seals. Finally, at the rear, there are rear lights, connector heads for the trailer brake, and the pins, bushes and springs that hold the linkage and attachments together.

Air couplings in the right order

A dual-line brake system has a red connector head for the supply and a yellow one for the brake control. When hitching up, connect yellow first and then red. When unhitching, reverse it: red off first, then yellow. That way the trailer stays braked until it is fully connected to the tractor. After coupling, listen for air escaping at the heads. If you hear it, the seal in the head needs replacing. And when a rear light on the trailer goes out, the fault is often in the socket or the trailer plug rather than in the lamp itself, so check there first.

If the temperature gauge suddenly shows odd readings, the engine is not necessarily overheating. The temperature sensor or its plug is often to blame. Let the engine cool before you unscrew the sensor, catch the coolant that runs out and fit the new sensor with a fresh seal, then top up the coolant.

Which Typ number does your 313 Vario have?

The 313 Vario comes in several versions. The type plate shows the Typ number, and each number has a page with only the parts for that version:

If the plate cannot be read, the old part helps. Alternators, sensors and lamps usually carry a reference number that leads you to the right replacement.

The other tractors in the Fendt 300 line each have a page too: the Fendt 309 Vario, the Fendt 310 Vario, the Fendt 311 Vario, the Fendt 312 Vario and the Fendt 314 Vario. Useful when there is more than one Fendt in the yard. Parts for other models of this make are collected on our Fendt parts page.
