Looking for parts for your Fendt Farmer 310 (Typ 192) tractor? In this category, you'll find everything you need for the maintenance and repair of your vehicle.
The Fendt Farmer 310 (Typ 192) is the all-wheel drive variant of the Farmer 310, part of the Farmer 300 LS series produced from 1984 to 1993. The Typ 192 designation refers specifically to the LSA (Allrad/4WD) chassis. Three production variants were built: T 192.210 (2,550 units, 1984-1990), T 192.220 (400 units, 1990-1991), and T 192.221/T 192.222 (476 and 48 units, 1991-1993), bringing total LSA production to just over 3,400 units. A rear-wheel drive version (T 192.010) was also briefly available from 1984 to 1988, but only 109 examples were built before Fendt discontinued it. From 1988 onward, the 310 was exclusively available with four-wheel drive.
The 310 (Typ 192) runs a fully synchronized Fendt fine-step overdrive gearbox. The standard setup was a 21 forward/6 reverse unit; from 1991 a 21/21 reversing transmission became available. A super-creeper gearbox was offered as an optional extra. Top speed is 40 km/h.
The front axle up to 1990 was a ZF APL-345 with side driveshaft and Locomatik, offering a steering angle of 39 degrees and a pendulum angle of 12 degrees. From 1990 this was replaced by the ZF APL 700 F4 with an electro-hydraulic four-wheel drive and differential lock system. The rear axle is a portal-type design with bevel gear differential and multi-disc differential lock.
From introduction until 1990, the tractor used the MWM TD 226-4.2, a water-cooled four-cylinder four-stroke turbocharged diesel with direct injection, 4,154 cc displacement, and 92 hp. Maximum torque was 340 Nm at 1,500 rpm. In 1990, Fendt fitted the updated MWM TD 226 B-4 with a slightly larger 4,156 cc displacement, raising output to 100 hp and torque to 379 Nm at 1,500 rpm. Rated speed for both engines is 2,300 rpm.
Specs (from 1990, MWM TD 226 B-4):
The hydraulic pump delivers around 40 l/min at 180 bar up to 1991, then 74 l/min at 180 bar from 1991 onward. Rear lift capacity is 5,130 kp from 1990 (4,840 kp before that). An optional front hydraulic system, Cat. II, was available with a maximum lift capacity of 2,945 kp. Standard equipment includes one single-acting and one double-acting control valve, operated via a cross-switch.
Standard front tyres: 14.9 R 24 (later also 420/70 R 24). Standard rear tyres: 16.9 R 38 (later also 480/70 R 38).
We stock a wide range of parts for the Fendt Farmer 310 (Typ 192), including engine components, gasket sets, cooling parts, fuel system parts, hydraulics, brakes, cab parts, mudguards, and electrical components. Parts in our range come from brands including Granit, Kramp, Agco Parts, Bosch, Hella, Grammer, Cobo, Mahle, Mann-Filter, and Scharmüller.
