Fendt Favorit 824 (Typ 824) technical data

The Fendt Favorit 824 is a tractor from Fendt's Favorit 800 series. The tractor was built from 1993 to 2004 in Marktoberdorf, Germany, with a total of 2,094 units produced. This makes it by far the best-selling model in the Favorit 800 series.

The Favorit 824 delivered 230 hp (169 kW) via a MAN six-cylinder engine and was in its time the leading high-powered heavy tractor – as well as one of the most technologically advanced tractors in European agriculture during the 1990s.

Technical Specifications

Engine

• Make/type: MAN D0826LE523, 6-cylinder turbodiesel
• Displacement: 6.9 litres
• Bore × stroke: 108 mm × 125 mm
• Power: 230 hp / 169–171 kW
• Rated engine speed: 2,300 rpm
• Maximum torque: 947 Nm at 1,400 rpm
• Fuel tank: 370 litres

Transmission

• Type: 44/44 Turboshift synchromesh gearbox
• Gears: 44 forward / 44 reverse
• Drive: 4WD (four-wheel drive)
• Steering: Power steering

Hydraulics & PTO

• Hydraulic system: Open centre
• Hydraulic capacity: ±101 litres/minute
• Rear linkage: Category II, lifting capacity ±9,180 kg
• PTO: 750 / 1,000 rpm

Dimensions & Weights

• Length: 494 cm
• Width: 259 cm
• Height: 311 cm
• Wheelbase: 284 cm
• Ground clearance: 60.5 cm
• Turning radius: 540 cm (with steering brake), 590 cm (without)
• Unladen weight: ±7,800–8,250 kg
• Front tyre size: 480/70R34
• Rear tyre size: 620/70R42

Speeds

• The maximum speed is theoretically 50 km/h, but a safety limiter restricts road speed to 40 km/h. The minimum speed is 3.45 km/h as standard. With the optional creep gear, a minimum speed of 0.48 km/h is achievable, making the tractor highly suitable for heavy draft work.

Cab and Equipment

The Favorit 824 features an on-board computer (Bordrechner) and a comprehensive diagnostic system that monitors all tractor systems and stores fault codes – at the time an exceptional level of electronic integration for an agricultural tractor.

The in-cab noise level is just 72 dB. The cab is sprung at the rear with coil springs and hydraulically sprung at the front. From 1995, the front axle was also suspended.

Additional features:

• Hydropneumatic front axle suspension (from 1995)
• Electrohydraulic spool valve control
• Full ComfortStep cab specification
• Exhaust pipe on the right-hand cab pillar (from 1996)

The Fendt Favorit 824 is the successor to the Favorit 600 series and was succeeded by the Fendt 800 Vario with continuously variable Vario transmission.
