Fiat F 100 tractor parts & technical data

This page lists more than 200 replacement parts for the Fiat F 100 in the Winner F100 series, from trailer couplings to lighting and electrics.

218 parts found for Fiat F 100
Show:
GRAMMER Tractor seat Maximo Basic MSG85/721
GRAMMER
Suspension: Mechanical. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 480 mm. Joystick console: Optional. S... More
Suspension: Mechanical. Upholstery type: Fabric. Seat contact switch: ...
€1.362,65 €1.126,16 €1.303,64 €1.077,39
You save 4%
Sauermann Piton Fix rail 320 mm, locking pin Ø 30 mm, guide 20 mm, 3000 kg
Sauermann
Height adjustable, rotating bolt system to fit as System Sauermann. More
Height adjustable, rotating bolt system to fit as System Sauermann.
€1.736,14 €1.434,83 €1.647,25 €1.361,36
You save 5%
FEBI Engine oil filter Ø 107,67 mm, height 129,92 mm, thread 3/4"-16 UNF
€59,44 €49,12 €10,98 €9,07
You save 82%
Perkins Fuel filter outer-Ø 88 mm, inner-Ø 18 mm, height 72 mm
Perkins
Outer Ø: 88 mm. Inner Ø: 18 mm. Height: 72 mm. More
Outer Ø: 88 mm. Inner Ø: 18 mm. Height: 72 mm.
€20,09 €16,60
Walterscheid Drawbar manual rail width 330 mm, coupling pin 31 mm, 92 kN
Walterscheid
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 31 mm. Load capacity: 2000 kg. D-value: 92 kN. Colour: Black. Descriptio... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.104,81 €913,07 €873,47 €721,88
You save 21%
Walterscheid Adapter plate 335 mm rail, guide 30 mm, hole pattern 160 x 100 mm
Walterscheid
Rail width (mm): 335 | Assembly notes: The vehicle part support distance (from the centre of the coupling plate to the centre of the coupling point) m... More
Rail width (mm): 335 | Assembly notes: The vehicle part support distan...
€936,88 €774,28 €740,70 €612,15
You save 21%
Donaldson Maintenance switch air filter electric, 2 blade connections
Donaldson
Donaldson no.: X770062 | Version: Differential pressure switch 2 blade terminals | Type: Electrical More
Donaldson no.: X770062 | Version: Differential pressure switch 2 blade...
€35,42 €29,27 €32,59 €26,93
You save 8%
Repair set clutch cylinder Fiat, Ford, McCormick, New Holland
€51,39 €42,47 €47,28 €39,07
You save 8%
Walterscheid Ball hitch K80 330 / 25 / 32 mm, 2800 kg, 97,1 kN
Walterscheid
Quick height adjustment with rotation lock, load capacity up to 40 km/h 2800 kg, from 40 km/h 2,000 kg. More
Quick height adjustment with rotation lock, load capacity up to 40 km/...
€2.111,26 €1.744,84 €1.719,18 €1.420,81
You save 19%
Expansion valve airco 1/2 inch - 3/8 inch o-ring, 195 g
Connection thread: M | Connection thread E: # 6, 3/8"" O-ring | Equipment: O-ring | Connection thread A: # 8, 1/2"" O-ring | Weight (g): 195 More
Connection thread: M | Connection thread E: # 6, 3/8"" O-ring | Equipm...
€57,45 €47,48 €52,85 €43,68
You save 8%
Danfoss Orbitrol OSPC 160 ON Case IH, Fiat, Ford, New Holland
Danfoss
Type: OSPC 160 ON / 150N1282 More
Type: OSPC 160 ON / 150N1282
€1.119,22 €924,98 €1.029,68 €850,98
You save 8%
AKS-Dasis Condenser without dryer Case IH, Fiat, Ford, New Holland
AKS-Dasis
Weight (kg): 3 | Weight (g): 3000 | Supplementary set: without dryer More
Weight (kg): 3 | Weight (g): 3000 | Supplementary set: without dryer
€580,51 €479,76 €534,07 €441,38
You save 8%
Expansion valve 3/8 - 5/8 inch o-ring
Equipment: O-ring | Connection thread E: # 6, 3/8"" O-ring | Connection thread A: # 10, 5/8"" O-ring More
Equipment: O-ring | Connection thread E: # 6, 3/8"" O-ring | Connectio...
€48,74 €40,28 €44,84 €37,06
You save 8%
AKS-Dasis Thermostat airco Case IH, Fiat, Ford, Laverda
AKS-Dasis
Version: For air conditioning system More
Version: For air conditioning system
€92,69 €76,60 €85,27 €70,48
You save 8%
Cobo Lamp glass right
Cobo
Installation location: Right. Menke no.: 55041. More
Installation location: Right. Menke no.: 55041.
€18,81 €15,55
Cobo Flasher unit 12 V, 2+1+1 / 8 x 21 W, 6 connections, with holder
Cobo
Version: 12 V / 2 + 1 + 1 x 21 / 8 x 21 W, With bracket, With hazard warning light function. More
Version: 12 V / 2 + 1 + 1 x 21 / 8 x 21 W, With bracket, With hazard w...
€58,12 €48,03 €53,47 €44,19
You save 8%
Walterscheid Adapter plate rail width 330 mm, hole pattern 160 x 100 mm, M21
Walterscheid
Guide width (mm): 32 | Description: The coupling plate is a height-adjustable sliding plate that can only be operated in hitch supports with locking r... More
Guide width (mm): 32 | Description: The coupling plate is a height-adj...
€1.207,08 €997,59 €954,33 €788,70
You save 21%
MAHLE Air conditioning compressor 12 V, pulley Ø 132 mm, 2 grooves, V/TO
MAHLE
No. of grooves: 2 | Nominal voltage (V): 12 | Refrigerant: R 134a | Connection: V/TO | Suitable oil: PAG 46 | Pulley Ø (mm): 132 More
No. of grooves: 2 | Nominal voltage (V): 12 | Refrigerant: R 134a | Co...
€513,19 €424,12 €461,06 €381,04
You save 10%
Eaton PTO shaft end piece Case IH, Fiat, Ford, New Holland, Steyr
Eaton
Reference no.: 5185602 More
Reference no.: 5185602
€196,97 €162,79 €181,21 €149,76
You save 8%
Eaton Planetary gear transmission, 994 g
Eaton
Reference no.: 5145497 More
Reference no.: 5145497
€85,99 €71,07 €79,11 €65,38
You save 8%
Filter dryer Ø 62 mm, 203 mm, connection thread F/M 3/8 inch
Connection thread A: 3/8"" | Connection thread: F/M | Outer Ø (mm): 62 | Length (mm): 203 | Weight (g): 400 | Connection thread E: 3/8"" | Dimensions... More
Connection thread A: 3/8"" | Connection thread: F/M | Outer Ø (mm): 6...
€58,64 €48,46 €53,95 €44,59
You save 8%
SANDEN Air conditioning compressor 12 V, pulley Ø 119 mm, 2 grooves, 200 ccm oil
SANDEN
No. of grooves: 2 | Nominal voltage (V): 12 | Pulley Ø (mm): 119 | Fixing: EM | Suitable oil: SP 10 | Oil quantity (ccm): 200 | Refrigerant: R 134a More
No. of grooves: 2 | Nominal voltage (V): 12 | Pulley Ø (mm): 119 | Fi...
€732,23 €605,15 €673,65 €556,74
You save 8%
LUK Thrust bearing 65 x 115 x 30 mm Case IH, Fiat, Ford, New Holland
LUK
Dimensions (mm): 65 x 115 x 30 More
Dimensions (mm): 65 x 115 x 30
€409,98 €338,83 €377,18 €311,72
You save 8%
FEBI Thermostat Ø 54 mm, 79 °C Ford, Case IH, Fiat, Steyr, New Holland
FEBI
To fit as: New Holland TD 55D, 65D, 75D, 85D, 95D, TL 70, 80, 90, 100, TN 55, 65, 70, 75, 80, 90, 95, L 60, 65, 75, 85, 95 More
To fit as: New Holland TD 55D, 65D, 75D, 85D, 95D, TL 70, 80, 90, 100,...
€30,67 €25,35 €15,73 €13,00
You save 49%
Elring Cylinder head gasket 1,43 mm, Ø 100 mm Fiat 980, 1180, 100-90
€86,68 €71,64 €79,75 €65,91
You save 8%
Scharmüller Schroefkogeladapter K80 3000 kg, 118 kN, bore M16 / M20, black
Scharmüller
V-value (kN): 83 | Hole (mm): M16 / M20 | Version: Threaded ball adapter K80 | Description: Suitable for Scharmüller drawbar part no. 10.820.9270.0 |... More
V-value (kN): 83 | Hole (mm): M16 / M20 | Version: Threaded ball adapt...
€1.926,92 €1.592,50 €1.822,77 €1.506,42
You save 5%
Double gear transmission Case IH, Fiat, New Holland
€447,45 €369,79 €411,65 €340,21
You save 8%
LUK Clutch kit without release bearing Case IH, Fiat, Ford, New Holland
LUK
Contents: Pressure plate 458133021410, clutch plate 458333007211 | Supplementary set: Without release bearing More
Contents: Pressure plate 458133021410, clutch plate 458333007211 | Sup...
€657,87 €543,69 €605,24 €500,20
You save 8%
Thrust bearing single 65 x 115 x 30 mm Case IH, Fiat, Ford, New Holland
Dimensions (mm): 65 x 115 x 30 More
Dimensions (mm): 65 x 115 x 30
€126,14 €104,25 €116,05 €95,91
You save 8%
Starter motor 12V 3,0 kW, 9 teeth clockwise, 266,5 mm
€296,00 €244,63 €272,32 €225,06
You save 8%
Bush 14 teeth Fiat 90-90 - 110-90, F 100 - F 140, M 115 - M 160
€71,34 €58,96 €65,63 €54,24
You save 8%
PROBOSS Seat PROBOSS AS3510 air suspended, fabric, 510 mm, 12 V
PROBOSS
Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 510 mm. Joystick console: Optiona... More
Suspension: Air suspension. Upholstery type: Fabric. Seat contact swit...
€1.383,42 €1.143,32
Walterscheid Piton Fix rail width 335 mm, locking pin Ø 22 mm, 3000 kg, 89,3 kN
Walterscheid
Rail width: 335 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 3000 kg. D-value: 89.3 kN. Colour: Black. Description: This product is a ... More
Rail width: 335 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.852,29 €1.530,82 €1.464,43 €1.210,28
You save 21%
Ball joint taper 20 - 22,2 mm, 95 mm, M24 x 1,5
Taper (mm): 20 - 22.2. Length (mm): 95. Outer thread (mm): M24 x 1.5. More
Taper (mm): 20 - 22.2. Length (mm): 95. Outer thread (mm): M24 x 1.5.
€53,78 €44,45 €49,48 €40,89
You save 8%
Linkage steering valve series 90, 94 and Winner
can be used in 90, 94 and Winner More
can be used in 90, 94 and Winner
€136,38 €112,71 €125,47 €103,69
You save 8%
Clutch slave cylinder Ø 19,9 mm, mineral oil
Hole Ø (mm): 19.9 More
Hole Ø (mm): 19.9
€58,64 €48,46 €53,95 €44,59
You save 8%
CARLISLE External plate 1,5 mm, inner 99 mm, outer 152 mm
CARLISLE
Version: Thickness: 1.5 mm Inner: 99 mm Outer: 152 mm More
Version: Thickness: 1.5 mm Inner: 99 mm Outer: 152 mm
€35,28 €29,16 €32,46 €26,82
You save 8%
Aircon compressor 12 V, Ø 132 mm, 2 grooves, 135 ccm, connection A2
No. of grooves: 2 | Nominal voltage (V): 12 | Oil quantity (ccm): 135 | Pulley Ø (mm): 132 | Reference no.: QP7H15-7849 | Suitable oil: PAG 46 | Fixi... More
No. of grooves: 2 | Nominal voltage (V): 12 | Oil quantity (ccm): 135 ...
€485,74 €401,44 €446,88 €369,32
You save 8%
SANDEN Aircon compressor 12 V, pulley Ø 125 mm, 2 grooves
SANDEN
Fixing: EM | Suitable oil: SP 10 | Refrigerant: R 134a | Oil quantity (ccm): 185 | Nominal voltage (V): 12 | Pulley Ø (mm): 125 | No. of grooves: 2 More
Fixing: EM | Suitable oil: SP 10 | Refrigerant: R 134a | Oil quantity ...
€710,18 €586,93 €653,37 €539,97
You save 8%
Elring Cylinder head gasket 1,43 mm, Ø 105,5 mm Fiat 980 - 1380
€95,83 €79,20 €88,16 €72,86
You save 8%
FEBI Fuel filter WK842
€19,60 €16,20 €8,47 €7,00
You save 57%
MAHLE Starter motor 12 V, 4,2 kW, 9 teeth, flange distance 30,0 mm
€656,78 €542,79 €393,37 €325,10
You save 40%
GRAMMER Tractor seat Maximo Professional MSG95AL/731 air suspended
GRAMMER
Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 530 mm. Joystick console: Optiona... More
Suspension: Air suspension. Upholstery type: Fabric. Seat contact swit...
€3.917,46 €3.237,57
Sauermann Drawbar ball 80, rail width 320 mm, guide 19 mm, 3000 kg
Sauermann
Rail width: 320 mm. Detent pin Ø: 30,5 mm. Guide width: 19 mm. Load capacity: 3000 kg. Colour: Black. D-value: 92 kN. Version: Pivot bolt. Lock: ball... More
Rail width: 320 mm. Detent pin Ø: 30,5 mm. Guide width: 19 mm. Load c...
€1.594,08 €1.317,42 €1.516,55 €1.253,35
You save 5%
Single clutch 330 TBVP, flywheel 34 mm Fiat, Ford, New Holland
Flywheel dimension (mm): 34 (tief) | Additional information: Made in Germany More
Flywheel dimension (mm): 34 (tief) | Additional information: Made in G...
€293,16 €242,28 €269,71 €222,90
You save 8%
Repair set clutch cylinder Fiat, Ford
€43,03 €35,56 €39,59 €32,72
You save 8%
Aircon compressor 12 V, Ø 134 mm, 2 grooves, 135 ccm
Suitable oil: PAG 46 | Pulley Ø (mm): 134 | No. of grooves: 2 | Oil quantity (ccm): 135 | Nominal voltage (V): 12 | Refrigerant: R 134a | Fixing: EM More
Suitable oil: PAG 46 | Pulley Ø (mm): 134 | No. of grooves: 2 | Oil q...
€514,14 €424,91 €473,01 €390,92
You save 8%
Showing 1 - 48 of 218

Fiat F 100 parts for servicing and repairs

The Fiat F 100 from the Winner range is a tractor that plenty of owners still maintain in their own shed. This page lists more than 200 parts that fit it, from GRANIT, Cobo, Walterscheid, MAHLE and LUK, and covers the jobs that come round year after year.

Service items and engine

An air filter is on offer together with its matching inner filter. One rule worth sticking to: never clean the inner filter with compressed air, replace it instead. It is the last line of defence for the engine, and a hairline crack caused by blowing it out is impossible to spot. The outer element can be tapped clean between changes, but it does wear out eventually.

If the engine runs too cold or too hot, the thermostat is the obvious suspect, and you will find it here. Gaskets, for example for the rear engine cover, O-rings for the pistons and a starter motor complete the engine side of the F 100.

Lift linkage leaks

Oil dripping below the linkage often points to a worn seal on the lift arm shaft. There are seals, sealing rings and complete seal kits for that job, along with bushes. Replace the seals on both sides at once, because the second one usually follows soon after, and check the bushes for play while everything is apart.

Cab, steering and hitch

When the rear window keeps dropping shut, the gas strut has lost its force. Gas struts for this window are available, as are an aircon compressor and push button switches for the dash. Play in the steering is sorted with new ball joints, and at the back there are drawbars and the Piton Fix system.

Finding the part that fits

Start with the type plate, as the tractors in the Winner range look alike from the outside. Next, check the number on the old part. Filters, thermostats and gaskets often carry a reference number you can compare with the product page. If in doubt, lay the old part beside the new one and compare the shape.

If you also run a heavier model from the same range, use the pages for the Fiat F 115 and the Fiat F 140. Each of those types has its own overview, so there is no guessing about fit. Looking after another Fiat as well? Try Fiat parts.
