Fiat 566 tractor parts & technical data

What fits a Fiat 566? You can see it at a glance here: more than 120 parts, including lighting and brake and transmission parts for this tractor.

124 parts found for Fiat 566
Show:
Ball joint 80 mm, M14 x 1,5, M20 x 1, taper 16,2 - 18,3 mm
Ball joint 80 mm, M14 x 1,5, M20 x 1, taper 16,2 - 18,3 mm
A: 80 mm. C: M14 x 1,5 mm. D: M20 x 1 mm. E: 16,2 mm. F: 18,3 mm. Taper: 16,2 - ...
€38,53 €31,84

Brake mechanism foot brake Fiat, Case IH, New Holland
8%
Brake mechanism foot brake Fiat, Case IH, New Holland
€209,04 €172,76 €192,32 €158,94

Starter ring gear Ø 335/293 mm, 110 teeth
8%
Starter ring gear Ø 335/293 mm, 110 teeth
Version: Ø 335/293 mm, 110 teeth.
€54,23 €44,82 €49,89 €41,23

Gear lever knob thread M14 x 1,5 Ford, Fiat
Gear lever knob thread M14 x 1,5 Ford, Fiat
Version: Thread M14 x 1,5.
€6,86 €5,67

Radiator hose, bottom inner-Ø 35 mm, length 80 mm
Radiator hose, bottom inner-Ø 35 mm, length 80 mm
Inner Ø: 35 mm. Length: 80 mm.
€5,05 €4,17

Cobo Starter switch with key, 12 V, blade terminal, parking light, Ø 40 mm
8%
Cobo
Starter switch with key, 12 V, blade terminal, parking light, Ø 40 mm
Version: 12 V, with blade terminal, Function:, P: parking light, 0: off, 1: cons...
€64,26 €53,11 €59,12 €48,86

Switch lighting and horn, 6 blade connections
8%
Switch lighting and horn, 6 blade connections
Version: Functions: lights, horn with 6 blade terminals.
€38,51 €31,83 €35,43 €29,28

Ball joint taper 16,2 - 18,3 mm, 640 mm, M14 x 1,5, 20 mm
8%
Ball joint taper 16,2 - 18,3 mm, 640 mm, M14 x 1,5, 20 mm
A: 640 mm. C: M14 x 1,5 mm. D: 20 mm. E: 16,2 mm. F: 18,3 mm. Taper: 16,2 - 18,3...
€45,71 €37,78 €42,05 €34,75

Thermostat Ø 54 mm, 79 °C Ford, Case IH, Fiat, Steyr, New Holland
Thermostat Ø 54 mm, 79 °C Ford, Case IH, Fiat, Steyr, New Holland
Ø: 54 mm. Temperature: 79 °C.
€24,35 €20,12

Bolt set 3de steering valve M10 x 200 Fiat, New Holland
8%
Bolt set 3de steering valve M10 x 200 Fiat, New Holland
Technical data: M10 x 200.
€53,09 €43,88 €48,84 €40,37

Steering valve ew/dw with float position 220 bar, 70 l/min
8%
Steering valve ew/dw with float position 220 bar, 70 l/min
Technical data: Max. operating pressure: 220 bar, Nominal flow rate: max. 70 l/m...
€940,41 €777,20 €865,18 €715,02

Headlight left / right 12/24 V, 45/40 W R2, 192 x 133 x 126 mm, built-in
8%
Headlight left / right 12/24 V, 45/40 W R2, 192 x 133 x 126 mm, built-in
Bulb: 12V45/40WAS / R2, or 12V45/40W halogen / R2, 24V55WAS / R2. Material: Glas...
€72,73 €60,11 €66,91 €55,30

Cobo Rear light right 169 x 62 x 90 mm, 12 V, hole spacing 132 mm
8%
Cobo
Rear light right 169 x 62 x 90 mm, 12 V, hole spacing 132 mm
Bulb: 12V21WK / P21W, 12V5WK / R5W. Connection: Plug. Width: 169 mm. Form: Recta...
€46,15 €38,14 €42,46 €35,09

Cobo Rear light left 169 x 62 x 90 mm, 12 V, hole spacing 132 mm
8%
Cobo
Rear light left 169 x 62 x 90 mm, 12 V, hole spacing 132 mm
Bulb: 12V21WK / P21W, 12V5WK / R5W. Connection: Plug. Width: 169 mm. Form: Recta...
€46,15 €38,14 €42,46 €35,09

Track rod without four-wheel drive A 1165 mm, B M20 x 1,5, E 34 mm
8%
Track rod without four-wheel drive A 1165 mm, B M20 x 1,5, E 34 mm
A: 1070 - 1300 mm. B: M20 x 1,5 mm. C: 16 - 18 mm. G: . D: M14 x 1,5 mm. E: 34 m...
€287,29 €237,43 €264,31 €218,44

Radiator hose, top inner-Ø 44 mm New Holland, Case IH, Fiat
Radiator hose, top inner-Ø 44 mm New Holland, Case IH, Fiat
Inner Ø: 44 mm.
€20,03 €16,55

Crankshaft 3-cylinder Fiat 446-580
8%
Crankshaft 3-cylinder Fiat 446-580
Notes: Please follow the installation instructions. Then fill in the test report...
€942,14 €778,63 €866,77 €716,34

Crankshaft seal Ø 42 x 65 x 12 mm Case IH, Fiat, Steyr, New Holland
Crankshaft seal Ø 42 x 65 x 12 mm Case IH, Fiat, Steyr, New Holland
Outer Ø: 65 mm. Width: 12 mm. Inner Ø: 42 mm.
€5,24 €4,33

Tube vertical 780 mm, inner-Ø 46,5 mm, outer-Ø 48 mm Ford, Fiat
8%
Tube vertical 780 mm, inner-Ø 46,5 mm, outer-Ø 48 mm Ford, Fiat
Version: Length: 780 mm, Inner Ø: 46.5 mm, Outer Ø: 48 mm. Outer Ø: 48 mm. Inner...
€34,33 €28,37 €31,58 €26,10

Injection nozzle Fiat 466-766, 570, 670, 480-1380, 540, 640, 1000
8%
Injection nozzle Fiat 466-766, 570, 670, 480-1380, 540, 640, 1000
Type formula: DLL140S64F, DLLA140S662, 0433271325. Bosch no.: 2580433271325. Men...
€50,25 €41,53 €46,23 €38,21

Bolt set 2de steering valve M10 x 160 Fiat, Ford, New Holland
8%
Bolt set 2de steering valve M10 x 160 Fiat, Ford, New Holland
Technical data: M10 x 160. Description: For 2nd Control unit.
€36,29 €29,99 €33,39 €27,59

Lever with bolt and lock steering valve Fiat, Ford, New Holland
8%
Lever with bolt and lock steering valve Fiat, Ford, New Holland
€88,99 €73,55 €81,87 €67,66

Spacer 85 x 89 x 6 mm Fiat series 66-94
Spacer 85 x 89 x 6 mm Fiat series 66-94
Dimensions: 85 x 89 x 6 mm.
€35,16 €29,06

Lifting shaft sealing ring 55 x 70 x 8/8,5 mm Ford, Fiat, New Holland
Lifting shaft sealing ring 55 x 70 x 8/8,5 mm Ford, Fiat, New Holland
Dimensions: 55 x 70 x 8/8.5 mm.
€3,76 €3,11

Temperature sensor thread M22 x 1,5, 25-100 °C
Temperature sensor thread M22 x 1,5, 25-100 °C
Version: Thread: M22 x 1.5. Temperature: 25 - 100 °C.
€19,71 €16,29

Cobo Lamp glass left
Cobo
Lamp glass left
Installation location: Left.
€19,43 €16,05

Cobo Indicator/position light 169 x 62 x 90 mm, P21W, R5W right
8%
Cobo
Indicator/position light 169 x 62 x 90 mm, P21W, R5W right
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 169 mm. Form: ...
€50,01 €41,33 €46,01 €38,02

Clamp Ø 46 mm Fiat 466-780
Clamp Ø 46 mm Fiat 466-780
To fit as: Fiat 446, 466, 566, 666, 766, 570, 670, 580, 680, 780, 55-46, 60-46, ...
€17,00 €14,05

Optibelt V-belt Case IH, Ford, David Brown, New Holland, Fiat
Optibelt
V-belt Case IH, Ford, David Brown, New Holland, Fiat
To fit as: Case IH
€24,08 €19,90

MANN-FILTER Hydraulics- / getriebeöl filters W1150/2, HF7569
MANN-FILTER
Hydraulics- / getriebeöl filters W1150/2, HF7569
€31,99 €26,44

LUK Pilot bearing 17 x 47 x 14 mm
LUK
Pilot bearing 17 x 47 x 14 mm
Dimensions: 17 x 47 x 14 mm. Menke no.: 167836.
€38,59 €31,89

Thermostat gasket Fiat 400-1580
Thermostat gasket Fiat 400-1580
€2,86 €2,37

Seal oil pump Ford, Fiat
Seal oil pump Ford, Fiat
€6,79 €5,61

Showing 49 - 96 of 124

Fiat 566 parts for the clutch, cooling and lights

Most Fiat 566 owners come to this page with one of three jobs in mind: a clutch that slips, an engine that runs too hot or too cold, or a light that no longer works. All three are covered by the more than 120 replacement parts that fit the 566, supplied by GRANIT and by brands such as LUK, SACHS, FEBI and Cobo.

Clutch

For the driving clutch there are complete clutch kits, double clutches, clutch plates and thrust bearings. A kit contains the parts that wear together and finishes the job in one go. If you replace parts separately, always include the thrust bearing. Centre the clutch plate with an alignment tool before bolting up the pressure plate, then tighten its bolts in a cross pattern over several passes so it pulls down evenly and the clutch does not judder.

Cooling and engine

For the cooling system there are thermostats, water pump gaskets and V-belts. The engine is covered by crankshaft seals, spacers, bolt sets and engine oil filters for routine servicing, and the charging side by alternators. When a thermostat is replaced, fit a new gasket at the same time rather than reusing the old one.

Exhaust and lights

For the exhaust there are pipes, including a curved vertical pipe with an enamelled finish. For the lighting you will find headlights and separate lamp glasses, so a cracked glass does not mean a whole new lamp.

Oil changes and the V-belt

Every oil change calls for a new engine oil filter. Smear the rubber ring of the new filter with a little clean oil and screw it on by hand, without a filter wrench. Run the engine briefly afterwards and check for leaks.

If the alternator is not charging or you hear a squeal when you open the throttle, look at the V-belt. A belt with glazed flanks, cracks or too much slack will slip and no longer drive the alternator and water pump properly. Retension a new belt after the first few hours of work, as it stretches slightly at first.

Making sure it fits

Check the type plate, then look at the part you are replacing. Clutch plates, thrust bearings and gaskets often carry a reference number you can compare with the new part, and with a clutch plate the diameter and spline count matter too.

Within the Fiat range, the 566 sits in the 66 series alongside several close relatives. The Fiat 60-66, Fiat 65-66 and Fiat 70-66 each have their own page showing what fits those tractors. For other Fiat models, start at Fiat parts.
