Massey Ferguson 250 tractor parts & technical data

The Massey Ferguson 250 from the 200 series deserves parts that fit. Choose from more than 140 items, such as lighting, electrics, brakes and transmission.

146 parts found for Massey Ferguson 250
Show:
Spindle three-point 3/4 inch thread Massey Ferguson, Ford
Dimensions: 3/4" thread mm. More
Dimensions: 3/4" thread mm.
€28,55 €23,60
Clevis 3/4 inch thread Massey Ferguson 135-550
Dimensions: 3/4" thread mm. More
Dimensions: 3/4" thread mm.
€55,11 €45,55 €50,70 €41,90
You save 8%
HELLA Oil pressure switch engine open function (NO) 1/8 inch NPT, 0,4 - 0,6 bar
HELLA
Version: Thread: 1/8" NPT, Switching pressure: 0.4 - 0.6 bar, Blade terminal 6.3 mm, AF: 24 mm, Colour: black. Pressure range: 0,4 - 0,6 bar. Thread: ... More
Version: Thread: 1/8" NPT, Switching pressure: 0.4 - 0.6 bar, Blade te...
€11,24 €9,29
Headlight insert left 12V45 / 40WAS / R2
Bulb: 12V45/40WAS / R2, or 12V45/40W halogen / R2. To fit: Types:, Massey Ferguson, 135, 148, 165, 168, 175, 178, 185, 188, 230, 240, 245, 250, 265, 2... More
Bulb: 12V45/40WAS / R2, or 12V45/40W halogen / R2. To fit: Types:, Mas...
€52,08 €43,04 €47,91 €39,60
You save 8%
Indicator/position light rectangular right yellow, white P21W, R5W
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Form: Rectangular. Installation location: Right. Type: Bulb. Light function: With indicator... More
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Form: Recta...
€57,46 €47,49 €52,86 €43,69
You save 8%
Indicator/position light rectangular P21W, R5W left
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Form: Rectangular. Installation location: Left. Type: Bulb. Light function: With indicator ... More
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Form: Recta...
€57,46 €47,49 €52,86 €43,69
You save 8%
Gaiter inner-Ø upper 12 mm Massey Ferguson
To fit as: Massey Ferguson 35, 65, 135, 140, 145, 148, 152, 155, 158, 165, 168, 175, 178, 185, 188, 230, 235, 240, 245, 250, 253, 255, 260, 265, 275, ... More
To fit as: Massey Ferguson 35, 65, 135, 140, 145, 148, 152, 155, 158, ...
€1,91 €1,58
Brake disc Ø 224 mm, 27 teeth, thickness 5 mm, 50 km/h, for ceramic
Notes: Please check the rear axle version and take this into account when ordering.. More
Notes: Please check the rear axle version and take this into account w...
€40,13 €33,16
Needle bearing transmission input Ø 49,3 x 41,2 x 16,1 mm
Dimensions: 41,2 x 49,3 x 16,1 mm. Outer Ø: 49,3 mm. Inner Ø: 41,2 mm. Height 1: 16.1 mm. More
Dimensions: 41,2 x 49,3 x 16,1 mm. Outer Ø: 49,3 mm. Inner Ø: 41,2 m...
€10,76 €8,89
Gear lever knob Ø 29 mm, thread 7/16" UNF Massey Ferguson
Version: Ø 29 mm, thread 7/16" UNF. More
Version: Ø 29 mm, thread 7/16" UNF.
€10,98 €9,07
KS Piston set complete Ø 101,05 mm, piston pin 34,925 x 84,2 mm
KS
Dimensions: 4 rings, Ø 101.05 mm, gudgeon pin Ø 34.925 x 84.2 mm, combustion chamber Ø 61 mm, combustion chamber depth 20.5 mm, cast iron cylinder ... More
Dimensions: 4 rings, Ø 101.05 mm, gudgeon pin Ø 34.925 x 84.2 mm, co...
€263,13 €217,46 €242,08 €200,07
You save 8%
Oil drain valve thread 3/4 inch - 16UNF Massey Ferguson
Thread: 3/4" - 16UNF. More
Thread: 3/4" - 16UNF.
€14,11 €11,66
Oil pump Perkins engine 3.144, 3.152
€74,50 €61,57 €68,54 €56,64
You save 8%
Bolt set additional control unit 4x M8 x 110 Massey Ferguson
Technical data: 4x M8 x 110. More
Technical data: 4x M8 x 110.
€38,51 €31,83
Bearing three-point parts 19,4 x 41,6 x 12,7 mm Massey Ferguson, Ford
Dimensions: 19.4 x 41.6 x 12.7 mm. Outer Ø: 41,28 mm. Inner Ø: 19,3 mm. Height 1: 12.7 mm. More
Dimensions: 19.4 x 41.6 x 12.7 mm. Outer Ø: 41,28 mm. Inner Ø: 19,3 ...
€8,29 €6,85
Sealing washer Ø 44,4 mm Ford, Massey Ferguson
Dimensions: Ø: 44.4 mm. More
Dimensions: Ø: 44.4 mm.
€1,55 €1,28
Temperature sensor 12 volt, thread 5/8 BSP
Version: Thread: 5/8" BSP. Thread: 5/8 BSP. More
Version: Thread: 5/8" BSP. Thread: 5/8 BSP.
€15,96 €13,19
Tractormeter Ø 85 mm
Version: Ø 85 mm. More
Version: Ø 85 mm.
€43,75 €36,16 €40,25 €33,26
You save 8%
Cobo Lamp glass right, left
Cobo
Installation location: Right, left. More
Installation location: Right, left.
€16,41 €13,56
Seal input shaft reversing clutch Ø 28,5 x 38,1 x 6,35 mm
Dimensions: 28,5 x 38,1 x 6,35 mm. Outer Ø: 38.1 mm. Inner Ø: 28,5 mm. Height 1: 6.35 mm. More
Dimensions: 28,5 x 38,1 x 6,35 mm. Outer Ø: 38.1 mm. Inner Ø: 28,5 m...
€4,33 €3,57
VICTOR REINZ Crankshaft seal rear Ø 133,3 x 158,7 x 12,7 mm
Crankshaft seal rear Ø 133,5 x 159 x 11 mm
Outer Ø: 159 mm. Width: 11 mm. Inner Ø: 133,5 mm. More
Outer Ø: 159 mm. Width: 11 mm. Inner Ø: 133,5 mm.
€23,70 €19,59
Pin for cross top 19 x 85 mm Massey Ferguson
Dimensions: 19 x 85 mm. More
Dimensions: 19 x 85 mm.
€9,39 €7,76
Start safety switch open function (NO), 3/4" UNF
Version: Break contact, Thread: 3/4" UNF, 2 blade terminals. More
Version: Break contact, Thread: 3/4" UNF, 2 blade terminals.
€26,44 €21,85
Contact switch clutch M14 x 1,5, blade connection
Version: Thread M14 x 1.5, Mechanical with blade terminal connection. More
Version: Thread M14 x 1.5, Mechanical with blade terminal connection.
€93,36 €77,16 €85,89 €70,98
You save 8%
Showing 97 - 144 of 146

Massey Ferguson 250 parts

On plenty of farms a Massey Ferguson 250 still earns its keep, doing yard work and lighter field jobs. To keep it running there are more than 140 replacement tractor parts that fit it, from GRANIT, Eaton, VICTOR REINZ, KS and LUK.

Cold starts and the engine

If your 250 struggles on a frosty morning, check the flame glow plug first. It only works when fuel reaches it, so inspect the feed and the sealing rings on the fuel line for leaks or air. For the engine itself there are complete pistons, piston ring sets and gaskets such as the one for the rear cover. Before ordering rings, find out which cylinder liners your engine has. Some ring sets are made only for cast iron liners and should not go into anything else.

Clutch, linkage and front axle

  • clutch plates for the driving clutch
  • seals for the lift arm shaft
  • pins for the top link cross and balls for the lower links
  • thrust bearings for the front axle
  • rubber buffers and an oil pressure switch

Lights for road work

There are rear lights, indicator and position lights, and headlight inserts. Once a lens cracks, moisture gets in, the reflector dulls and the beam fades. Fitting a fresh insert is usually quicker than trying to restore the old one.

Oil pressure and front axle

If the oil pressure light comes on at hot idle, do not assume the worst straight away. Fit a gauge in place of the switch and measure the real pressure first. If that reads fine, a new oil pressure switch is often all it needs. When the 250 steers heavily, or creaks as you turn the wheels with the front end jacked up, the front axle thrust bearing is the first suspect. A fresh bearing packed with grease makes the steering light again.

Getting the size right

The 250 is part of the Massey Ferguson 200 series. The serial number on the type plate helps narrow things down, but the part number on the old component, a seal or gasket for example, is the surest lead. Type it into the shop search and the right replacement appears. With a clutch plate, count the hub splines and check the diameter before you order.

Other models in the 200 series have their own pages too, so if there is more than one on the yard, order for each tractor from its own page:

The full list for the brand is at Massey Ferguson parts.
