Massey Ferguson 7618 tractor parts & technical data

Working on a Massey Ferguson 7618? This page holds more than 300 parts that fit, including trailer couplings, electrics and lighting.

330 parts found for Massey Ferguson 7618
Show:
Rear axle shaft seal outer Ø 120 x 155 x 16 mm Fendt, Massey Ferguson
Material: NBR (nitrile butadiene rubber). Inner Ø d1: 120 mm. Height 1: 16 mm. More
Material: NBR (nitrile butadiene rubber). Inner Ø d1: 120 mm. Height ...
€29,44 €24,33
ROCKINGER Drawbar KS80 rail 336 mm, pin Ø 22 mm, 4000 kg, black
ROCKINGER
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 4000 kg. D-value: 100 kN. Colour: Black. Lock: KS80. Menke no.: 67134. More
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.732,20 €1.431,57
AdBlue supply unit Fendt, Massey Ferguson, SAME, Lamborghini
Description: AdBlue supply units ensure even metering of AdBlue depending on the load on the common rail engine. It is important that only filtered ur... More
Description: AdBlue supply units ensure even metering of AdBlue depend...
€1.521,13 €1.257,13 €1.399,44 €1.156,56
You save 8%
AdBlue-filter Fendt, John Deere, Massey Ferguson
Description: for AdBlue supply unit. MANN no.: U5001KIT. Donaldson no.: P956170. Fleetguard no.: UF101. Hifi no.: SD70380. Hengst no.: E103UD295. More
Description: for AdBlue supply unit. MANN no.: U5001KIT. Donaldson no....
€59,17 €48,90 €54,44 €44,99
You save 8%
Filler cap for expansion tank
Version: For expansion tank. More
Version: For expansion tank.
€51,57 €42,62 €47,44 €39,21
You save 8%
Tensioning pulley Ø 74 / 46,3 mm, PK12
€46,78 €38,66 €43,04 €35,57
You save 8%
Belt tensioner Ø 75 mm, width 46,5 mm Fendt, Massey Ferguson
Outer Ø: 75 mm. Width: 46,5 mm. More
Outer Ø: 75 mm. Width: 46,5 mm.
€135,96 €112,36 €125,08 €103,37
You save 8%
O-ring sump Ø 50 x 5,6 mm Massey Ferguson 8170-8280
€4,98 €4,11
Cylinder head gasket engine Sisu
€82,88 €68,50 €76,25 €63,02
You save 8%
Cover fender
€18,94 €15,65
Gas strut roof window 300 N, 215 mm, stroke 70 mm Massey Ferguson
suitable for: Dachluke. Newtons: 300. A: 215 mm. B: 110 mm. C: 6 mm. D: 8 mm. Form: 8. d1: 8 mm. d2: 18 mm. Stroke: 70 mm. To fit: Roof hatch. More
suitable for: Dachluke. Newtons: 300. A: 215 mm. B: 110 mm. C: 6 mm. D...
€72,72 €60,10 €66,90 €55,29
You save 8%
Cam Massey Ferguson series 3000-6400
€181,07 €149,64 €166,58 €137,67
You save 8%
Lift cylinder front power lift Massey Ferguson series 5400-7600
€902,80 €746,12 €830,58 €686,43
You save 8%
Top link cat. 2, 495 - 710 mm, M30 x 3,5, threaded spindle / threaded spindle
I: M30 x 3,5 mm. A cat.: 2 / 25,4. B cat.: 2 / 25,4. C: 360 mm. D: 495 / 710 mm. E: 80 mm. F: 80 mm. G: 51 mm. H: 51 mm. Type: Ball joint/ball joint. ... More
I: M30 x 3,5 mm. A cat.: 2 / 25,4. B cat.: 2 / 25,4. C: 360 mm. D: 495...
€304,32 €251,50 €279,97 €231,38
You save 8%
Lock pin adjuster 22 x 97,5 mm Massey Ferguson
Dimensions: 22 x 97.5 mm. More
Dimensions: 22 x 97.5 mm.
€45,06 €37,24
Pin linkage Massey Ferguson 5425-7618
€55,37 €45,76 €50,94 €42,10
You save 8%
Pin three-point parts Massey Ferguson 3050-3125, 6110-6290
€34,43 €28,45 €31,68 €26,18
You save 8%
Mirror 195 x 143 mm, unheated, rod-Ø 10 - 22 mm
Dimensions: 195 x 143 mm. Height: 195 mm. Width: 143 mm. Version: Unheated. Rod Ø: 10 - 22 mm. More
Dimensions: 195 x 143 mm. Height: 195 mm. Width: 143 mm. Version: Unhe...
€48,90 €40,41 €44,99 €37,18
You save 8%
Pivot fender left Massey Ferguson 5460-8732
€459,22 €379,52 €422,48 €349,16
You save 8%
Spring right fender Fendt, Massey Ferguson
Version: Suitable for Fendt pivoting mudguards. More
Version: Suitable for Fendt pivoting mudguards.
€37,99 €31,39
Scharmüller Drawbar K80 rail 330 mm, pin Ø 20 mm, 3000 kg, black
Scharmüller
Rail width: 330 mm. Detent pin Ø: 20 mm. Guide width: 30 mm. Load capacity: 3000 kg. D-value: 89,3 kN. Plate height: 150 mm. Colour: Black. Overhang:... More
Rail width: 330 mm. Detent pin Ø: 20 mm. Guide width: 30 mm. Load cap...
€1.349,76 €1.115,50 €1.186,11 €980,26
You save 12%
Scharmüller Drawbar inner part 311 mm, coupling pin 38 mm, 2500 kg
Scharmüller
Rail width: 311 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecting pin: 38 mm. Load capacity: 2500 kg. D-value: 89,3 kN. Colour: AGCO grey. Desc... More
Rail width: 311 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecti...
€1.211,09 €1.000,90 €1.114,20 €920,83
You save 8%
Scharmüller Drawbar JSV ball 50 rail 325 mm, pin Ø 25 mm, 250 kg, black
Scharmüller
Rail width: 325 mm. Guide width: 26 mm. Detent pin Ø: 25 mm. Load capacity: 250 kg. D-value: 31 kN. Overhang: 180 mm. Plate height: 133 mm. Hole: M20... More
Rail width: 325 mm. Guide width: 26 mm. Detent pin Ø: 25 mm. Load cap...
€1.123,39 €928,42 €1.033,52 €854,15
You save 8%
Scharmüller Forced steering inner part left Ball 80 to K50 250 mm, 2 ton
Scharmüller
Assembly notes: Anticlockwise. Steering power: 2 t. Lock: K50. Description: Approved for steering forces up to 20 kN (2 t). Load capacity: 2 t. Load c... More
Assembly notes: Anticlockwise. Steering power: 2 t. Lock: K50. Descrip...
€481,06 €397,57 €453,50 €374,79
You save 6%
Knob operating switch heating
Version: Operating switch for heater. More
Version: Operating switch for heater.
€27,51 €22,74
Rotary switch heating and air conditioning, 5 plug connections
Version: Without knob, 5 plug connections. More
Version: Without knob, 5 plug connections.
€65,49 €54,13
HELLA Work lamp flood beam H3 55 W, 160 x 100 x 78 mm, 12 / 24 V, upright
HELLA
Bulb: H3. Bulbs included: Yes. Light function: Close-range illumination. Installation location: Universal. Dimensions W x H x D: 160 x 100 x 78 mm. Mo... More
Bulb: H3. Bulbs included: Yes. Light function: Close-range illuminatio...
€71,84 €59,37 €69,19 €57,18
You save 4%
Micro relays changeover contact 12 V / 15 - 25 A, 5-pin, without bracket
Version: 12 V / 15 - 25 A, Without bracket, 5-pin, blade terminal. More
Version: 12 V / 15 - 25 A, Without bracket, 5-pin, blade terminal.
€7,75 €6,41
HELLA Multifunction relay changeover contact 12 V, 30 - 40 A, 5-pin
HELLA
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 mm, With parallel resistor for suppressing inductive interference voltage peaks.... More
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 ...
€16,58 €13,70
Sensor transmission speed inductive, 135 mm, plug connection
Version: Inductive sensor (transmission speed), length: 135 mm, Connection cable with plug connection. More
Version: Inductive sensor (transmission speed), length: 135 mm, Connec...
€71,97 €59,48 €66,21 €54,72
You save 8%
Temperature sensor air conditioning
Version: Air conditioning system. More
Version: Air conditioning system.
€25,10 €20,74
Potentiometer for accelerator and clutch pedal
Version: For accelerator and clutch pedal. More
Version: For accelerator and clutch pedal.
€179,84 €148,63 €165,45 €136,74
You save 8%
Cardan shaft bearing Massey Ferguson 5460-7615
€187,00 €154,55 €172,04 €142,18
You save 8%
Shaft sealing ring 95 x 110 x 10 mm Fendt, Massey Ferguson
Version: 95 x 110 x 10 mm. More
Version: 95 x 110 x 10 mm.
€40,33 €33,33
Intermediate disc hand brake 5 mm thick Massey Ferguson 6460-6499
PTO shaft end piece 1 3/8 inch, 6 splines, 286,5 mm, 540 rpm
Version: 1 3/8", 6 splines, 540 rpm. Length: 286,5 mm. More
Version: 1 3/8", 6 splines, 540 rpm. Length: 286,5 mm.
€245,30 €202,73 €225,68 €186,51
You save 8%
Retaining ring PTO shaft end piece Massey Ferguson, Valtra
€155,63 €128,62 €143,18 €118,33
You save 8%
PTO shaft end piece 1 3/8 inch, 21 splines Fendt, Valtra-Valmet
Version: 1 3/8", 21 splines. More
Version: 1 3/8", 21 splines.
€358,30 €296,12 €329,64 €272,43
You save 8%
Rail pressure valve Valtra-Valmet N 104 - T 234, Massey Ferguson
€149,08 €123,21 €137,15 €113,35
You save 8%
Showing 241 - 288 of 330

Massey Ferguson 7618 parts

Four wheel drive that no longer engages cleanly, a thermostat stuck open, a seal around the door handle that lets in draughts: the jobs on a Massey Ferguson 7618 vary a lot. This page lists more than 300 parts for it, from GRANIT, Scharmüller, Walterscheid, ROCKINGER and HELLA.

Clutch packs and seals in the transmission

There are internal and external plates, including plates for the four wheel drive clutch, plus adjusting plates, PTO O-rings, sealing rings and seals. When rebuilding a plate pack, lay the old plates out in the order they came out. You will see straight away whether one was missing or fitted the wrong way round, and you can stack the new set the same way.

An inductive sensor reads transmission speed. If it throws a fault, check the tip for metal fines before replacing it. A clean is sometimes all it takes.

Thermostats

Thermostats for the 7618 come in more than one version. The opening temperature is stamped on the old one, and that is the value to match. A thermostat that opens too early keeps the engine running cold in spring and autumn.

Hitching and linkage

For the rear there are drawbars, drawbar frames, adapter plates, automatic hitches and forced steering for trailers with a steered axle. The linkage is covered by hydraulic lift rods. Work lamps come partly from HELLA.

A hydraulic lift rod lets you adjust the lower links without leaving the seat. If oil is weeping past the rod, keep the cylinder clean and replace it before dirt gets into the hydraulic system. On forced steering, play in the lock is the first sign of wear. Check it at every service, since a trailer that no longer tracks cleanly scrubs its tyres. Adjusting plates in axle and gearbox always go back where they came from, so keep them sorted by position when you strip things down.

An automatic hitch needs little care. Keep the catch and the lock clean and lightly greased, and listen for it to latch after coupling up.

Type plate and reference number

Take the serial number from the type plate and the reference number from the old part. Transmissions and equipment vary within the 7600 series, so both help. For clutch plates, measure the inner and outer diameter of an old plate before you order.

Related models have their own pages: Massey Ferguson 7615, Massey Ferguson 7616, Massey Ferguson 7619, Massey Ferguson 7620 and Massey Ferguson 7624. The whole brand is on Massey Ferguson parts.
