Case IH 433 tractor parts & technical data

Looking after a Case IH 433, also known as the IHC 433? Here are more than 400 matching parts, including vintage tractor parts, lighting and trailer couplings.

453 parts found for Case IH 433
Show:
Fender rear right without onderconstructie McCORMICK / IHC
Fender rear right without onderconstructie McCORMICK / IHC
To fit as: McCORMICK / IHC 433, 533, 633, 733, 833
€694,99 €574,37

Water channel cast McCORMICK, IHC 353-1455
8%
Water channel cast McCORMICK, IHC 353-1455
To fit as: McCORMICK / IHC 353, 383, 423, 433, 453, 523, 533, 553, 554, 624, 633...
€517,68 €427,83 €476,27 €393,61

Tank cap tank collar Ø 65 mm Case IH, IHC, International, McCormick
Tank cap tank collar Ø 65 mm Case IH, IHC, International, McCormick
To fit as: McCORMICK / IHC 433, 533, 554, 633, 644, 733, 743, 744, 833, 844, 844...
€23,36 €19,31

Tank cap tankdopkraag-Ø 80 mm IHC, McCormick, International, Case IH
Tank cap tankdopkraag-Ø 80 mm IHC, McCormick, International, Case IH
To fit as: McCORMICK / IHC DLD2, D212, D217F, DED3, D320, D324, DGD4, D430, 323,...
€22,65 €18,72

Injection nozzle McCormick, IHC, International, Case IH 433-1056
8%
Injection nozzle McCormick, IHC, International, Case IH 433-1056
To fit as: McCORMICK / IHC 433, 533, 554, 633, 644, 733, 1055, 1056
€48,86 €40,38 €44,95 €37,15

LED rear light 12/24 V, 96 x 80 x 25.5 mm Case IH, John Deere
8%
LED rear light 12/24 V, 96 x 80 x 25.5 mm Case IH, John Deere
Depth (mm): 25.5 | Form: Rectangular | Additional information: Power consumption...
€85,24 €70,45 €78,42 €64,81

Headlight H4 Case IH, John Deere
8%
Headlight H4 Case IH, John Deere
Reference no.: 1333291C1 | Bulb: H4
€51,20 €42,31 €47,10 €38,93

SACHS Double clutch DuT 228/290 41 x 45 mm, 25 splines sintered Case IH
8%
SACHS
Double clutch DuT 228/290 41 x 45 mm, 25 splines sintered Case IH
Material specifications: Sintered clutch lining | Dimensions (mm): 41 x 45 25 gr...
€1.313,14 €1.085,24 €1.208,09 €998,42

SACHS Double clutch DuT 228/250 41 x 45 mm, 25 splines Case IH
8%
SACHS
Double clutch DuT 228/250 41 x 45 mm, 25 splines Case IH
Dimensions (mm): 41 x 45 25 grooves | Flywheel dimension (mm): 40 (tief)
€829,24 €685,32 €762,90 €630,50

LUK Double clutch 228/290TGU 41 x 45 mm, 25 splines Case IH 433 - 940
8%
LUK
Double clutch 228/290TGU 41 x 45 mm, 25 splines Case IH 433 - 940
Flywheel dimension (mm): 40 (tief) | Dimensions (mm): 41 x 45 25 grooves
€937,99 €775,20 €862,95 €713,18

Scharmüller Drawbar 598 mm, 90 x 50 mm, pin 31,5 mm, 78,5 kN, position 1
8%
Scharmüller
Drawbar 598 mm, 90 x 50 mm, pin 31,5 mm, 78,5 kN, position 1
Pin Ø (mm): 31,5 | Height (mm): 50 | Colour: Kubota grey | Mounting position: 1 ...
€392,43 €324,32 €361,04 €298,38

Brake light switch mechanical M12 x 1,5, cable 200 mm IHC 433 - 833
8%
Brake light switch mechanical M12 x 1,5, cable 200 mm IHC 433 - 833
Version: Thread: M12 x 1.5 Cable length: 200 mm Make contact
€109,27 €90,31 €100,53 €83,08

Clutch plate 290 sintered, 22 x 25 mm, 13 splines Case IH
8%
Clutch plate 290 sintered, 22 x 25 mm, 13 splines Case IH
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Sintered clutch l...
€382,07 €315,76 €351,50 €290,50

Double clutch DuT 228/250 41 x 45 mm, 25 spline, flywheel 40 mm
8%
Double clutch DuT 228/250 41 x 45 mm, 25 spline, flywheel 40 mm
Dimensions (mm): 41 x 45 25 grooves | Flywheel dimension (mm): 40 (tief) | Addit...
€412,74 €341,11 €379,72 €313,82

HELLA Alternator 14 V / 33 A, without belt pulley, Case IH 433 - 940
23%
HELLA
Alternator 14 V / 33 A, without belt pulley, Case IH 433 - 940
Charging current (A): 33 | Nominal voltage (V): 14 | Additional information: Wit...
€358,83 €296,55 €276,46 €228,48

Headlight H4 radiator grille Fendt, Case IH, Mercedes Benz
8%
Headlight H4 radiator grille Fendt, Case IH, Mercedes Benz
€103,16 €85,26 €94,91 €78,44

Glass lighting left IHC 433 - 1455
Glass lighting left IHC 433 - 1455
€20,20 €16,69

Emblem IHC 323 - 1246
8%
Emblem IHC 323 - 1246
€49,87 €41,21 €45,88 €37,92

FEBI Fuel filter WK842
57%
FEBI
Fuel filter WK842
€19,60 €16,20 €8,47 €7,00

MAHLE Gear reduction starter 12 V, 3,2 kW, 11 teeth, Ø 89 mm, flange 25 mm
40%
MAHLE
Gear reduction starter 12 V, 3,2 kW, 11 teeth, Ø 89 mm, flange 25 mm
€612,77 €506,42 €367,01 €303,31

Starter motor 12 V, 3,1 kW, 11 teeth, 256,5 mm, Ø 89 mm
8%
Starter motor 12 V, 3,1 kW, 11 teeth, 256,5 mm, Ø 89 mm
€297,93 €246,22 €274,10 €226,53

Starter ring gear Ø 363/325 mm, 119 teeth Case IH
8%
Starter ring gear Ø 363/325 mm, 119 teeth Case IH
Version: Ø 363/325 mm, 119 teeth.
€1.002,91 €828,85 €922,68 €762,54

Gear lever 480 mm IHC 433-833
8%
Gear lever 480 mm IHC 433-833
€132,92 €109,85 €122,29 €101,06

Thermostat Ø 54 mm, 82 °C Case IH
Thermostat Ø 54 mm, 82 °C Case IH
Ø: 54 mm. Temperature: 82 °C.
€27,28 €22,54

Return line Case IH 433, 533, 633
8%
Return line Case IH 433, 533, 633
€88,65 €73,26 €81,56 €67,40

Intake plate with pressure continuation 250 bar, 40 l/min, M18 x 1,5 Case IH
8%
Intake plate with pressure continuation 250 bar, 40 l/min, M18 x 1,5 Case IH
Technical data: Max. operating pressure: 250 bar, Nominal flow rate: max. 40 l/m...
€391,14 €323,26 €359,85 €297,40

End plate steering valve 210 bar, 40 l/min, 80 x 10 x 70 mm Case IH
8%
End plate steering valve 210 bar, 40 l/min, 80 x 10 x 70 mm Case IH
Technical data: Max. operating pressure: 210 bar, Nominal flow rate: max. 40 l/m...
€98,74 €81,60 €90,84 €75,08

Headlight left / right 12 / 24 V, H4, built-in, 172 x 142 x 77 mm
8%
Headlight left / right 12 / 24 V, H4, built-in, 172 x 142 x 77 mm
Bulb: 12V60/55W / H4, 12V4WK / T4W, 24V75/70W / H4, 24V4WK/T4W. Material: Housin...
€48,86 €40,38 €44,95 €37,15

Cobo Indicator/position light 84 x 84 x 51 mm, P21W, C5W left / right
8%
Cobo
Indicator/position light 84 x 84 x 51 mm, P21W, C5W left / right
Bulb: 12V21WK / P21W, 12V5WS / C5W. Colour: Yellow, white. Connection: Blade ter...
€34,28 €28,33 €31,54 €26,06

HELLA Headlight left / right 12 / 24 V, H4, glass 138 x 124 mm, built-in
23%
HELLA
Headlight left / right 12 / 24 V, H4, glass 138 x 124 mm, built-in
To fit as: Case IH 383, 423, 433, 533, 633, 733, 833, 440, 540, 640, 453, 553, 5...
€128,66 €106,33 €99,13 €81,93

HELLA Headlight left / right 12 / 24 V, R2, dipped beam / main beam, built-in
23%
HELLA
Headlight left / right 12 / 24 V, R2, dipped beam / main beam, built-in
To fit as: Case IH 383, 423, 433, 533, 633, 733, 833, 440, 540, 640, 453, 553, 5...
€106,89 €88,34 €82,37 €68,07

Brake disc Ø 165 mm McCORMICK, IHC 323-833
8%
Brake disc Ø 165 mm McCORMICK, IHC 323-833
To fit as: McCORMICK / IHC 323, 353, 383, 423, 433, 453, 533, 633, 733, 833
€107,96 €89,22 €99,32 €82,09

Coolant filter Ø 93,1 x 105,4 mm McCormick, IHC 433-1455
Coolant filter Ø 93,1 x 105,4 mm McCormick, IHC 433-1455
To fit as: McCORMICK / IHC 433, 533, 633, 733, 833, 554, 644, 743, 744, 745, 844...
€27,39 €22,63

Connecting rod bearing standard, 32 mm wide McCORMICK, IHC 353-1455
Connecting rod bearing standard, 32 mm wide McCORMICK, IHC 353-1455
To fit as: McCORMICK / IHC 353, 383, 423, 433, 453, 523, 533, 553, 554, 624, 633...
€28,96 €23,94

Valve guide McCORMICK, IHC 353-1455
Valve guide McCORMICK, IHC 353-1455
To fit as: McCORMICK / IHC 353, 383, 423, 433, 453, 523, 533, 553, 554, 624, 633...
€12,39 €10,24

Piston set complete 3 rings, Ø 98,425 mm, pin Ø 36 x 82 mm
8%
Piston set complete 3 rings, Ø 98,425 mm, pin Ø 36 x 82 mm
To fit as: McCORMICK / IHC 353, 383, 423, 433, 453, 533, 624, 654, 733, 946, 955
€171,47 €141,71 €157,75 €130,37

SACHS Double clutch DuT 228/290 41 x 45 mm, 25 splines organic Case IH
8%
SACHS
Double clutch DuT 228/290 41 x 45 mm, 25 splines organic Case IH
Dimensions (mm): 41 x 45 25 grooves | Material specifications: Organic clutch li...
€995,41 €822,65 €915,78 €756,84

SACHS Clutch plate 290, 22 x 25 mm, 13 splines organic Case IH
8%
SACHS
Clutch plate 290, 22 x 25 mm, 13 splines organic Case IH
Material specifications: Organic clutch lining | Dimensions (mm): 22 x 25 13 gro...
€396,72 €327,87 €364,98 €301,64

Connecting rod bearing 32 mm wide, undersize 0,5 mm IHC 353 - 1046
Connecting rod bearing 32 mm wide, undersize 0,5 mm IHC 353 - 1046
Version: 32 mm wide, undersize 0.5 mm
€11,53 €9,52

Scharmüller Drawbar frame 59,7 kN, rail 330 mm, guide 32 mm, pin Ø 25 mm
3%
Scharmüller
Drawbar frame 59,7 kN, rail 330 mm, guide 32 mm, pin Ø 25 mm
Guide width (mm): 32 | D-value (kN): 59,7 | Version: Prepared for drawbar | Load...
€1.074,22 €887,79 €1.038,28 €858,08

LUK Clutch kit double plate connection Case IH 323 - 833
8%
LUK
Clutch kit double plate connection Case IH 323 - 833
Supplementary set: Without release bearing | Connection: For vehicles with doubl...
€1.293,37 €1.068,90 €1.189,90 €983,39

LUK Thrust bearing 65 x 101,6 x 17 mm Case IH, Lindner
8%
LUK
Thrust bearing 65 x 101,6 x 17 mm Case IH, Lindner
Dimensions (mm): 65 x 101.6 x 17
€150,99 €124,79 €138,91 €114,80

LUK Clutch plate 250TZFN 22 x 25 mm, 13 splines Case IH
8%
LUK
Clutch plate 250TZFN 22 x 25 mm, 13 splines Case IH
Dimensions (mm): 22 x 25 13 grooves
€334,66 €276,58 €307,89 €254,45

Clutch plate 290 organic, 22 x 25 mm, 13 splines Case IH
8%
Clutch plate 290 organic, 22 x 25 mm, 13 splines Case IH
Additional information: Made in Germany | Dimensions (mm): 22 x 25 13 grooves | ...
€257,35 €212,69 €236,76 €195,67

Clutch plate 250 CZ 21,7 x 25 mm, 13 splines organic Case IH
8%
Clutch plate 250 CZ 21,7 x 25 mm, 13 splines organic Case IH
Additional information: Made in Germany | Dimensions (mm): 21.7 x 25 13 grooves ...
€213,46 €176,41 €196,38 €162,30

Double clutch DuT 228/290 41 x 45 mm, 25 spline, organic
8%
Double clutch DuT 228/290 41 x 45 mm, 25 spline, organic
Dimensions (mm): 41 x 45 25 grooves | Flywheel dimension (mm): 40 (tief) | Mater...
€569,02 €470,26 €523,50 €432,64

Double clutch DuT 295 45 x 50 mm, 24 splines
3%
Double clutch DuT 295 45 x 50 mm, 24 splines
Additional information: Made in Germany | Dimensions (mm): 45 x 50, 24 grooves |...
€1.022,57 €845,10 €990,76 €818,81

Showing 97 - 144 of 453

Case IH 433 parts for a tractor with plenty of hours behind it

Many owners still call it the IHC 433, and that is the name found on a good number of its parts. Keeping one working means dealing with gaskets that have gone hard, a clutch that starts to slip and steering ball joints with play. There are more than 400 Case IH 433 parts on this page, from GRANIT, HELLA, Scharmüller, LUK and FEBI.

Clutch: double clutch, plate and thrust bearing

The clutch side covers double clutches, clutch plates and thrust bearings. A double clutch works both the travel clutch and the PTO, so slipping and a PTO that will not disengage can share the same cause. Replace clutch, plate and thrust bearing together while the tractor is split anyway, and inspect the flywheel for scoring and blue heat spots. A new plate on a damaged flywheel soon starts to judder.

Engine and sealing

Around the engine there are gaskets, for example for the camshaft, O-rings, fuel pump seals and crankshaft seals. Before a new seal goes onto the crankshaft, look at the running surface. If the old lip has worn a track, press the new seal in slightly deeper or use a repair sleeve so the lip runs on clean metal.

For the steering there are ball joints, for the gearbox gear balls, and for the shift rod sealing rings. Replace ball joints left and right at the same time and reset the toe-in afterwards. On an older tractor the taper can be seized solid in the arm. Use a ball joint puller rather than a hammer so the steering arm is not damaged.

Lights and panels

Lighting is often the first thing on a 433 that needs attention before it goes back on the road. There are headlights, separate lenses for the tail and indicator light on the fender, and indicator and position lights that come as a pair. Rear fenders are part of the range too. A cracked lens on a tail light lets water in, and then the holder and contacts corrode, so swap the lens early.

The right part for an IHC 433

Check the type plate to confirm it is a 433. Many parts name a McCormick or IHC number range that includes the 433, and the old part often still shows a reference number. Copy it, because on a tractor that has been repaired many times you cannot be sure the part fitted was meant for this model.

If you also run a Case IH 640 or Case IH 740, their parts are on a page of their own. For the whole make, go to Case IH parts.
