Case IH CX 90 tractor parts & technical data

Keep your Case IH CX 90 from the CX series running with more than 250 matching parts on this page, among them electrics, trailer couplings and lighting.

261 parts found for Case IH CX 90
Show:
PROBOSS Tractor seat air suspended fabric, 480 mm, 12 V, AS2480
PROBOSS
Air suspension with 12V compressor. Fore/aft isolator. Height adjustment, longitudinal adjustment, backrest tilt adjustment. Mechanical lumbar support... More
Air suspension with 12V compressor. Fore/aft isolator. Height adjustme...
€875,22 €723,32
LED main headlight 12/24 V, 168 x 107 x 81,5 mm, H4
Voltage range (V): 10 - 30 | Nominal voltage (V): 12 / 24 | Connection: H4 | Power consumption (W): 55 | Light colour (K): 6000 | Housing material: Al... More
Voltage range (V): 10 - 30 | Nominal voltage (V): 12 / 24 | Connection...
€124,74 €103,09 €114,76 €94,84
You save 8%
FEBI Engine oil filter Ø 93 mm, height 177 mm, thread 3/4"-16 UNF
€19,80 €16,36 €12,18 €10,07
You save 38%
Tank cap with ventilation, thread Ø 60 / 64 mm, tank collar Ø 65 mm
Thread Ø mm: 60 / 64. Filler neck Ø: 65 mm. More
Thread Ø mm: 60 / 64. Filler neck Ø: 65 mm.
€29,04 €24,00
Pump screenwash tank 12 V, intake-Ø 6,3 mm, press-Ø 6,3 mm
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system. Voltage: 12 V. Connection type: 2 x 6,3. Operating mode: electric. More
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system...
€35,49 €29,33 €32,65 €26,98
You save 8%
Walterscheid Top drawbar rail 309 mm, pin Ø 22 mm, coupling pin 31 mm
Walterscheid
Rail width: 309 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecting pin: 31 mm. Load capacity: 2000 kg. D-value: 92 kN. Colour: Black. Descriptio... More
Rail width: 309 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecti...
€1.104,81 €913,07 €873,47 €721,88
You save 21%
Walterscheid Inner part ball 80 rail width 309 mm, pin Ø 22 mm, 3000 kg
Walterscheid
D-value (kN): 89.3 | Colour: Black | Assembly notes: Suitable for connection to ball hitches 80 according to ISO 24347. The 80 mm diameter ball can be... More
D-value (kN): 89.3 | Colour: Black | Assembly notes: Suitable for conn...
€2.146,48 €1.773,95 €1.697,03 €1.402,50
You save 21%
Donaldson Maintenance switch air filter electric, 2 blade connections
Donaldson
Donaldson no.: X770062 | Version: Differential pressure switch 2 blade terminals | Type: Electrical More
Donaldson no.: X770062 | Version: Differential pressure switch 2 blade...
€35,42 €29,27 €32,59 €26,93
You save 8%
Start safety switch differential lock M18 x 1,5 Case IH
Version: Differential lock (contact function) Thread: M18 x 1.5 2 blade terminals More
Version: Differential lock (contact function) Thread: M18 x 1.5 2 blad...
€40,09 €33,13 €36,88 €30,48
You save 8%
HELLA Flasher unit 12 V, 2+1+1 / 8 x 21 W, 6 connections, with cable
HELLA
Version: Power rating: 12 V / 2 + 1 + 1 x 21 W / 8 x 21 W, With hazard warning light function, with cable and bracket. Additional information: • Rel... More
Version: Power rating: 12 V / 2 + 1 + 1 x 21 W / 8 x 21 W, With hazard...
€80,43 €66,47 €77,45 €64,01
You save 4%
Steering column switch indicator, horn, lever length 85 mm
Version: Functions: indicators, horn and headlight flasher, lever length 85 mm, without locking position (spring-loaded switch), blade terminal connec... More
Version: Functions: indicators, horn and headlight flasher, lever leng...
€314,14 €259,62 €289,01 €238,85
You save 8%
FEBI Engine oil filter Ø 93 mm, height 177 mm, thread 3/4"-16 UNF
€26,68 €22,05 €8,08 €6,68
You save 70%
HELLA Starter motor 12 V, 2,8 kW, 10 teeth, flange 89 mm, clockwise
€503,79 €416,36 €485,20 €401,00
You save 4%
HELLA Rocker switch hazard lights locks in place, 7 connections 6,3 mm
HELLA
Version: Insert with symbol must be ordered separately. Without location light, with function light, 7 blade terminals 6.3 mm, 2 switch positions: 0: ... More
Version: Insert with symbol must be ordered separately. Without locati...
€32,91 €27,20
HELLA Interior lights K (10W), clear, 12 V, built-in
HELLA
Bulb: K (10W). Colour: Transparent. Installation location: Interior. Nominal voltage: 12 V. Switches: On switch. Type: Halogen. Light function: Interi... More
Bulb: K (10W). Colour: Transparent. Installation location: Interior. N...
€14,68 €12,13
SANDEN Aircon compressor SD7H15 12 V, pulley Ø 152 mm, 2 grooves
SANDEN
Fixing: EM | Pulley Ø (mm): 152 | Connection: A2 | Suitable oil: SP - 15 | No. of grooves: 2 | Reference no.: SD7H15-4478, 86993462, 1999755C2, 19997... More
Fixing: EM | Pulley Ø (mm): 152 | Connection: A2 | Suitable oil: SP -...
€621,28 €513,45 €571,58 €472,38
You save 8%
AKS-Dasis Thermostat airco Case IH, Fiat, Ford, Laverda
AKS-Dasis
Version: For air conditioning system More
Version: For air conditioning system
€92,69 €76,60 €85,27 €70,48
You save 8%
Replacement key Case IH - 2 pieces
Version: To fit as: Case IH More
Version: To fit as: Case IH
€34,91 €28,85 €32,12 €26,54
You save 8%
Koppelingshulpcilinder Case IH 3210 - 4240, CX 50 - CX 100
€127,06 €105,01 €116,90 €96,61
You save 8%
Perkins Oil filter Ø 93 mm, length 177 mm, thread 3/4" 16 UNF Perkins
Perkins
Outer Ø: 93 mm. Length: 177 mm. Thread: 3/4" 16 UNF. More
Outer Ø: 93 mm. Length: 177 mm. Thread: 3/4" 16 UNF.
€41,20 €34,05 €37,01 €30,59
You save 10%
Internal plate PTO clutch 2,1 mm, inner 93,3 mm, outer 125 mm
Version: thickness = 2,1 mm inner = 93,3 mm outer 125 mm More
Version: thickness = 2,1 mm inner = 93,3 mm outer 125 mm
€34,20 €28,26 €31,46 €26,00
You save 8%
Filter dryer airco 197 mm, #6 3/8 o-ring, M/F Case IH, McCormick
Weight (g): 800 | Thread: #6 3/8 O-ring | Connection thread: M/F | Length (mm): 197 More
Weight (g): 800 | Thread: #6 3/8 O-ring | Connection thread: M/F | Len...
€78,90 €65,21 €72,59 €59,99
You save 8%
Rotary switch fan, 5 blade terminals Case IH
Version: For blower With 5 blade terminals More
Version: For blower With 5 blade terminals
€39,39 €32,55 €36,24 €29,95
You save 8%
LUK Single clutch 310TBFR 1 5/8 inch, 10 splines Case IH, McCormick
LUK
Dimensions (inches): 1 5/8"" 10 grooves More
Dimensions (inches): 1 5/8"" 10 grooves
€522,06 €431,45 €480,30 €396,94
You save 8%
Thrust bearing 60 x 102 x 20,5 mm Case IH
Dimensions (mm): 60 x 102 x 20.5 More
Dimensions (mm): 60 x 102 x 20.5
€45,69 €37,76 €42,03 €34,74
You save 8%
PROBOSS Seat AS3520 air suspended 520 mm, 12 V IHC, Steyr, New Holland
PROBOSS
- Air suspension with 12V compressor - Fore/aft isolator - Continuous height adjustment - Longitudinal adjustment - Backrest tilt adjustment - Mechani... More
- Air suspension with 12V compressor - Fore/aft isolator - Continuous ...
€1.818,19 €1.502,64 €1.792,40 €1.481,32
You save 1%
MAHLE Gear reduction starter 12 V, 3,2 kW, 10 teeth, 238 mm, clockwise
€467,44 €386,31 €279,96 €231,38
You save 40%
MAHLE Gear reduction starter 12 V, 3,2 kW, 10 teeth clockwise, 213,3 mm
€401,62 €331,92 €240,55 €198,80
You save 40%
GRAMMER Tractor seat air suspended Maximo Professional fabric, seat width 530 mm
GRAMMER
Super comfort seat with low-frequency air suspension and 12V compressor. APS: automatic positioning system. Armrests height adjustable and folding. Ad... More
Super comfort seat with low-frequency air suspension and 12V compresso...
€1.991,23 €1.645,64
Walterscheid Ball hitch ball 80, rail width 309 mm, pin Ø 22 mm, 2800 kg
Walterscheid
Description: This product is a ball hitch. The hitch ball 80 dimensions and areas of application comply with ISO 24347, VO (EU) 2015/208 and UN ECE R1... More
Description: This product is a ball hitch. The hitch ball 80 dimension...
€2.071,98 €1.712,38 €1.638,13 €1.353,83
You save 21%
Internal plate differential 1,6 mm, inner 44 mm, outer 71,7 mm
Version: Thickness: 1.6 mm Inner: 44 mm Outer: 71.7 mm 22 teeth More
Version: Thickness: 1.6 mm Inner: 44 mm Outer: 71.7 mm 22 teeth
€14,85 €12,27
AKS-Dasis Condenser Case IH C 70 - CX 100, MX 80C - 100C
AKS-Dasis
Weight (g): 3000 More
Weight (g): 3000
€639,87 €528,82 €588,68 €486,51
You save 8%
LUK Clutch kit without release bearing Case IH, McCormick
LUK
Contents: Pressure plate 458131025410, clutch plate 458331023510 | Supplementary set: Without release bearing More
Contents: Pressure plate 458131025410, clutch plate 458331023510 | Sup...
€790,09 €652,97 €726,88 €600,73
You save 8%
AKS-Dasis Potentiometer airco 3 link steps Case IH CX 50 - 100
AKS-Dasis
Equipment: 3 switching stages More
Equipment: 3 switching stages
€55,33 €45,73 €50,90 €42,07
You save 8%
Expansion valve airco 1/2 inch - 3/8 inch o-ring, 238 g
Connection thread A: # 8, 1/2"" O-ring | Connection thread E: # 6, 3/8"" O-ring | Equipment: O-ring | Weight (g): 238 More
Connection thread A: # 8, 1/2"" O-ring | Connection thread E: # 6, 3/8...
€57,16 €47,24 €52,59 €43,46
You save 8%
Symbol four-wheel drive green Case IH 3210 - 4240, C 50 - CX 100
Version: Green, four-wheel drive More
Version: Green, four-wheel drive
€5,61 €4,64
MAHLE Alternator 14 V, 70 A, flange 80,5 mm, form A
MAHLE
Additional information: With fan | Nominal values (V / A): 14 / 70 | Nominal voltage (V): 14 | Belt width (mm) / type: - | Charging current (A): 70 | ... More
Additional information: With fan | Nominal values (V / A): 14 / 70 | N...
€277,39 €229,25 €166,13 €137,30
You save 40%
HELLA Starter motor 12 V, 3,2 kW, 10 teeth, Ø 89 mm, clockwise
€596,39 €492,88 €459,50 €379,76
You save 23%
PTO shaft end piece 244,5 mm Case IH
Version: Length 244,5 mm. More
Version: Length 244,5 mm.
€231,13 €191,02 €212,64 €175,74
You save 8%
ROCKINGER Piton Fix rail width 330 mm, locking pin Ø 25 mm, 4000 kg, 89,3 kN
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 89,3 kN. Description: Manual Piton-Fix with elevator be... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.363,65 €1.126,98 €1.100,67 €909,64
You save 19%
Exhaust pipe Case IH CX 50-100, MX 80C-90C
€77,10 €63,72 €70,93 €58,62
You save 8%
PROBOSS Seat PROBOSS AS3510 air suspended, fabric, 510 mm, 12 V
PROBOSS
Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 510 mm. Joystick console: Optiona... More
Suspension: Air suspension. Upholstery type: Fabric. Seat contact swit...
€1.383,42 €1.143,32
GRAMMER Tractor seat Maximo Comfort Plus Case CVX, Steyr, New Holland
GRAMMER
To fit: Case CVX, Steyr, New Holland. Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Yes. Track gauge: 260 mm. Seat width: ... More
To fit: Case CVX, Steyr, New Holland. Suspension: Air suspension. Upho...
€2.247,41 €1.857,36
ROCKINGER Drawbar K80 rail width 330 mm, locking pin Ø 25 mm
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 102 kN. Description: Manual ball hitch with height-adju... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.285,58 €1.062,46 €990,51 €818,61
You save 23%
Pin three-point parts Case IH C 50 - 90, CX 50 - 100
€37,88 €31,31 €34,85 €28,80
You save 8%
Showing 1 - 48 of 261

Case IH CX 90 parts

On a Case IH CX 90 that spends its days on loader work, the steering joints take a beating. That is a good place to start, but this page goes further, with more than 250 parts that fit this tractor from GRANIT, HELLA, ROCKINGER, MAHLE and GRAMMER.

Steering and front axle

Ball joints and axial joints cover the steering. A potentiometer receiver for the four wheel drive axle is listed as well. Before you remove a ball joint, measure the track rod or count the turns as you unscrew it. Fitting the new joint at the same position keeps the toe close to correct until you can have it aligned. Always use a new lock nut or split pin.

Cab, switches and mirrors

The cab side is well covered. There are rocker switches, for example for the front PTO, rotary switches, relays and hazard symbols for switch faces. Cab door hinges are available, and gas struts hold the side, front or rear window open. Heavy duty telescopic mirror arms complete the list.

Before you pull the plug off a rocker switch, disconnect the battery and take a photo of the back. Every wire then goes back on the right terminal.

Engine and rear linkage

For the engine there is a starter motor, O-rings and sealing rings, such as the front crankshaft seal. Oil the lip of a new crankshaft seal lightly and drive it in squarely with a suitable drift. A seal that sits crooked leaks almost at once, and a dry lip can tear on the first start. Check the shaft for a worn groove where the old lip ran. At the rear you will find drawbars and pins for the three point linkage.

Matching parts to your CX 90

Check the type plate first. The Case IH CX series includes several models that look almost identical from the outside. After that, the reference number on the old part is the best guide. On a ball joint it is often on the housing, and on a hinge it may be stamped into the metal. Use that number to confirm the details given for the part.

The other models in the CX series each have a page with the parts that fit them: Case IH CX 70, Case IH CX 80 and Case IH CX 100. That saves time if you run more than one CX. All remaining models from the brand are listed under Case IH parts.
