New Holland TL70 tractor parts & technical data

Looking for New Holland TL70 parts? Pick from more than 250 items that fit this TL series tractor, such as trailer couplings, lighting and electrics.

302 parts found for New Holland TL70
Show:
Ball joint taper 18,1 - 20,3 mm, length 740 mm, M16 x 1,5, 20 mm
A: 740 mm. C: M16 x 1,5 mm. D: 20 mm. E: 18,1 mm. F: 20,3 mm. Taper: 18,1 - 20,3 mm. More
A: 740 mm. C: M16 x 1,5 mm. D: 20 mm. E: 18,1 mm. F: 20,3 mm. Taper: 1...
€59,95 €49,55 €55,15 €45,58
You save 8%
Ball joint 888 mm, M16 x 1,5, 23,8 mm, taper 18,2 - 20,5 mm
A: 888 mm. C: M16 x 1,5 mm. D: 23,8 mm. E: 18,2 mm. F: 20,5 mm. Taper: 18,2 - 20,5 mm. More
A: 888 mm. C: M16 x 1,5 mm. D: 23,8 mm. E: 18,2 mm. F: 20,5 mm. Taper:...
€158,22 €130,76 €145,56 €120,30
You save 8%
Steering cylinder right and left, ball eye Ø 20 mm
Technical data: Ball eye Ø: 20 mm. More
Technical data: Ball eye Ø: 20 mm.
€474,31 €391,99 €436,37 €360,63
You save 8%
Feed pump Case IH, New Holland engine 8035
€42,93 €35,48 €39,50 €32,64
You save 8%
Lock rear window lower
ROCKINGER Drawbar without sensor rail 310 mm, coupling pin 38 mm, black
ROCKINGER
Rail width: 310 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 120,0 kN. Colour: Black. Descrip... More
Rail width: 310 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecti...
€1.122,48 €927,67 €864,85 €714,76
You save 23%
ROCKINGER Piton Fix rail width 330 mm, locking pin Ø 25 mm, 3000 kg, 102 kN
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 3000 kg. D-value: 102 kN. Description: Piton-Fix with manual lock and hei... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.504,05 €1.243,02 €1.158,85 €957,72
You save 23%
ROCKINGER Drawbar without sensor rail width 330 mm, coupling pin 30,6 mm
ROCKINGER
Colour: Black. Description: Entire coupling body and bearing forged, Easy height adjustment thanks to the use of sliding blocks, Cylindrical hitch bol... More
Colour: Black. Description: Entire coupling body and bearing forged, E...
€1.126,27 €930,80 €867,77 €717,17
You save 23%
ROCKINGER Drawbar K80 rail width 310 mm, locking pin Ø 22 mm
ROCKINGER
Rail width: 310 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 4000 kg. D-value: 102 kN. Load capacity: 4 t. Ball Ø: 80 mm. Lock: KS80. More
Rail width: 310 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.431,83 €1.183,33 €1.103,20 €911,74
You save 23%
Walterscheid Top drawbar rail 309 mm, pin Ø 22 mm, coupling pin 37 mm
Walterscheid
Rail width: 309 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecting pin: 37 mm. Load capacity: 2000 kg. D-value: 120,5 kN. Colour: Black. Descrip... More
Rail width: 309 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Connecti...
€1.820,72 €1.504,73 €1.439,48 €1.189,65
You save 21%
Potentiometer rotation angle sensor EHR 4000 Ohm, 13,5 V
Version: Rotation angle sensor (position), electronic linkage control, For clutch and brake operation. More
Version: Rotation angle sensor (position), electronic linkage control,...
€151,60 €125,29 €139,47 €115,27
You save 8%
Lamp glass right, left
Installation location: Right, left. More
Installation location: Right, left.
€39,24 €32,43
Rear light left / right 235 x 70 x 45 mm, 12 V
Bulb: 12V10WK / R10W, 12V21WK / P21W. Width: 235 mm. Form: Rectangular, short sides rounded. Height: 70 mm. Dimensions W x H x D: 235 x 70 x 45 mm. De... More
Bulb: 12V10WK / R10W, 12V21WK / P21W. Width: 235 mm. Form: Rectangular...
€94,35 €77,98
Oil pressure switch transmission differential, 2 blade terminals
Version: Transmission, (hydraulics) differential, 2 blade terminals. More
Version: Transmission, (hydraulics) differential, 2 blade terminals.
€138,89 €114,79 €127,78 €105,60
You save 8%
Cobo Lens indicator/position light left / right
Cobo
To fit as: Case IH, Deutz-Fahr, Fiat, Hürlimann, John Deere, Lamborghini, Landini, Massey Ferguson, Mc Cormick, Renault, Same More
To fit as: Case IH, Deutz-Fahr, Fiat, Hürlimann, John Deere, Lamborgh...
€14,73 €12,17
MANN-FILTER Air filter C17337/2, AF25557, inner CF990/2
MANN-FILTER
Suitable secondary element 565CF990.2 More
Suitable secondary element 565CF990.2
€44,60 €36,86
MAHLE Gear reduction starter 12 V, 2,6 kW, 9 teeth, Ø 110 mm, clockwise
€544,83 €450,27 €326,32 €269,69
You save 40%
PTO shaft end piece 1 3/8 inch 6 splines Case IH, Steyr, New Holland
€179,75 €148,55 €165,37 €136,67
You save 8%
Starter ring gear Ø 335/293 mm, 110 teeth
Version: Ø 335/293 mm, 110 teeth. More
Version: Ø 335/293 mm, 110 teeth.
€54,23 €44,82 €49,89 €41,23
You save 8%
Gear lever knob Ø upper 20 mm, length 35 mm, thread M8
Version: Ø top 20 mm, length 35 mm, thread M8. More
Version: Ø top 20 mm, length 35 mm, thread M8.
€7,34 €6,06
Borg Warner Cooling fan Ø 450 mm, hole spacing-Ø 48 mm
Borg Warner
Ø: 450 mm. PCD: 48 mm. More
Ø: 450 mm. PCD: 48 mm.
€373,74 €308,88 €314,39 €259,83
You save 16%
Radiator cap grommet-Ø 57 mm, height 25 mm, for expansion tank
Version: For expansion tank. Neck Ø: 57 mm. Height: 25 mm. More
Version: For expansion tank. Neck Ø: 57 mm. Height: 25 mm.
€16,00 €13,22
Radiator hose, bottom inner-Ø 35 mm, length 80 mm
Inner Ø: 35 mm. Length: 80 mm. More
Inner Ø: 35 mm. Length: 80 mm.
€5,05 €4,17
Thermostat Ø 54 mm, 79 °C Ford, Case IH, Fiat, Steyr, New Holland
Ø: 54 mm. Temperature: 79 °C. More
Ø: 54 mm. Temperature: 79 °C.
€24,35 €20,12
Exhaust manifold 4 cylinder Case IH, Fiat, New Holland, Ford
€116,87 €96,59 €107,52 €88,86
You save 8%
Steering valve ew/dw with float position 220 bar, 70 l/min
Technical data: Max. operating pressure: 220 bar, Nominal flow rate: max. 70 l/min, Tightening torque: 30 Nm, Connections: M18 x 1.5, Dimensions: 210 ... More
Technical data: Max. operating pressure: 220 bar, Nominal flow rate: m...
€940,41 €777,20 €865,18 €715,02
You save 8%
Bosch/Rexroth Hydraulic pump 14 cm³/rpm., taper 1:8, Ø 17,46, left
Bosch/Rexroth
Output volume: 14 cc/rev. Drive shaft: Taper 1:8, Ø 17.46. Direction of rotation: Anticlockwise. Bosch no.: 0510525360. More
Output volume: 14 cc/rev. Drive shaft: Taper 1:8, Ø 17.46. Direction ...
€1.389,34 €1.148,21 €1.278,19 €1.056,36
You save 8%
Gas strut roof window 150 N, 256 mm, stroke 82 mm
suitable for: Dachluke. Newtons: 150. A: 256 mm. B: 144 mm. C: 8 mm. D: 7,8 mm. Form: 11. d1: 8 mm. d2: 18 mm. Stroke: 82 mm. To fit: Roof hatch. More
suitable for: Dachluke. Newtons: 150. A: 256 mm. B: 144 mm. C: 8 mm. D...
€82,74 €68,38 €76,12 €62,91
You save 8%
Door lock, left Ford, Fiat, New Holland
€165,99 €137,18 €152,71 €126,21
You save 8%
Handle right and left Case IH, New Holland
€93,38 €77,17 €85,91 €71,00
You save 8%
ROCKINGER Drawbar KS80 rail 330 mm, pin Ø 25 mm, 4000 kg, black
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 100 kN. Colour: Black. Description: Ball hitch with com... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.489,09 €1.230,65 €1.197,32 €989,52
You save 20%
Brake light switch oil pressure make contact, neutral position off, M10 x 1
Version: Thread M10 x 1, normally off, make contact, Blade terminal. More
Version: Thread M10 x 1, normally off, make contact, Blade terminal.
€39,55 €32,69 €36,39 €30,07
You save 8%
Contact switch
€38,51 €31,83 €35,43 €29,28
You save 8%
Contact switch mechanical brake light and start safety switch
Version: Brake light and start safety switch. More
Version: Brake light and start safety switch.
€35,01 €28,93 €32,21 €26,62
You save 8%
Relays make contact 12 V, 30 A, without bracket, 5-pin, 6,3 mm
Version: 12 V / 30 A, Without bracket, 5-pin, blade terminal 6.3 mm. More
Version: 12 V / 30 A, Without bracket, 5-pin, blade terminal 6.3 mm.
€30,51 €25,22
Thermostat Ø 54 mm, 79 °C Ford, Case IH, Fiat, Steyr, New Holland
To fit as: New Holland TD 55D, 65D, 75D, 85D, 95D, TL 70, 80, 90, 100, TN 55, 65, 70, 75, 80, 90, 95, L 60, 65, 75, 85, 95 More
To fit as: New Holland TD 55D, 65D, 75D, 85D, 95D, TL 70, 80, 90, 100,...
€24,35 €20,12
MAHLE Starter motor 12V 2,8 kW, 9 teeth clockwise, mounting Ø 110 mm
€277,68 €229,49 €249,47 €206,18
You save 10%
Showing 145 - 192 of 302

New Holland TL70 parts for the driveline, belts and electrics

A slipping clutch, an air conditioning belt that squeals on a cold start or an alternator that has stopped charging are all jobs you can sort out with the parts on this page. There are more than 250 new replacement parts here that fit the New Holland TL70, from makers such as GRANIT, LUK, Eaton, Cobo and ROCKINGER.

Check the part number first

The quickest route to the right part is the reference number stamped into the old part or printed on its label. Type it into the search bar or compare it with the numbers listed with each product. If you are not sure the tractor really is a TL70, the identification plate on the chassis settles it. For an alternator, compare the flange and the pulley on the old unit before ordering, and for an aircon compressor count the grooves in the pulley.

What you can order for the TL70

  • Clutch and gearbox: double clutches, release bearings for the driving clutch and individual gear wheels.
  • Belts and air conditioning: V-belts, including the belt that drives the aircon compressor, and complete aircon compressors.
  • Sealing: piston sealing rings, seals for the outer lift cylinder, gaskets and O-rings at the thermostat.
  • Electrics and lights: alternators, contact switches, rear lights and indicator position lights.
  • Hitching: automatic drawbars and Piton Fix hitches, worth fitting once the pin or rail of the old hitch has worn.

A workshop tip for the clutch

If the clutch pack is coming out, order the thrust bearing with it. That bearing turns every time you press the pedal and has done just as many hours as the plate you are replacing. Splitting a tractor is a job you only want to do once. With the gearbox off, also check the crankshaft rear seal and the guide sleeve the bearing slides on, because scoring on that sleeve will chew through a new bearing in no time.

When the air conditioning stops cooling

If the cab only gets lukewarm air, first check that the clutch on the aircon compressor engages and that the V-belt is tight enough. A slipping belt turns the compressor too slowly to do much. If the compressor itself has to be replaced, have the drier renewed and the system evacuated before it is recharged, because moisture left in the circuit will ruin a new compressor quickly.

Other tractors in the TL series

The TL80, TL90 and TL100 each have their own page. If you run more than one of them, look up each tractor separately, as a part listed for the TL70 does not automatically fit its neighbour. Every other model from the brand is listed under New Holland parts.
