Case IH 740 tractor parts & technical data

Case IH 740 or IHC 740, the name on the bonnet makes no difference here: more than 250 items for this tractor, including trailer couplings and oldtimer parts.

299 parts found for Case IH 740
Show:
Scharmüller Drawbar 598 mm, 90 x 50 mm, pin 31,5 mm, 78,5 kN, position 1
Scharmüller
Pin Ø (mm): 31,5 | Height (mm): 50 | Colour: Kubota grey | Mounting position: 1 | Category: Drawbar | Length (mm): 598 | D-value (kN): 78,5 | Load ca... More
Pin Ø (mm): 31,5 | Height (mm): 50 | Colour: Kubota grey | Mounting p...
€392,43 €324,32 €361,04 €298,38
You save 8%
Clutch plate 290 sintered, 22 x 25 mm, 13 splines Case IH
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Sintered clutch lining | Additional information: Made in Germany More
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Sintere...
€382,07 €315,76 €351,50 €290,50
You save 8%
HELLA Alternator 14 V / 33 A, without belt pulley, Case IH 433 - 940
HELLA
Charging current (A): 33 | Nominal voltage (V): 14 | Additional information: Without pulley | Nominal values (V / A): 14 / 33 More
Charging current (A): 33 | Nominal voltage (V): 14 | Additional inform...
€358,83 €296,55 €276,46 €228,48
You save 23%
FEBI Fuel filter WK842
€19,60 €16,20 €8,47 €7,00
You save 57%
MAHLE Gear reduction starter 12 V, 3,2 kW, 11 teeth, Ø 89 mm, flange 25 mm
€612,77 €506,42 €367,01 €303,31
You save 40%
Starter motor 12 V, 3,1 kW, 11 teeth, 256,5 mm, Ø 89 mm
€297,93 €246,22 €274,10 €226,53
You save 8%
Universal joint 30 x 83 mm, 1x outer lubrication / centralised lubrication
A: 30 mm. B: 83 mm. Universal joint size: . Lubrication system: 1 x external lubrication/centralised lubrication. More
A: 30 mm. B: 83 mm. Universal joint size: . Lubrication system: 1 x ex...
€57,80 €47,77 €53,18 €43,95
You save 8%
Thermostat Ø 54 mm, 82 °C Case IH
Ø: 54 mm. Temperature: 82 °C. More
Ø: 54 mm. Temperature: 82 °C.
€27,28 €22,54
Gasket set lower Case IH 474-884, Series 32-4240, Hydro 84
Additional information: Without cylinder liner gasket set. Menke no.: 59577. More
Additional information: Without cylinder liner gasket set. Menke no.: ...
€64,36 €53,19 €59,21 €48,93
You save 8%
Intake plate with pressure continuation 250 bar, 40 l/min, M18 x 1,5 Case IH
Technical data: Max. operating pressure: 250 bar, Nominal flow rate: max. 40 l/min., Tightening torque: 30 Nm, Connections: M18 x 1.5, Dimensions: 90 ... More
Technical data: Max. operating pressure: 250 bar, Nominal flow rate: m...
€391,14 €323,26 €359,85 €297,40
You save 8%
End plate steering valve 210 bar, 40 l/min, 80 x 10 x 70 mm Case IH
Technical data: Max. operating pressure: 210 bar, Nominal flow rate: max. 40 l/min., Tightening torque: 30 Nm, Dimensions: 80 x 10 x 70 mm. More
Technical data: Max. operating pressure: 210 bar, Nominal flow rate: m...
€98,74 €81,60 €90,84 €75,08
You save 8%
Cobo Indicator/position light 84 x 84 x 51 mm, P21W, C5W left / right
Cobo
Bulb: 12V21WK / P21W, 12V5WS / C5W. Colour: Yellow, white. Connection: Blade terminal connection. Width: 84 mm. Form: Square. Height: 84 mm. Dimension... More
Bulb: 12V21WK / P21W, 12V5WS / C5W. Colour: Yellow, white. Connection:...
€34,28 €28,33 €31,54 €26,06
You save 8%
Start safety switch M12 x 1, cable 300 mm Case IH 440 - 940
Version: Make contact (contact function) Thread: M12 x 1 Connection cable 300 mm long More
Version: Make contact (contact function) Thread: M12 x 1 Connection ca...
€115,66 €95,59 €106,41 €87,94
You save 8%
SACHS Double clutch DuT 228/290 41 x 45 mm, 25 splines organic Case IH
SACHS
Dimensions (mm): 41 x 45 25 grooves | Material specifications: Organic clutch lining More
Dimensions (mm): 41 x 45 25 grooves | Material specifications: Organic...
€995,41 €822,65 €915,78 €756,84
You save 8%
SACHS Clutch plate 290, 22 x 25 mm, 13 splines organic Case IH
SACHS
Material specifications: Organic clutch lining | Dimensions (mm): 22 x 25 13 grooves More
Material specifications: Organic clutch lining | Dimensions (mm): 22 x...
€396,72 €327,87 €364,98 €301,64
You save 8%
Scharmüller Drawbar frame 59,7 kN, rail 330 mm, guide 32 mm, pin Ø 25 mm
Scharmüller
Guide width (mm): 32 | D-value (kN): 59,7 | Version: Prepared for drawbar | Load capacity (kg): 2500 | Detent pin Ø (mm): 25 | Rail width (mm): 330 |... More
Guide width (mm): 32 | D-value (kN): 59,7 | Version: Prepared for draw...
€1.074,22 €887,79 €1.038,28 €858,08
You save 3%
Starter switch 12 / 24 V, 7 blade terminals, M26 x 1,5, 2 keys
Version: Operating voltage: 12 V/24 V 7 blade terminals (6.3 x 0.8 / 9.5 x 1.2 mm) Locking cylinder with water protection 2 keys (type A 14607) Number... More
Version: Operating voltage: 12 V/24 V 7 blade terminals (6.3 x 0.8 / 9...
€76,91 €63,56 €70,76 €58,48
You save 8%
LUK Thrust bearing 65 x 101,6 x 17 mm Case IH, Lindner
LUK
Dimensions (mm): 65 x 101.6 x 17 More
Dimensions (mm): 65 x 101.6 x 17
€150,99 €124,79 €138,91 €114,80
You save 8%
LUK Clutch plate 290TDCN 22 x 25 mm, 13 splines, Case IH 633 - 940
LUK
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Sintered clutch lining More
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Sintere...
€469,20 €387,77 €431,66 €356,75
You save 8%
Clutch plate 290 organic, 22 x 25 mm, 13 splines Case IH
Additional information: Made in Germany | Dimensions (mm): 22 x 25 13 grooves | Material specifications: Organic clutch lining More
Additional information: Made in Germany | Dimensions (mm): 22 x 25 13 ...
€257,35 €212,69 €236,76 €195,67
You save 8%
Double clutch DuT 228/290 41 x 45 mm, 25 spline, organic
Dimensions (mm): 41 x 45 25 grooves | Flywheel dimension (mm): 40 (tief) | Material specifications: Organic clutch lining | Additional information: Ma... More
Dimensions (mm): 41 x 45 25 grooves | Flywheel dimension (mm): 40 (tie...
€569,02 €470,26 €523,50 €432,64
You save 8%
Guide bearing bush 22,3 x 28,6 x 25,4 mm Case IH 323-940, D 320-D 326
Dimensions (mm): 22.3 x 28.6 x 25.4 More
Dimensions (mm): 22.3 x 28.6 x 25.4
€58,04 €47,97 €53,40 €44,13
You save 8%
Alternator 14 V, 33 A, flange 56 mm Case IH, Goldoni
Direction of rotation: ↻ | Installation angle (°): r 60 | Flange size (mm): 56,0 | Mounting L / d / R (mm): 56,0 / 8,2 / 86,0 | Pulley spacing (mm)... More
Direction of rotation: ↻ | Installation angle (°): r 60 | Flange si...
€141,48 €116,93 €130,16 €107,57
You save 8%
FEBI Alternator 14 V / 33 A, form B, flange 56,0 mm
FEBI
To fit as: Case IH, Goldoni More
To fit as: Case IH, Goldoni
€356,37 €294,52 €121,86 €100,71
You save 66%
FEBI Safety cartridge secondary air filter CF 600, AF 4521
€64,73 €53,50 €28,88 €23,87
You save 55%
Ball joint 95 mm, M14 x 1,5, M20 x 1,5 L, taper 16,2 - 18,2 mm
A: 95 mm. C: M14 x 1,5 mm. D: M20 x 1,5 L mm. E: 16,2 mm. F: 18,2 mm. Taper: 16,2 - 18,2 mm. More
A: 95 mm. C: M14 x 1,5 mm. D: M20 x 1,5 L mm. E: 16,2 mm. F: 18,2 mm. ...
€42,53 €35,15 €39,13 €32,34
You save 8%
Side plate gasket engine block Case IH
€35,47 €29,31 €32,63 €26,97
You save 8%
Stabilizer strut 390 - 640 mm, 25 x 3 mm, 19 mm Case IH
d: 19 mm. h: 45 mm. D: 25 x 3 mm. L: 390 - 640 mm. Dimensions: Length = 390-640 mm. Installation location: links und rechts. More
d: 19 mm. h: 45 mm. D: 25 x 3 mm. L: 390 - 640 mm. Dimensions: Length ...
€288,51 €238,44 €265,43 €219,36
You save 8%
HELLA Rocker switch on/off 12/24 V, 16 A, 2 blade connections
HELLA
Version: On/off switch, 12 V/24 V, power rating: 16 A at 12 V, 8 A at 24 V, 2 blade terminals. To operate: Kippbetätigung. Switching function: ohne K... More
Version: On/off switch, 12 V/24 V, power rating: 16 A at 12 V, 8 A at ...
€21,31 €17,61
Holder for lamp base
To fit as: Case IH 433, 533, 633, 733, 833, 933, 440, 540, 640, 740, 840, 940, 946, 1046, 1246 More
To fit as: Case IH 433, 533, 633, 733, 833, 933, 440, 540, 640, 740, 8...
€51,20 €42,31 €47,10 €38,93
You save 8%
Flasher unit electronic 12 V, 6 connections, with holder
Version: Power rating: 12 V / 2 + 1 + 1 / 8 x 21 W, Slim version, with bracket, with indicator light monitoring for commercial vehicles or tractors wi... More
Version: Power rating: 12 V / 2 + 1 + 1 / 8 x 21 W, Slim version, with...
€50,77 €41,96 €46,71 €38,60
You save 8%
Exhaust manifold IHC, Case IH 533-940
To fit as: Case IH 433, 533, 633, 733, 833, 933, 440, 540, 640, 740, 840, 940 More
To fit as: Case IH 433, 533, 633, 733, 833, 933, 440, 540, 640, 740, 8...
€157,07 €129,81 €144,50 €119,43
You save 8%
HELLA Bulb R10W 12 V, 10 W, BA15s - 10 pieces
HELLA
Type: R10W | Voltage (V): 12 | Socket: BA15s | Bulb: Konventionell | Power (watts): 10 More
Type: R10W | Voltage (V): 12 | Socket: BA15s | Bulb: Konventionell | P...
€18,94 €15,65
HELLA Lens indicator/position light P21W/C5W, with screws - 2 pieces
HELLA
Version: With bolts | Light function: with position light, with turn signal light | Test mark: E1 42712, ECE | Bulb: P21W, C5W | Installation location... More
Version: With bolts | Light function: with position light, with turn s...
€33,15 €27,40
LUK Clutch kit disc-Ø 290 mm Case IH 433 - 940
LUK
Disc Ø (mm): 290 | Contents: Pressure plate 458229000112, clutch plate 458329000116 More
Disc Ø (mm): 290 | Contents: Pressure plate 458229000112, clutch plat...
€1.444,35 €1.193,68 €1.328,80 €1.098,18
You save 8%
Clutch plate 290 MCC lining, 22 x 25 mm, 13 splines Case IH
Dimensions (mm): 22 x 25 13 grooves | Material specifications: MCC clutch lining | Additional information: Made in Germany More
Dimensions (mm): 22 x 25 13 grooves | Material specifications: MCC clu...
€559,32 €462,25 €514,57 €425,27
You save 8%
LUK Clutch kit disc-Ø 290 mm Case IH 433 - 940
LUK
Disc Ø (mm): 290 | Contents: Pressure plate 458229000111, clutch plate 458329000111 More
Disc Ø (mm): 290 | Contents: Pressure plate 458229000111, clutch plat...
€1.331,11 €1.100,09 €1.224,62 €1.012,08
You save 8%
LUK Clutch plate 290TZFN 22 x 25 mm, 13 splines, Case IH 433 - 940
LUK
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Organic clutch lining More
Dimensions (mm): 22 x 25 13 grooves | Material specifications: Organic...
€380,36 €314,35 €349,93 €289,20
You save 8%
LUK Double clutch 228/290TGU sintered 41 x 45 mm, 25 splines Case IH
LUK
Dimensions (mm): 41 x 45 25 grooves | Material specifications: Sintered clutch lining More
Dimensions (mm): 41 x 45 25 grooves | Material specifications: Sintere...
€1.102,91 €911,50 €1.014,68 €838,58
You save 8%
Elring Cylinder head gasket set with valve stem seal engine D-206, D-239, D-268
Elring
Additional information: With valve stem seal More
Additional information: With valve stem seal
€202,15 €167,07 €185,98 €153,70
You save 8%
FEBI Mirror wide-angle right / left 314 x 228 mm, rod Ø 14 - 22 mm
FEBI
Tractor types: Case IH Maxxum 5120, 5130, 5140, 5150 as of Bj. 95 More
Tractor types: Case IH Maxxum 5120, 5130, 5140, 5150 as of Bj. 95
€115,03 €95,07 €98,75 €81,61
You save 14%
FEBI Mirror 250 x 155 mm, unheated, rod Ø 10, 15, 18 mm
FEBI
Tractor type: Case IH 433, 533, 633, 733, 833, 933, 3210, 3220, 3230, 4210, 4220, 4230, 4240, 440, 540, 640, 740, 743, 644, 744, 745 S, 840, 844, 844 ... More
Tractor type: Case IH 433, 533, 633, 733, 833, 933, 3210, 3220, 3230, ...
€69,49 €57,43 €59,66 €49,31
You save 14%
Ball joint 101 mm, taper 16,2 - 18,3 mm, M14 x 1,5, M20 x 1,5
A: 101 mm. C: M14 x 1,5 mm. D: M20 x 1,5 mm. E: 16,2 mm. F: 18,3 mm. Taper: 16,2 - 18,3 mm. More
A: 101 mm. C: M14 x 1,5 mm. D: M20 x 1,5 mm. E: 16,2 mm. F: 18,3 mm. T...
€39,32 €32,50 €36,17 €29,90
You save 8%
Showing 49 - 96 of 299

Case IH 740 parts, also listed as IHC 740

Plenty of these tractors still wear an IHC 740 badge, and the type plate may well say the same. The more than 250 parts on this page fit the Case IH 740 whichever name is on the bonnet. They are new parts from GRANIT, HELLA, Scharmüller, LUK and FEBI.

Steering, clutch and driveline

The steering side covers ball joints and steering valves. A steering valve that leaks internally lets the wheel creep back and makes loader work heavy going. When fitting a new valve, flush the lines and refill with fresh oil so dirt from the old oil does not go straight into the new unit. Further back you will find clutch plates, double clutch pressure plates and universal joints for the drive shafts.

Grease universal joints until fresh grease appears at all four bearing seals. If one side stays dry, the passage is blocked and that needle bearing is running without lubrication, which is the usual reason a joint fails early.

Engine sealing and cooling

For the engine there are gaskets, O-rings for the feed pump, sealing rings and a crankshaft seal set. Cooling is covered by radiator hoses and a thermostat gasket. Replace a hose that feels soft or crunchy when you squeeze it, even if it is not leaking yet, and fit new clamps at the same time because old ones are often stretched. At the thermostat housing, scrape off every trace of the old gasket with a flat scraper, or the new one will weep as well.

Switches, lights and towing

Rocker switches and indicator lenses, partly from HELLA, cover the electrics. Gas struts for the windscreen frame make the screen stay open again, and drawbars from Scharmüller and GRANIT handle the towing side. A rocker switch that only works now and then usually has burnt contacts, so replace it before it lets you down at the wrong moment.

Checking the fit and related models

Read the type plate first and note whether it says Case IH or IHC 740. For steering valves and clutch plates, which look very similar, the reference number on the part you removed is the safest check. Write it down before you clean the part, because stamped figures soon vanish under rust and paint. Compare it with the numbers shown with the item before you order.

Related models from the same family have their own pages with the parts that fit them:

To browse the whole brand, go to Case IH parts.
