John Deere 3120 tractor parts & technical data

Keep your John Deere 3120 running with more than 250 parts that fit. Alongside electrics and lighting, this page offers a wide choice of classic tractor parts.

268 parts found for John Deere 3120
Show:
GRAMMER Tractor seat mechanical suspension PVC 480 mm, track width 187 mm
GRAMMER
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Optional. Track gauge: 187 mm. Seat width: 480 mm. Joystick console: No. Restraint ... More
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Opt...
€333,37 €275,51
Alternator 14 V / 65 A, form B, flange 56,0 mm, pulley-Ø 68,0 mm
To fit as: Case IH, Claas, Deutz-Fahr, Fendt, Mercedes-Benz, Steyr, Zetor More
To fit as: Case IH, Claas, Deutz-Fahr, Fendt, Mercedes-Benz, Steyr, Ze...
€183,88 €151,97 €169,17 €139,81
You save 8%
Control unit complete 1x da John Deere series 20, 30, 40, 50
€899,70 €743,55 €827,72 €684,07
You save 8%
BOSCH Start switch pull switch with gear change knob, Ø 10,5 mm
BOSCH
Version: Galvanised steel housing, including black control button, Power rating:, 50 A / 12 V, (terminals 17, 19), 27 A / 24 V (terminals 17, 19), 12 ... More
Version: Galvanised steel housing, including black control button, Pow...
€69,57 €57,50 €58,97 €48,74
You save 15%
Replacement key lock number 14610 - 2 pieces
Locking number: 14610. Version: Locking no. 14610. More
Locking number: 14610. Version: Locking no. 14610.
€15,70 €12,98
Perkins Fuel filter outer-Ø 88 mm, inner-Ø 18 mm, height 72 mm
Perkins
Outer Ø: 88 mm. Inner Ø: 18 mm. Height: 72 mm. More
Outer Ø: 88 mm. Inner Ø: 18 mm. Height: 72 mm.
€20,09 €16,60
MAHLE Alternator 14 V / 70 A, flange 56 mm, form B John Deere
MAHLE
Pulley Ø (mm): 87.0 | Belt width (mm) / type: 15,2 | Mounting L / d / R (mm): 56,0 / 8,2 / 86,0 | Form: B | Nominal voltage (V): 14 | Flange size (mm... More
Pulley Ø (mm): 87.0 | Belt width (mm) / type: 15,2 | Mounting L / d /...
€249,29 €206,02 €149,31 €123,40
You save 40%
GRAMMER Seat Compacto Basic S MSG83/511, mechanical, PVC, 400 mm
GRAMMER
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Optional. Track gauge: 227 mm. Seat width: 400 mm. Fore/aft isolator: Optional. Sea... More
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Opt...
€1.054,87 €871,79 €970,48 €802,05
You save 8%
Ball for gear shift linkage Ø 12,7 mm, 1/2 inch, DIN 5401
Ø Dw: 12,7 mm. Ø Dw: 1/2 inches. DIN: DIN 5401. More
Ø Dw: 12,7 mm. Ø Dw: 1/2 inches. DIN: DIN 5401.
€4,26 €3,52
MAHLE Alternator 14 V / 120 A, flange 56 mm, form B, W-connection
MAHLE
Nominal voltage (V): 14 | Installation angle (°): 0 | Flange size (mm): 56,0 | Additional information: Dust-tight, with fan, with W connection | Nomi... More
Nominal voltage (V): 14 | Installation angle (°): 0 | Flange size (mm...
€522,64 €431,93 €313,03 €258,70
You save 40%
HELLA Alternator 14 V, 33 A Case IH, Deutz-Fahr, John Deere
HELLA
Nominal values (V / A): 14 / 33 | Charging current (A): 33 | Nominal voltage (V): 14 | Additional information: Without pulley More
Nominal values (V / A): 14 / 33 | Charging current (A): 33 | Nominal v...
€354,91 €293,31 €273,45 €225,99
You save 23%
Handle John Deere
Brand: John Deere. More
Brand: John Deere.
€8,38 €6,92
Sealing ring for injection nozzle Ø 13,6 x 9,3 mm, height 5,1 mm
Dimensions: Height 5.1, Outer Ø 13.6, Inner Ø 9.3 mm. Menke no.: 221605. More
Dimensions: Height 5.1, Outer Ø 13.6, Inner Ø 9.3 mm. Menke no.: 221...
€2,51 €2,08
Plunger pump 23 cm³/rpm. John Deere 940-3650
for tractors with hydraulic steering More
for tractors with hydraulic steering
€922,04 €762,02 €848,28 €701,06
You save 8%
HELLA Indicator/position light 12 V, R21W/C5W, yellow/white - 2 pieces
HELLA
Bulb: 12V5WS / C5W 12V21WK / R21W | Version: For front mounting, horizontal, yellow indicator light, white position light, with 2 holes for M4 fixing ... More
Bulb: 12V5WS / C5W 12V21WK / R21W | Version: For front mounting, horiz...
€47,11 €38,94
LUK Thrust bearing 55 x 90,5 x 22 mm
LUK
Dimensions (mm): 55 x 90.5 x 22 More
Dimensions (mm): 55 x 90.5 x 22
€192,19 €158,83 €176,81 €146,13
You save 8%
Control unit complete 1x sa John Deere series 20, 30, 40, 50
€568,99 €470,24 €523,47 €432,62
You save 8%
GRAMMER Seat Compacto Basic M MSG83/521, mechanical, PVC, 450 mm
GRAMMER
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Optional. Track gauge: 225 mm. Seat width: 450 mm. Fore/aft isolator: Optional. Res... More
Suspension: Mechanical. Upholstery type: PVC. Seat contact switch: Opt...
€1.022,73 €845,23 €940,91 €777,61
You save 8%
Valve head steering valve EW John Deere 830 - 3650
€398,35 €329,21 €366,48 €302,88
You save 8%
Alternator 14 V / 35 A, flange 56 mm, pulley Ø 68 mm, W-connection
Additional information: with W connection | Mounting L / d / R (mm): 56,0 / 8,3 / 86,0 | Installation angle (°): l 60 | Charging current (A): 35 | Fo... More
Additional information: with W connection | Mounting L / d / R (mm): 5...
€122,13 €100,93 €112,36 €92,86
You save 8%
Alternator 14 V, 35 A, flange 56 mm, pulley Ø 68 mm, form B
Pulley spacing (mm): 21,0 | Mounting L / d / R (mm): 56,0 / 8,3 / - | Flange size (mm): 56,0 | Nominal voltage (V): 14 | Belt tension hole Ø / R (mm)... More
Pulley spacing (mm): 21,0 | Mounting L / d / R (mm): 56,0 / 8,3 / - | ...
€142,88 €118,08 €131,45 €108,64
You save 8%
MAHLE Alternator 14 V / 95 A, flange 56 mm, pulley-Ø 87 mm
MAHLE
Mounting L / d / R (mm): 56.0 / 8.2 / 86.0 | Installation angle (°): 0 | Charging current (A): 95 | Mounting hole Ø / R (mm): 8.2 / 86.0 | Additiona... More
Mounting L / d / R (mm): 56.0 / 8.2 / 86.0 | Installation angle (°): ...
€453,45 €374,75 €271,58 €224,45
You save 40%
HELLA Seal for main headlights
HELLA
To fit: Main headlight More
To fit: Main headlight
€26,04 €21,52
Alternator 14 V / 33 A, flange 27 mm John Deere, Lindner, Massey Ferguson
Direction of rotation: ↻ | Belt tension hole Ø / R (mm): M6 / 83,0 | Nominal voltage (V): 14 | Pulley Ø (mm): 80,0 | Nominal values (V / A): 14 / ... More
Direction of rotation: ↻ | Belt tension hole Ø / R (mm): M6 / 83,0 ...
€137,22 €113,41 €126,24 €104,33
You save 8%
Headlight right round 12 V, tube-Ø 24 mm John Deere
Bulb: 12V60/55WH4 12V4WK / T4W | Light function: Abblendlicht, Fernlicht, Positionslicht, Standlicht | Additional information: Fassung für Glasssocke... More
Bulb: 12V60/55WH4 12V4WK / T4W | Light function: Abblendlicht, Fernlic...
€104,55 €86,41 €96,19 €79,49
You save 8%
FEBI Alternator 14 V / 33 A, form B, flange 27,0 mm, pulley-Ø 80,0 mm
FEBI
To fit as: Lindner, Massey Ferguson More
To fit as: Lindner, Massey Ferguson
€25,53 €21,10 €13,18 €10,89
You save 48%
Tank sender metal tank
Version: Metal tank. More
Version: Metal tank.
€64,28 €53,12 €59,14 €48,87
You save 8%
Start switch 12 V pull switch, built-in Ø 10,5 mm, 0-1-2
Menke no.: 248055 | Switching stages: 0-1-2 | Version: Pull switch Protected against dripping water when installed vertically Mounting opening Ø 10.5... More
Menke no.: 248055 | Switching stages: 0-1-2 | Version: Pull switch Pro...
€60,35 €49,88
Scharmüller Forced steering K50, 2 ton, 250 mm, left John Deere
Scharmüller
Steering power (t): 2 | Colour: Black | Lock: K50 | Assembly notes: Anticlockwise | Description: Approved for steering forces up to 20 kN (2 t) | Conn... More
Steering power (t): 2 | Colour: Black | Lock: K50 | Assembly notes: An...
€754,30 €623,39 €693,96 €573,52
You save 8%
Single clutch GN 300 41,5 x 44,8 mm, 27 splines John Deere
Dimensions (mm): 41.5 x 44.8, 27 grooves | Flywheel dimension (mm): 21,6 | Additional information: Made in Germany More
Dimensions (mm): 41.5 x 44.8, 27 grooves | Flywheel dimension (mm): 21...
€692,79 €572,55
Pilot bearing 15 x 35 x 11 mm John Deere 820 - 3650
Dimensions (mm): 15 x 35 x 11 More
Dimensions (mm): 15 x 35 x 11
€5,83 €4,81
Alternator 12 V / 70 A, flange 56 mm, pulley Ø 87 mm, John Deere
Pulley Ø (mm): 87 | Flange size (mm): 56,0 | Installation angle (°): 0 | Nominal voltage (V): 12 | Belt tension hole Ø / R (mm): M8 / 84,5 | Mounti... More
Pulley Ø (mm): 87 | Flange size (mm): 56,0 | Installation angle (°):...
€192,51 €159,10 €177,11 €146,37
You save 8%
As hydraulic pump John Deere 840 - 3650
€125,88 €104,03 €115,81 €95,71
You save 8%
HELLA Alternator 14 V / 85 A, without belt pulley, Fendt, John Deere
HELLA
Nominal values (V / A): 14 / 85 | Charging current (A): 85 | Nominal voltage (V): 14 | Additional information: Without pulley More
Nominal values (V / A): 14 / 85 | Charging current (A): 85 | Nominal v...
€429,84 €355,24 €331,19 €273,71
You save 23%
MAHLE Starter motor 12 V, 3,0 kW, 10 teeth, Ø 82,5 mm, 246 mm, clockwise
€395,10 €326,53 €236,65 €195,58
You save 40%
Parts set hydraulic pump John Deere 830-3650
€291,67 €241,05 €268,34 €221,77
You save 8%
Start switch 12 V, Ø 13,5 mm, without push button
Version: 12 V with blade terminal, 0: off, 1: preheat, 2: start, Mounting opening Ø 13.5 mm / 3 mm, control button 50712034. More
Version: 12 V with blade terminal, 0: off, 1: preheat, 2: start, Mount...
€58,78 €48,58 €54,08 €44,69
You save 8%
Indicator switch left and right, 3 blade connections
Version: Functions: centre position off, indicator left and right, 3 blade terminals. More
Version: Functions: centre position off, indicator left and right, 3 b...
€73,36 €60,63 €67,49 €55,78
You save 8%
Parts set hydraulic pump John Deere 830 - 3650
€106,31 €87,86 €97,81 €80,83
You save 8%
External plate 2,3 mm, inner 99 mm, outer 143 mm, 10 teeth John Deere
Version: Thickness: 2.3 mm Inner: 99 mm Outer: 143 mm, 10 splines More
Version: Thickness: 2.3 mm Inner: 99 mm Outer: 143 mm, 10 splines
€26,06 €21,54
Prestolite Alternator 12 V, 70 A, pulley Ø 69 mm, belt 6pK
€252,98 €209,07 €232,74 €192,35
You save 8%
Starter motor 12 V, 2,7 kW, 10 teeth, Ø 82,5 mm, clockwise
€351,67 €290,64 €323,54 €267,39
You save 8%
HELLA Starter motor 12 V, 2,9 kW, 10 teeth, Ø 82 mm, clockwise
€560,36 €463,11 €431,75 €356,82
You save 23%
PTO shaft end piece John Deere 3030-3650
€309,60 €255,87 €284,83 €235,40
You save 8%
Set of parts feed pump John Deere engine 3164-6359
€52,55 €43,43 €48,35 €39,96
You save 8%
Single clutch 320GDVM 41,5 x 44,8 mm, 27 splines John Deere
Dimensions (mm): 41.5 x 44.8, 27 grooves | Flywheel dimension (mm): 21,6 | Additional information: Made in Germany More
Dimensions (mm): 41.5 x 44.8, 27 grooves | Flywheel dimension (mm): 21...
€630,05 €520,70 €579,65 €479,05
You save 8%
Showing 1 - 48 of 268

John Deere 3120 parts

An old John Deere 3120 tends to tell you about its electrics first: a slow crank on a cold morning or a charge light that stays on. The more than 250 new replacement parts on this page for the John Deere 3120 cover that and a good deal more, from GRANIT, HELLA, MAHLE, GRAMMER and LUK.

Matching by part number

John Deere part numbers are often included in the product description, so the number on your old part or in the workshop manual is the fastest way in. The identification plate confirms that the tractor is a 3120. When matching an alternator, compare the flange and pulley, and for a starter motor check the number of pinion teeth and the direction of rotation.

Parts for the 3120

  • Charging and starting: alternators, starter motors and gear reduction starters.
  • Fuel system: feed pumps with their seals, injector sealing rings and stop cables.
  • Engine and hydraulics: gaskets such as the lift housing gasket, and O-rings including the one for the master brake cylinder.
  • Clutch: single clutches.
  • Body and lights: headlights, bonnet springs, V-belts and push button switches.

Check the cables before the starter

Before replacing a starter motor, go over the battery, the earth strap and the terminals on the starter itself. A corroded earth connection produces exactly the same symptoms as a worn starter. With someone turning the key, put a meter across the starter terminals and watch the reading. If it drops a long way with a fully charged battery, the resistance is in the cabling. A gear reduction starter draws less current and is worth considering if the engine turns over reluctantly in winter.

Fuel, lights and belts

If the engine is hard to start after standing overnight or dies under load, look at the feed pump. A leaking seal lets air into the fuel system, and that shows up straight away at start-up. Replace the seal or the complete pump and bleed the system with the hand primer until fuel comes through without bubbles. If the engine no longer stops cleanly, the stop cable has often stretched or become stiff. Adjust a new cable so the stop lever travels all the way.

A headlight that glows dimly often has a poor earth or a tarnished reflector. Check V-belt tension with your thumb as well.

The 20 series

The John Deere 4520 from the same series has its own page too, so if you run both, look up each one separately. The full list of models is under John Deere parts.
