John Deere 5100R tractor parts & technical data

More than 450 parts for the John Deere 5100R from the 5R/5RN range, from lighting and electrics to trailer couplings and plenty of other items.

494 parts found for John Deere 5100R
Show:
PROBOSS Seat PROBOSS AS4550 air suspended 12 V, 550 mm, seat heater
PROBOSS
On-board voltage: 12 V. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 550 mm. Joystick console: Optional. S... More
On-board voltage: 12 V. Upholstery type: Fabric. Seat contact switch: ...
€1.867,44 €1.543,34 €1.839,59 €1.520,32
You save 1%
GRAMMER Tractor seat air suspended Maximo COMFORT Plus fabric, seat width 530 mm
GRAMMER
Super comfort seat with air suspension and 12V compressor. APS: automatic positioning system. Armrests height adjustable and folding. Weight, height a... More
Super comfort seat with air suspension and 12V compressor. APS: automa...
€1.657,67 €1.369,98
LED main headlight 12/24 V, 168 x 107 x 81,5 mm, H4
Voltage range (V): 10 - 30 | Nominal voltage (V): 12 / 24 | Connection: H4 | Power consumption (W): 55 | Light colour (K): 6000 | Housing material: Al... More
Voltage range (V): 10 - 30 | Nominal voltage (V): 12 / 24 | Connection...
€124,74 €103,09 €114,76 €94,84
You save 8%
HELLA Beacon KL 600 H1 orange, Ø 135 mm, push-on pin
HELLA
Mounting type: Pipe socket | Bulb: H1 | Power consumption (W): 55 | Bulbs included: Yes | Type: Halogen | Light function: Rotating | Colour: Yellow | ... More
Mounting type: Pipe socket | Bulb: H1 | Power consumption (W): 55 | Bu...
€145,20 €120,00 €139,85 €115,58
You save 4%
LED main headlight round 133 x 166 x 84 mm, H4, 12/24 V
Protection class: IP69K | Connection: H4 | EMC: CISPR 25 class 3 | Test mark: ECE R148, ECE R149 | Light function: Dipped beam, full beam, side light,... More
Protection class: IP69K | Connection: H4 | EMC: CISPR 25 class 3 | Tes...
€112,54 €93,01 €103,54 €85,57
You save 8%
GRAMMER Tractor seat Maximo Dynamic DDS MSG95AL/741 air suspended Steyr
GRAMMER
Suspension: Air suspension. Upholstery type: Fabric. Track gauge: 260 mm. Seat width: 550 mm. Side horizontal suspension: Yes. Fore/aft isolator: Yes.... More
Suspension: Air suspension. Upholstery type: Fabric. Track gauge: 260 ...
€2.776,81 €2.294,88
HELLA Headlight H4 12 V angular built-in John Deere
HELLA
Type: Einbau | Form: eckig | Bulb: H4 | Version: Universal | Nominal voltage (V): 12 More
Type: Einbau | Form: eckig | Bulb: H4 | Version: Universal | Nominal v...
€31,44 €25,98 €30,27 €25,02
You save 4%
Installation cable mini-contact plug 1 m
Length: 1 m. Technical data: Closure: 1.0 m. Reference no.: 1762510. More
Length: 1 m. Technical data: Closure: 1.0 m. Reference no.: 1762510.
€171,07 €141,38 €157,38 €130,07
You save 8%
GRAMMER Tractor seat air suspended fabric, 480 mm, 12 V, MSG95G/721
GRAMMER
Comfort seat with air suspension and 12V compressor. Armrests, height adjustable and foldable. Weight adjustment, height adjustment 60 mm and Longitud... More
Comfort seat with air suspension and 12V compressor. Armrests, height ...
€1.051,50 €869,01
Wabco Connector head M22 x 1,5 black aluminum with valve, 8 bar
Wabco
Operating pressure max. (bar): 8 | Version: Black, aluminium, with valve, for vehicles | Vehicle/application: For single-line brake, towing vehicle | ... More
Operating pressure max. (bar): 8 | Version: Black, aluminium, with val...
€96,48 €79,74 €88,76 €73,36
You save 8%
Tank cap with ventilation, thread Ø 60 / 64 mm, tank collar Ø 65 mm
Thread Ø mm: 60 / 64. Filler neck Ø: 65 mm. More
Thread Ø mm: 60 / 64. Filler neck Ø: 65 mm.
€29,04 €24,00
MAHLE Alternator 14 V / 150 A, flange 56 mm, form B, compact, dust-tight
MAHLE
Mounting hole Ø / R (mm): 10,2 / 90,0 | Nominal values (V / A): 14 / 150 | Belt width (mm) / type: - | Form: B | Charging current (A): 150 | Nominal ... More
Mounting hole Ø / R (mm): 10,2 / 90,0 | Nominal values (V / A): 14 / ...
€561,20 €463,80 €336,12 €277,79
You save 40%
Pump screenwash tank 12 V, intake-Ø 6,3 mm, press-Ø 6,3 mm
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system. Voltage: 12 V. Connection type: 2 x 6,3. Operating mode: electric. More
Intake Ø: 6.3 mm. Outlet Ø: 6.3 mm. To fit: Windscreen washer system...
€35,49 €29,33 €32,65 €26,98
You save 8%
Battery cut-off switch starter relay 12 V, 300 A
Version: 12 V / 300 A With screw and blade terminal connections. More
Version: 12 V / 300 A With screw and blade terminal connections.
€321,87 €266,01 €296,12 €244,73
You save 8%
Sauermann Trailer coupling hitch pin 38 mm, rail 330 mm, John Deere green
Sauermann
Detent pin Ø (mm): 25 | Colour: Green | Connecting pin (mm): 38 | Rail width (mm): 330 | Drawbar eye: DIN 11026, 11043, 74054 (ISO 8755) = 40 mm | D-... More
Detent pin Ø (mm): 25 | Colour: Green | Connecting pin (mm): 38 | Rai...
€1.181,86 €976,74 €1.087,31 €898,60
You save 8%
Replacement key lock number 14610 - 2 pieces
Locking number: 14610. Version: Locking no. 14610. More
Locking number: 14610. Version: Locking no. 14610.
€15,70 €12,98
GRAMMER Tractor seat Maximo Basic MSG85/721
GRAMMER
Suspension: Mechanical. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 480 mm. Joystick console: Optional. S... More
Suspension: Mechanical. Upholstery type: Fabric. Seat contact switch: ...
€1.362,65 €1.126,16 €1.303,64 €1.077,39
You save 4%
Walterscheid Drawbar manual rail width 330 mm, coupling pin 31 mm, 92 kN
Walterscheid
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 31 mm. Load capacity: 2000 kg. D-value: 92 kN. Colour: Black. Descriptio... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.104,81 €913,07 €873,47 €721,88
You save 21%
Connector head M22 x 1,5 red, supply line, vehicle
Additional information: - For dual-line brake systems for vehicles - Connect the air brake system of the truck or tractor unit with the brake system o... More
Additional information: - For dual-line brake systems for vehicles - C...
€25,70 €21,24
GRAMMER Tractor seat Maximo Comfort Plus MSG95A/731 John Deere
GRAMMER
To fit: John Deere. Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Yes. Track gauge: 260 mm. Seat width: 530 mm. Joystick c... More
To fit: John Deere. Suspension: Air suspension. Upholstery type: Fabri...
€2.381,22 €1.967,95
Oil pressure switch engine 1/8" NPT, 0,4 - 0,7 bar, open function
Version: Thread: 1/8" NPT, Measuring range: 0.4 - 0.7 bar, normally closed, Blade terminal. More
Version: Thread: 1/8" NPT, Measuring range: 0.4 - 0.7 bar, normally cl...
€11,46 €9,47
Wabco Trailer control valve 8 bar, M22 x 1,5, NW 10 mm
Wabco
Working pressure (bar): 8 | Connection: M22 x 1.5 | Nominal width (mm): 10 More
Working pressure (bar): 8 | Connection: M22 x 1.5 | Nominal width (mm)...
€630,05 €520,70 €579,65 €479,05
You save 8%
ROCKINGER Drawbar ball 80, rail width 330 mm, guide 32 mm, 4000 kg
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 105 kN. Colour: John Deere green. Description: Manual b... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.256,32 €1.038,28 €967,98 €799,98
You save 23%
Sauermann Cover trailer coupling Ø 8,2 mm HS 1700-1KUD / 3KUD 330 mm
Sauermann
Description: Ø 8.2 mm More
Description: Ø 8.2 mm
€94,98 €78,50 €87,38 €72,22
You save 8%
ROCKINGER Drawbar without sensor rail 330 mm, coupling pin 38 mm, JD green
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 120,0 kN. Colour: JD green. Desc... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.013,32 €837,45 €780,74 €645,24
You save 23%
Walterscheid Ball hitch K80 330 / 25 / 32 mm, 2800 kg, 97,1 kN
Walterscheid
Quick height adjustment with rotation lock, load capacity up to 40 km/h 2800 kg, from 40 km/h 2,000 kg. More
Quick height adjustment with rotation lock, load capacity up to 40 km/...
€2.111,26 €1.744,84 €1.719,18 €1.420,81
You save 19%
LED work lights floodlight left 20 W, 121,4 x 116,5 x 111,2 mm
Light function: Floodlight | Light colour (K): 5500-5700 | Form: Rectangular | Cable length (mm): 180 | Effective luminous flux (lm): 2840 | Theoretic... More
Light function: Floodlight | Light colour (K): 5500-5700 | Form: Recta...
€99,52 €82,25 €91,56 €75,67
You save 8%
Connector head M16 x 1,5 red, supply line, vehicle
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, supply line | Menke no.: 55927 | Additional information: - For dual-line brake sys... More
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, su...
€24,88 €20,56
Sauermann Wear plate trailer coupling HS 1710-1KUD/3KUD
€179,80 €148,60 €165,42 €136,71
You save 8%
Wiper motor 105° John Deere
Angle (°): 105 More
Angle (°): 105
€186,91 €154,47 €171,96 €142,11
You save 8%
HELLA Alternator 14 V / 150 A, without belt pulley, 7,25 kg
HELLA
Nominal values (V / A): 14 / 150 | Charging current (A): 150 | Nominal voltage (V): 14 | Additional information: Without pulley More
Nominal values (V / A): 14 / 150 | Charging current (A): 150 | Nominal...
€649,71 €536,95 €500,59 €413,71
You save 23%
FEBI Cap John Deere 5620, 5720, 5820, 5080R, 5090R
FEBI
Cap John Deere 5620, 5720, 5820, 5080R, 5090R More
Cap John Deere 5620, 5720, 5820, 5080R, 5090R
€21,82 €18,03 €3,55 €2,93
You save 84%
Hinge cab door bottom left John Deere SE6010-6930 PR
Technical data: für Kabinentür, unten links. Menke no.: 221632. More
Technical data: für Kabinentür, unten links. Menke no.: 221632.
€82,01 €67,78 €75,45 €62,35
You save 8%
ROCKINGER Adapter plate rail width 330 mm, 93,6 kN, 2500 kg, 160 x 100 mm
ROCKINGER
Colour: Black | Hole pattern (mm): 160 x 100 | Guide width (mm): 32 | Detent pin Ø (mm): 25 | D-value (kN): 93,6 | Load capacity (kg): 2500 | Rail wi... More
Colour: Black | Hole pattern (mm): 160 x 100 | Guide width (mm): 32 | ...
€651,63 €538,54 €627,60 €518,67
You save 4%
Walterscheid Adapter plate rail width 330 mm, hole pattern 160 x 100 mm, M21
Walterscheid
Guide width (mm): 32 | Description: The coupling plate is a height-adjustable sliding plate that can only be operated in hitch supports with locking r... More
Guide width (mm): 32 | Description: The coupling plate is a height-adj...
€1.207,08 €997,59 €954,33 €788,70
You save 21%
BOSCH Micro relays 12 V / 30 - 20 A, 5-pin, 6,3 mm blade connection
BOSCH
Version: 12 V / 30 - 20 A Without bracket, 5-pin, blade terminal 6.3 mm More
Version: 12 V / 30 - 20 A Without bracket, 5-pin, blade terminal 6.3 m...
€11,20 €9,26
Wabco Pressure regulator afblaasdruk 8,1 bar, safety valve 12 bar, M22 x 1,5
Wabco
Control range: 0,6 +0,4 | Safety valve opening pressure (bar): 12 +2 | Pressure regulator cut-off pressure (bar): 8,1 ±0,2 | Connection: M22 x 1,5 | ... More
Control range: 0,6 +0,4 | Safety valve opening pressure (bar): 12 +2 |...
€547,98 €452,88 €504,14 €416,65
You save 8%
LED work lights spotlight 65 W, 166 x 115 x 95 mm John Deere
Theoretical luminous flux (lm): 5200 | Light colour (K): 6000 | Bulb: LED | Effective luminous flux (lm): 3800 | Dimensions W x H x D (mm): 166 x 115 ... More
Theoretical luminous flux (lm): 5200 | Light colour (K): 6000 | Bulb: ...
€103,79 €85,78 €95,49 €78,91
You save 8%
Crankshaft seal 55,4 x 84 x 8 mm John Deere 5075GL - 6195R
Outer Ø (mm): 84 | Width (mm): 8 | Inner Ø (mm): 55,4 More
Outer Ø (mm): 84 | Width (mm): 8 | Inner Ø (mm): 55,4
€34,99 €28,92
FEBI Multi-rib belt Powerband John Deere, Case IH, New Holland
FEBI
To fit as: John Deere More
To fit as: John Deere
€45,25 €37,40 €27,36 €22,61
You save 40%
INA Belt kit 8 ribs, 3308 mm John Deere
Starter motor with reduction 12 V, 3,4 kW, 10 teeth, 239 mm, Ø 82,5 mm
ROCKINGER Drawbar KS80 rail 330 mm, pin Ø 25 mm, 4000 kg, John Deere green
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 3000 kg. D-value: 100 kN. Colour: JD green. Technical data: Kugelkupplung... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.485,41 €1.227,61 €1.194,48 €987,17
You save 20%
Solenoid switch starter motor 12 V, 80 A, 3 schraubkontakt
Version: 12 V / 80 A, 3 screw connections. Additional information: Spulenwiderstand: 3.95-4.15 Temporärer Strom: 800 Amp. More
Version: 12 V / 80 A, 3 screw connections. Additional information: Spu...
€50,38 €41,64 €46,35 €38,31
You save 8%
GRAMMER Tractor seat air suspended Maximo Professional fabric, seat width 530 mm
GRAMMER
Super comfort seat with low-frequency air suspension and 12V compressor. APS: automatic positioning system. Armrests height adjustable and folding. Ad... More
Super comfort seat with low-frequency air suspension and 12V compresso...
€1.991,23 €1.645,64
Wiper motor angle 175° John Deere 5055E - 5820
€229,50 €189,67 €211,14 €174,50
You save 8%
Showing 1 - 48 of 494

Parts for the John Deere 5100R

The John Deere 5100R from the 5R series has more than 450 replacement parts on this page. They come from GRANIT and from makers including HELLA, Sauermann, MAHLE and GRAMMER, and they cover the engine, the electrics, the cab and the rear hitch.

Belts, and why the air conditioning matters

For the belt drive you will find single multi-rib belts and complete belt kits, including kits for tractors without air conditioning. Whether your tractor has air conditioning changes the belt routing, and so it decides which kit you need. Check that before ordering. Take a photo of how the belt runs over the pulleys and tensioner before you remove it, which saves a lot of guesswork when fitting the new one. While you are there, spin the tensioner pulley by hand. If it feels rough, replace it as well.

Starting, charging and lighting

Electrical parts include starter motors, gear reduction starters, alternators and sensors. A gear reduction starter has a reduction gearbox inside the housing, so it looks different from a conventional starter. Compare the housing, the flange and the number of pinion teeth with the unit on your tractor. Before condemning a starter, clean the battery terminals and check the earth cable, because a corroded connection makes a starter turn slowly in just the same way. For lighting there are headlights with dipped and main beam, and work lamps including spotlights and LED lamps.

Seals, cab and hitch

Around the engine there are O-rings for the fuel line, the air receiver gasket and other seals. A tired O-ring on a fuel line lets the system draw in air and the engine starts badly, so always fit new ones when you open a line. Inside the cab you will find seals for the door hinges and pull handles, gas struts and air suspended tractor seats. At the rear there are drawbars with a ball, and there are bushes for smaller repairs.

Use the type plate to confirm you have a 5100R. Many John Deere parts carry a reference number, which is the quickest way to make sure a new part fits. For a multi-rib belt, count the ribs. For a headlight, check the mounting and the bulb type.

Two other models from the 5R series have pages of their own, listing the parts for those tractors: John Deere 5090R and John Deere 5125R. Every John Deere model is reachable from John Deere parts.
