New Holland TM120 tractor parts & technical data

Trailer couplings, electrics and lighting are a sample of the more than 250 parts for the New Holland TM120, a tractor from the TM Series.

293 parts found for New Holland TM120
Show:
Exhaust manifold gasket for cylinder head
€35,09 €29,00 €32,28 €26,68
You save 8%
Door lock, right Case IH JX 70U, MXM 190, New Holland T5030, TS115
€220,86 €182,53 €203,19 €167,93
You save 8%
Replacement key
€10,41 €8,61
Sealing ring lift arm shaft 32,5 x 49 x 14 mm Fiat, Ford, New Holland
Dimensions: 32.5 x 49 x 14 mm. More
Dimensions: 32.5 x 49 x 14 mm.
€19,49 €16,11
Windshield frame shock absorber 150 N, 585 mm
Newtons: 150. A: 585 mm. B: 290 mm. C: 10 mm. D: 10 mm. To fit: windscreen. Form: 2. More
Newtons: 150. A: 585 mm. B: 290 mm. C: 10 mm. D: 10 mm. To fit: windsc...
€37,75 €31,20 €34,73 €28,70
You save 8%
AL-KO Chock UK 800 folding, 2.500 kg, tires radius 830 mm
AL-KO
Static tyre radius up to max.: 830 mm. More
Static tyre radius up to max.: 830 mm.
€114,26 €94,43 €109,22 €90,27
You save 4%
Chock folding Fiat, Ford, New Holland
€103,91 €85,88 €95,60 €79,01
You save 8%
Scharmüller Automatic hitch rail width 255 mm, coupling pin 38 mm
Scharmüller
Rail width: 255 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 82,4 kN. Colour: Black. Descript... More
Rail width: 255 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.236,75 €1.022,11 €1.083,22 €895,22
You save 12%
Scharmüller Ball 80® ball inserts gray cast iron, rail width 335 mm, 4000 kg
Scharmüller
Rail width: 335 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 4000 kg. D-value: 89,3 kN. Plate height: 160 mm. Colour: AGCO grey. Overh... More
Rail width: 335 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.116,48 €922,71
ROCKINGER Drawbar K80 rail width 336 mm, locking pin Ø 22 mm
ROCKINGER
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 4000 kg. D-value: 105 kN. Description: Manual ball hitch with height-adju... More
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.405,31 €1.161,41 €1.082,77 €894,85
You save 23%
Potentiometer hydraulic linkage with connection cable and plug
Version: Hydraulic lifting device control, Connection cable with plug. More
Version: Hydraulic lifting device control, Connection cable with plug.
€238,99 €197,51 €219,87 €181,71
You save 8%
Oil pressure switch steering, 2 blade connections
Version: 2 blade terminals, Also suitable for: four-wheel drive, power shuttle and differential lock. More
Version: 2 blade terminals, Also suitable for: four-wheel drive, power...
€81,29 €67,18 €74,79 €61,81
You save 8%
Sensor wheel speed Hall Matteffekt, connection cable with plug
Version: For speed, clutch block transmission (Hall effect), Connection cable with plug. More
Version: For speed, clutch block transmission (Hall effect), Connectio...
€116,92 €96,63 €107,57 €88,90
You save 8%
Starter switch without key, connection cable with plug
Version: Connection cable with plug, Key 50717018. More
Version: Connection cable with plug, Key 50717018.
€101,02 €83,49 €92,94 €76,81
You save 8%
Cobo Headlight left, right 12V60/55W / H4, built-in, screw fixing
Cobo
Bulb: 12V60/55W / H4. Installation location: Left, right. Nominal voltage: 12 V. Test mark: ECE. Light function: Dipped beam, full beam. Additional in... More
Bulb: 12V60/55W / H4. Installation location: Left, right. Nominal volt...
€138,13 €114,16 €127,08 €105,02
You save 8%
Cobo Indicator/position light 122 x 82 x 60 mm, P21W, R5W left
Cobo
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 122 mm. Form: Rectangular. Height: 82 mm. Dimensions W x H x D: 122 x 82 x 60 mm. De... More
Bulb: 12V21WK / P21W, 12V5WK / R5W. Colour: Yellow, white. Width: 122 ...
€50,80 €41,98 €33,09 €27,35
You save 35%
Track rod 2WD 900 mm, M18 x 1,5 mm, taper 20 - 22 mm
A: 900 mm. C: M18 x 1,5 mm. D: 32 mm. E: 20 mm. F: 22 mm. Taper: 20 - 22 mm. More
A: 900 mm. C: M18 x 1,5 mm. D: 32 mm. E: 20 mm. F: 22 mm. Taper: 20 - ...
€152,67 €126,17 €140,46 €116,08
You save 8%
Clutch cylinder mineral oil Ford, Fiat, New Holland
€196,97 €162,79 €181,21 €149,76
You save 8%
Sealing ring foot brake 259,6 x 266,4 x 3,4 mm
€50,32 €41,59 €46,29 €38,26
You save 8%
PTO shaft end piece 182,6 mm, 1 3/8 inch 21 splines, 1000 rpm.
Version: Length 182.6 mm, 1 3/8", 21 grooves, 1000 rpm. Menke no.: 125042. More
Version: Length 182.6 mm, 1 3/8", 21 grooves, 1000 rpm. Menke no.: 125...
€343,68 €284,03 €316,19 €261,31
You save 8%
PTO shaft end piece 182,5 mm, 1 3/8 inch 6 grooves, 540 rpm.
Version: Length 182.5 mm, 1 3/8", 6 grooves, 540 rpm. More
Version: Length 182.5 mm, 1 3/8", 6 grooves, 540 rpm.
€354,81 €293,23 €326,43 €269,77
You save 8%
ROCKINGER Drawbar KS80 rail 336 mm, pin Ø 22 mm, 4000 kg, black
ROCKINGER
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load capacity: 4000 kg. D-value: 100 kN. Colour: Black. Lock: KS80. Menke no.: 67134. More
Rail width: 336 mm. Detent pin Ø: 22 mm. Guide width: 30 mm. Load cap...
€1.732,20 €1.431,57
Fan clutch M30 x 2 L, hole spacing-Ø 96,77 mm
Thread: M30 x 2 L. PCD: 96,77 mm. More
Thread: M30 x 2 L. PCD: 96,77 mm.
€225,56 €186,41 €207,52 €171,50
You save 8%
Fan clutch M30 x 2 L, Ø 152,4 mm New Holland, Case IH
Weight: 6000 g. Thread: M30 x 2 L. PCD: 152,4 mm. Equipment: 662 Drive. Menke no.: 95215. More
Weight: 6000 g. Thread: M30 x 2 L. PCD: 152,4 mm. Equipment: 662 Drive...
€545,56 €450,88 €501,92 €414,81
You save 8%
Radiator hose, bottom inner-Ø 50 mm New Holland, Case IH
€74,79 €61,81 €68,81 €56,87
You save 8%
O-ring 34,52 x 3,53 mm Case IH, Ford, Fiat, New Holland
Dimensions: 34.52 x 3.53 mm. More
Dimensions: 34.52 x 3.53 mm.
€4,03 €3,33
Crankshaft seal Ø 60 x 82,5 x 25,6 mm Case IH, New Holland
Outer Ø: 82,5 mm. Width: 25,6 mm. Inner Ø: 60 mm. Material: PTFE (polytetrafluoroethylene). More
Outer Ø: 82,5 mm. Width: 25,6 mm. Inner Ø: 60 mm. Material: PTFE (po...
€135,47 €111,96 €124,63 €103,00
You save 8%
Oil pump engine 675TA Ford, Case IH, Fiat, New Holland
€183,55 €151,69 €168,87 €139,56
You save 8%
Electric feed pump without filter 230 l/hour, 0,55 bar
Version: Delivery volume 230 l/h, Pressure 0.55 bar. Menke no.: 209005. More
Version: Delivery volume 230 l/h, Pressure 0.55 bar. Menke no.: 209005...
€114,72 €94,81 €105,54 €87,23
You save 8%
Bosch/Rexroth Hydraulic pump clockwise 19 cm³/rpm., taper 1:8, Ø 17,46 mm
Bosch/Rexroth
Output volume: 19 cc/rev. Drive shaft: Taper 1:8, Ø 17.46. Direction of rotation: Right. Line connection suction side: Ø 40mm, 4-Loch, M8. Line conn... More
Output volume: 19 cc/rev. Drive shaft: Taper 1:8, Ø 17.46. Direction ...
€436,15 €360,45 €401,26 €331,62
You save 8%
Door lock, left Case IH JX 70U, MXM 190, New Holland T5030, TS120
€220,86 €182,53 €203,19 €167,93
You save 8%
Bearing for lower link shaft Ø 35 mm Fiat, Ford, New Holland
€120,38 €99,49 €110,75 €91,53
You save 8%
O-ring for piston 104 x 5 mm Fiat, Ford, New Holland
Dimensions: 104 x 5 mm. More
Dimensions: 104 x 5 mm.
€17,91 €14,80
Gas strut door 410 N, 215 mm
Newtons: 410. A: 215 mm. B: 100 mm. C: 13 mm. D: 13 mm. To fit: door. Form: 6. More
Newtons: 410. A: 215 mm. B: 100 mm. C: 13 mm. D: 13 mm. To fit: door. ...
€40,78 €33,70 €37,52 €31,01
You save 8%
Gas strut rear window 350 N, 460 mm
Newtons: 350. A: 460 mm. B: 245 mm. C: 8 mm. D: 8 mm. To fit: rear screen. Form: 2. More
Newtons: 350. A: 460 mm. B: 245 mm. C: 8 mm. D: 8 mm. To fit: rear scr...
€30,51 €25,22
Mirror Case IH Farmall 85C, Puma 230 CVX, New Holland T4.85-T4.95
Showing 193 - 240 of 293

New Holland TM120 parts

Sensors and switches first

When a TM120 throws up a warning that does not match how the tractor is behaving, a sensor or switch is usually the first suspect. This page has more than 250 New Holland TM120 parts from GRANIT, Scharmüller, ROCKINGER, Cobo and MAHLE, and the electrical side is well covered: transmission oil temperature sensors, oil pressure switches for the Full Power Shift with cable and plug, and relays. Before replacing anything, measure the resistance or switching point and inspect the connector. A pin with green corrosion produces exactly the same fault as a failed sensor.

Hitch and drawbar

At the rear you will find automatic drawbars, Piton Fix hitches and height adjustable adapter plates. Check the locking pin on a piton hitch regularly. If it is worn or no longer locks fully home, replace it straight away, because everything you tow depends on it. A height adjustable adapter plate lets you set the hitch to suit the trailer you pull every day, so the drawbar runs as level as possible.

Engine, fuel and cab

Around the engine there is the exhaust manifold gasket to the turbocharger, seal kits, O-rings, sealing rings and fan clutches. If the fan spins freely by hand with the engine hot, the fan clutch is no longer engaging and the engine will run hot under heavy work. If it stays locked all the time, you will hear the roar and see it in fuel use. With the manifold gasket, always use new nuts and replace any corroded studs, otherwise the joint at the turbo will start blowing again. There are tank caps with ventilation too. A blocked tank vent pulls a vacuum in the tank and the engine starts to stumble under load, which is easy to mistake for a fuel filter problem.

In the cab there are gas struts for the rear window, headlights and air suspended tractor seats, a worthwhile upgrade for anyone spending long days on the TM120.

Matching the right part

Start with the type plate and serial number of your TM120. With the old part in your hands, the reference number stamped or printed on it is the surest route. Other tractors in the TM series each have a page of their own:

The rest of the brand is listed under New Holland parts.
