Case IH CVX 150 tractor parts & technical data

With more than 400 matching items, this range covers the Case IH CVX 150 well. Product groups include lighting, electrics and trailer couplings, among others.

428 parts found for Case IH CVX 150
Show:
Scharmüller Piton Fix inserts 3000 kg, rail 330 mm, working length 67 mm, black
Scharmüller
Description: Can be disconnected with pin | Colour: Black | Rail width (mm): 330 | Overhang (mm): 67 | Plate height (mm): 160 | D-value (kN): 89,3 | G... More
Description: Can be disconnected with pin | Colour: Black | Rail width...
€754,30 €623,39 €693,96 €573,52
You save 8%
Connector head M16 x 1,5 red, supply line, vehicle
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, supply line | Menke no.: 55927 | Additional information: - For dual-line brake sys... More
Application: Vehicle | Connection thread: M16 x 1.5 | Version: Red, su...
€24,88 €20,56
SACHS Damper cab suspension S26X100, 235 mm, eye Ø 12 mm, rear
SACHS
Design: Oil pressure | To fit: CNH, SDF, STEYR, VALMET | Installation location: hinten beidseitig | Length (mm): 235 | Shock absorber mounting type: T... More
Design: Oil pressure | To fit: CNH, SDF, STEYR, VALMET | Installation ...
€173,66 €143,52 €159,77 €132,04
You save 8%
Expansion valve 3/8 - 5/8 inch o-ring
Equipment: O-ring | Connection thread E: # 6, 3/8"" O-ring | Connection thread A: # 10, 5/8"" O-ring More
Equipment: O-ring | Connection thread E: # 6, 3/8"" O-ring | Connectio...
€48,74 €40,28 €44,84 €37,06
You save 8%
SANDEN Aircon compressor SD7H15 12 V, pulley Ø 152 mm, 2 grooves
SANDEN
Fixing: EM | Pulley Ø (mm): 152 | Connection: A2 | Suitable oil: SP - 15 | No. of grooves: 2 | Reference no.: SD7H15-4478, 86993462, 1999755C2, 19997... More
Fixing: EM | Pulley Ø (mm): 152 | Connection: A2 | Suitable oil: SP -...
€621,28 €513,45 €571,58 €472,38
You save 8%
Maintenance switch air filter Case IH, New Holland, Steyr
Version: Function: maintenance switch Connection cable with plug connection More
Version: Function: maintenance switch Connection cable with plug conne...
€105,39 €87,10 €96,96 €80,13
You save 8%
Multifunction switch 2 lever, cable with 2 plugs
Version: 2 levers: forwards/reverse/neutral, For indicator light, lights, horn, windscreen wipers Connection cable with 2 plugs More
Version: 2 levers: forwards/reverse/neutral, For indicator light, ligh...
€1.177,41 €973,07 €1.083,22 €895,22
You save 8%
Push button switch front linkage on Case IH, New Holland, Steyr
Version: Control hydraulics Front linkage, on More
Version: Control hydraulics Front linkage, on
€101,50 €83,88 €93,38 €77,17
You save 8%
Push button switch PTO shaft on, lift operation Case IH, Steyr
Version: PTO shaft on, external switch (on mudguard) More
Version: PTO shaft on, external switch (on mudguard)
€48,11 €39,76 €44,26 €36,58
You save 8%
MAHLE Alternator 14 V, 95 A, flange 50,8 mm, form B
MAHLE
Installation angle (°): 0 | Mounting hole Ø / R (mm): 10,2 / 86,0 | Nominal values (V / A): 14 / 95 | Form: B | Nominal voltage (V): 14 | Flange siz... More
Installation angle (°): 0 | Mounting hole Ø / R (mm): 10,2 / 86,0 | ...
€453,06 €374,43 €271,36 €224,26
You save 40%
HELLA Alternator 14 V / 95 A, Case IH, Ford, Steyr
HELLA
Nominal values (V / A): 14 / 95 | Charging current (A): 95 | Nominal voltage (V): 14 More
Nominal values (V / A): 14 / 95 | Charging current (A): 95 | Nominal v...
€552,25 €456,41 €425,50 €351,66
You save 23%
Starter motor 12 V, 3,0 kW, 11 teeth, 229,5 mm, Ø 89 mm
€315,38 €260,64 €290,15 €239,79
You save 8%
Scharmüller Adapter plate rail width 330 mm, hole pattern 160 x 100 mm, M20
Scharmüller
Load capacity: 2000 kg. D-value: 89,3 kN. Rail width: 330 mm. Hole pattern: 160 x 100 mm. Guide width: 32 mm. Plate height: 120 mm. Thread: M20. Colou... More
Load capacity: 2000 kg. D-value: 89,3 kN. Rail width: 330 mm. Hole pat...
€600,57 €496,34 €552,52 €456,63
You save 8%
ROCKINGER Drawbar without sensor rail 330 mm, coupling pin 38 mm, black
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 120,0 kN. Colour: Black. Descrip... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.008,33 €833,33 €776,89 €642,06
You save 23%
HELLA Work lamp flood beam H3, 55/70 W, 12/24 V, Ø 168 x 116 mm
HELLA
Bulb: H3. Bulbs included: No. Light function: Close-range illumination. Installation location: Universal. Dimensions W x H x D: Ø 168 x 116 mm. Mount... More
Bulb: H3. Bulbs included: No. Light function: Close-range illumination...
€81,44 €67,31 €78,43 €64,82
You save 4%
ROCKINGER Adapter plate rail width 330 mm, 93,6 kN, 2500 kg, 160 x 100 mm
ROCKINGER
Colour: Black | Hole pattern (mm): 160 x 100 | Guide width (mm): 32 | Detent pin Ø (mm): 25 | D-value (kN): 93,6 | Load capacity (kg): 2500 | Rail wi... More
Colour: Black | Hole pattern (mm): 160 x 100 | Guide width (mm): 32 | ...
€651,63 €538,54 €627,60 €518,67
You save 4%
Bosch/Rexroth Hydraulic pump 63 cm³/rpm. clockwise Case IH CVX 140 - 1195
Bosch/Rexroth
Output volume (cc/rev): 63 | Direction of rotation: Right More
Output volume (cc/rev): 63 | Direction of rotation: Right
€5.769,12 €4.767,87 €5.307,59 €4.386,44
You save 8%
Scharmüller Adapter plate 330 mm rail, guide 32 mm, hole pattern 160 x 100 mm
Scharmüller
Description: Height adjustable with handle | V-value (kN): 45,6 | Hole pattern (mm): 160 x 100 | Guide width (mm): 32 | Dc-value (kN): 106 | D-value (... More
Description: Height adjustable with handle | V-value (kN): 45,6 | Hole...
€600,57 €496,34 €552,52 €456,63
You save 8%
Filter dryer Ø 62 mm, 203 mm, connection thread F/M 3/8 inch
Connection thread A: 3/8"" | Connection thread: F/M | Outer Ø (mm): 62 | Length (mm): 203 | Weight (g): 400 | Connection thread E: 3/8"" | Dimensions... More
Connection thread A: 3/8"" | Connection thread: F/M | Outer Ø (mm): 6...
€58,64 €48,46 €53,95 €44,59
You save 8%
Rocker switch control panel differential catch, airco
Version: Control panel Differential lock Speed range, heater, ventilation and air conditioning More
Version: Control panel Differential lock Speed range, heater, ventilat...
€161,49 €133,46 €148,57 €122,79
You save 8%
Rocker switch dashboard hazard warning light switch
Version: Dashboard Control panel Hazard warning light switch More
Version: Dashboard Control panel Hazard warning light switch
€92,02 €76,05 €84,66 €69,97
You save 8%
FEBI Fuel filter Ø 84 mm, inner-Ø 19 mm
€14,06 €11,62 €6,38 €5,27
You save 55%
MAHLE Starter motor 12 V, 3,0 kW, 11 teeth, mounting Ø 89 mm, mounting angle r 45
€505,95 €418,14 €303,03 €250,44
You save 40%
Axial joint 209 mm, M20 x 1,5, M24 x 1,5, 32 °, Ø 56 mm, Ø 40 mm
A: 209 mm. C: M20 x 1,5 mm. D: M24 x 1,5 mm. F: 32 °. Ø B: 56 mm. Ø E: 40 mm. More
A: 209 mm. C: M20 x 1,5 mm. D: M24 x 1,5 mm. F: 32 °. Ø B: 56 mm. Ø...
€96,00 €79,34 €88,32 €72,99
You save 8%
Scharmüller Support plates ball 80, 1142 x 240 mm, 4000 kg
Scharmüller
Lock: ball 80. Load capacity: 4000 kg. D-value: 89,3 kN. Length: 1142 mm. Width: 240 mm. Thickness: 60 mm. Number of heart pins: 2. Heart pin Ø: 32 m... More
Lock: ball 80. Load capacity: 4000 kg. D-value: 89,3 kN. Length: 1142 ...
€2.305,67 €1.905,51 €2.171,22 €1.794,40
You save 6%
Repair set polyurethane beglazingskit, Terostat primer - 310 ml
Contents: - Polyurethane direct glazing sealant, - Terostat primer, - Wool wiper, - Application nozzle, - Cleaner, - Cleaning sponge, - Instructions (... More
Contents: - Polyurethane direct glazing sealant, - Terostat primer, - ...
€58,03 €47,96 €53,39 €44,12
You save 8%
Scharmüller Drawbar ball 50, rail 200 mm, pin Ø 16 mm, 150 kg
Scharmüller
Rail width: 200 mm. Guide width: 25 mm. Detent pin Ø: 16 mm. Load capacity: 150 kg. D-value: 17,2 kN. Overhang: 80 mm. Plate height: 90 mm. Hole: M16... More
Rail width: 200 mm. Guide width: 25 mm. Detent pin Ø: 16 mm. Load cap...
€583,34 €482,10 €536,67 €443,53
You save 8%
Scharmüller Automatic hitch 330 mm, coupling pin 38 mm, 2000 kg, 97,1 kN
Scharmüller
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecting pin: 38 mm. Load capacity: 2000 kg. D-value: 97,1 kN. Colour: Black. Descript... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Connecti...
€1.324,09 €1.094,29
GRAMMER Tractor seat air suspended Maximo Professional fabric, seat width 530 mm
GRAMMER
Super comfort seat with low-frequency air suspension and 12V compressor. APS: automatic positioning system. Armrests height adjustable and folding. Ad... More
Super comfort seat with low-frequency air suspension and 12V compresso...
€1.991,23 €1.645,64
HELLA Work lamp spotlight Ultra beam H9 65 W, 12 V, 112 x 102 x 110 mm
HELLA
Dimensions W x H x D (mm): 112 x 102 x 110 | Additional information: - With swivel base with vibration damping - Vertical four-point mounting - Harden... More
Dimensions W x H x D (mm): 112 x 102 x 110 | Additional information: -...
€84,47 €69,81 €81,35 €67,23
You save 4%
HELLA Work lamp spotlight Ultra beam H3 24 V, 65 W, 115 x 230 x 94 mm
HELLA
Light function: Far-reaching illumination | Housing colour: Black | Form: Square | Test mark: ADR/GGVS tested | Bulbs included: Yes | Power consumptio... More
Light function: Far-reaching illumination | Housing colour: Black | Fo...
€96,59 €79,83 €93,02 €76,88
You save 4%
Push button switch lower, extern circuit Case IH, New Holland, Steyr
Version: Lower control hydraulics, External switch (on mudguard) More
Version: Lower control hydraulics, External switch (on mudguard)
€42,74 €35,32 €39,32 €32,50
You save 8%
Symbol linkage green Case IH CS 80 - 100, CVX 120 - 1195
Version: Green, lifting unit More
Version: Green, lifting unit
€5,65 €4,67
Rocker switch dashboard windshield wiser rear, battery-isolator
Version: Dashboard Control panel Wiper/washer system Windscreen Electric drives Rear windscreen wipers Reversible fans Battery cut-off with electrical... More
Version: Dashboard Control panel Wiper/washer system Windscreen Electr...
€61,57 €50,88 €56,64 €46,81
You save 8%
Contact switch driver’s seat with magnet, electric
Version: Driver’s seat Switch assembly with magnet More
Version: Driver’s seat Switch assembly with magnet
€102,10 €84,38 €97,84 €80,86
You save 4%
FEBI Feed pump 5 hole, 25/37 mm / 45 mm, flange 52 mm Valtra-Valmet
FEBI
To fit as: Valtra - Valmet 6200, 6300, 6400, 6600, 6800, 8000, 8050, 8150, 8450, 8550, 8750 More
To fit as: Valtra - Valmet 6200, 6300, 6400, 6600, 6800, 8000, 8050, 8...
€164,27 €135,76 €69,09 €57,10
You save 58%
FEBI Cab filter 380 x 130 x 48 mm
€30,96 €25,59 €16,64 €13,75
You save 46%
Pin lower arms Carraro front axle 147984
€369,32 €305,22 €339,77 €280,81
You save 8%
Carraro Bush 80 x 86 x 34,5 mm Case IH, New Holland
€75,30 €62,23 €69,28 €57,25
You save 8%
Universal joint axle drive 27 x 71 mm, maintenance-free
€80,05 €66,16 €73,65 €60,86
You save 8%
ROCKINGER Piton Fix rail width 330 mm, locking pin Ø 25 mm, 4000 kg, 89,3 kN
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 89,3 kN. Description: Manual Piton-Fix with elevator be... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.363,65 €1.126,98 €1.100,67 €909,64
You save 19%
PROBOSS Seat PROBOSS AS3510 air suspended, fabric, 510 mm, 12 V
PROBOSS
Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Optional. Track gauge: 260 mm. Seat width: 510 mm. Joystick console: Optiona... More
Suspension: Air suspension. Upholstery type: Fabric. Seat contact swit...
€1.383,42 €1.143,32
GRAMMER Tractor seat Maximo Comfort Plus Case CVX, Steyr, New Holland
GRAMMER
To fit: Case CVX, Steyr, New Holland. Suspension: Air suspension. Upholstery type: Fabric. Seat contact switch: Yes. Track gauge: 260 mm. Seat width: ... More
To fit: Case CVX, Steyr, New Holland. Suspension: Air suspension. Upho...
€2.247,41 €1.857,36
Scharmüller Drawbar K80 manual, rail 390 mm, pin Ø 25 mm, 4000 kg, black
Scharmüller
Rail width: 390 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 120,2 kN. Plate height: 175 mm. Colour: Black. Overhang... More
Rail width: 390 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.683,34 €1.391,19 €1.598,67 €1.321,21
You save 5%
ROCKINGER Drawbar K80 rail width 330 mm, locking pin Ø 25 mm
ROCKINGER
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load capacity: 4000 kg. D-value: 102 kN. Description: Manual ball hitch with height-adju... More
Rail width: 330 mm. Detent pin Ø: 25 mm. Guide width: 32 mm. Load cap...
€1.285,58 €1.062,46 €990,51 €818,61
You save 23%
ROCKINGER Drawbar automatic 48,7 mm, 330 / 25 / 32 mm, 2000 kg, 93,6 kN
€2.805,57 €2.318,65 €2.211,65 €1.827,81
You save 21%
Showing 49 - 96 of 428

Case IH CVX 150 parts from front linkage to drawbar

Walk round a Case IH CVX 150 from the nose to the rear and there is something at every corner that will need replacing sooner or later. This page holds more than 400 parts for this tractor, from GRANIT and from makers such as HELLA, Scharmüller, ROCKINGER and Carraro.

Front end and engine bay

The front linkage is operated with push button switches, such as the green button for lowering. The bonnet is held up by gas struts, and when it drops on its own in the wind or on a slope, they have had their day. Under the bonnet you will find alternators, V-belts, water pump gaskets, O-rings for the feed pump and sealing rings.

Before you condemn an alternator, check the tension and condition of the V-belt and make sure the battery terminals and earth strap are clean and tight. A slipping belt or a poor earth produces exactly the same symptoms as a failed alternator. If it does have to come off, fit a new belt at the same time. A stretched old belt rarely runs true on a fresh pulley.

In and around the cab

Inside there are rocker switches and push buttons for the controls, and tractor seats for long working days. Work lamps come in many shapes, including LED flood beams that light up a wide area around the tractor. On the outside of the cab, combined indicator and position lights complete the picture.

Rear linkage and hitching

At the back it is all about hitching and lifting. There are automatic drawbars, adapter plates to mount a hitch at the right height and bushes for the lower link shaft. A seal for a lubrication line belongs here too.

Which part fits your CVX 150

The CVX 150 belongs to the Case IH CVX range. With so many models and versions in that range, the type plate is your starting point, since it gives the exact model and serial number. The old part usually carries a reference number of its own. On an alternator it is on the unit's own plate, on a gasket it is sometimes pressed into the edge. Compare it with the product description before ordering. For a drawbar or adapter plate, also measure the rail width and hole pattern of what is fitted now.

Other CVX models with their own page:

The CVX 1155 and CVX 1170 are part of the same range. Every other model from the brand is under Case IH parts.

Brands
  • View more
Price
Min Max
Close
Choose your language
Choose your currency
€

Recently added

Total incl. tax
€0,00
0
Compare
Start comparison
This product has been added to your cart
