John Deere 2040S tractor parts & technical data

The John Deere 2040S from the 40 series gets its own overview here, with more than 350 parts such as lighting, electrics and engine components.

371 parts found for John Deere 2040S
Show:
V-belt John Deere 840-2140, 1350-1950, 5220-5410
€30,99 €25,61
Hose elbow oil cooler inner-Ø 16 mm John Deere 1040-4040
€10,68 €8,82
Water pump with pulley Ø 125 mm John Deere
€195,81 €161,83 €180,15 €148,88
You save 8%
Radiator hose by-pass inner-Ø 17 mm John Deere
€5,18 €4,28
Radiator hose, top inner-Ø 37 mm John Deere 1640-2140
€12,60 €10,41
Thermostat Ø 54 mm, 82 °C John Deere, JCB
Ø: 54 mm. Temperature: 82 °C. More
Ø: 54 mm. Temperature: 82 °C.
€29,95 €24,75
Oil cooler 402 x 130 x 48 mm John Deere 1640-3640
Width: 130 mm. Length: 402 mm. Depth: 48 mm. Version: Produced by BEHR. More
Width: 130 mm. Length: 402 mm. Depth: 48 mm. Version: Produced by BEHR...
€394,62 €326,13 €363,05 €300,04
You save 8%
Optibelt V-belt John Deere 840-2140, 1350-1950, 5120-5400
€47,85 €39,55 €44,02 €36,38
You save 8%
Cylinder head bolt 1/2" x 108 mm John Deere
Dimensions: 1/2" x 108 mm. More
Dimensions: 1/2" x 108 mm.
€8,58 €7,09
Stop cable without detent 2270 mm, 2100 mm John Deere 840-3650
€25,84 €21,35
Bush for crankshaft John Deere
€39,51 €32,65 €36,35 €30,04
You save 8%
O-ring oil pump 24,994 x 3,531 mm John Deere
Dimensions: 24.994 x 3.531 mm. More
Dimensions: 24.994 x 3.531 mm.
€4,45 €3,68
Cylinder head gasket John Deere, Renault
€35,57 €29,40 €32,72 €27,05
You save 8%
Collet set John Deere
Piston set, complete Ø 106,5 mm, combustion chamber Ø 58,4 mm
Dimensions: 3 rings, Ø 106.5 mm, Gudgeon pin Ø 41.28 x 84 mm, Combustion chamber Ø 58.4 mm, Combustion chamber depth 19.65 mm. Menke no.: 59649. De... More
Dimensions: 3 rings, Ø 106.5 mm, Gudgeon pin Ø 41.28 x 84 mm, Combus...
€191,74 €158,46 €176,40 €145,79
You save 8%
Control valve steering valve John Deere 920-3650
€34,36 €28,40 €31,61 €26,13
You save 8%
Valve parts set hydraulic pump John Deere 840-3650
€17,75 €14,67
Bush set lift arm shaft Ø 1 1/8 inch John Deere
Dimensions: Ø = 1 1/8" mm. More
Dimensions: Ø = 1 1/8" mm.
€36,36 €30,05 €33,45 €27,65
You save 8%
Threaded spindle M27 x 3 mm right-hand thread, cat. 2, B 175 mm, G 337 mm
I: M27 x 3 mm. Version: Right-hand thread. A: 25,4 mm. B: 175 mm. C: 51 mm. G: 337 mm. D: 66 mm. F: 162 mm. Category: 2 / 25.4. More
I: M27 x 3 mm. Version: Right-hand thread. A: 25,4 mm. B: 175 mm. C: 5...
€163,38 €135,02 €150,31 €124,22
You save 8%
Transmission-oil pump sintered binnenrotor John Deere 840-3350
€1.099,12 €908,36 €1.011,19 €835,69
You save 8%
Ignition switch with 2 keys 12 V, built-in-Ø 26 mm
Mounting Ø: 26 mm. Fixing: Fastening nut brass. Nominal voltage: 12 V. Switching stages: Parking light <lt>br<gt> Driving <lt>br<gt> Parking light <l... More
Mounting Ø: 26 mm. Fixing: Fastening nut brass. Nominal voltage: 12 V...
€39,43 €32,59 €36,28 €29,98
You save 8%
HELLA Branch connectors blue 0,8 - 2,0 mm² - 25 pieces
HELLA
Colour: Blue. Connection: Branch connectors. Cross section: 0,8 - 2,0 mm². More
Colour: Blue. Connection: Branch connectors. Cross section: 0,8 - 2,0 ...
€10,98 €9,07
Bolt set
€9,39 €7,76
Dust protection
€12,63 €10,43
Housing right metal, also als plastic housing available
€58,90 €48,68 €54,19 €44,78
You save 8%
Housing left metal, also als plastic housing available
€58,90 €48,68 €54,19 €44,78
You save 8%
HELLA Micro relays changeover contact 12 V, 30 - 40 A, 5-pin, with holder
HELLA
Version: 12 V / 30 - 40 A, With bracket, 5-pin, blade terminal 6.3 mm. Function: Make contact relay (mini relay). More
Version: 12 V / 30 - 40 A, With bracket, 5-pin, blade terminal 6.3 mm....
€20,18 €16,67
Multifunction relay relays 12 V, 30 - 40 A, 5-pin, 6,3 mm
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 mm, With parallel resistor for suppressing inductive interference voltage peaks,... More
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 ...
€33,86 €27,98 €31,15 €25,74
You save 8%
HELLA Multifunction relay changeover contact 12 V, 30 - 40 A, 5-pin
HELLA
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 mm, With parallel resistor for suppressing inductive interference voltage peaks.... More
Version: 12 V / 30 - 40 A, Without bracket, 5-pin, blade terminal 6.3 ...
€16,58 €13,70
Water pump without belt pulley and gasket John Deere Engine 940-5500
To fit as: John Deere 840, 940, 1040, 1140, 1640, 1840, 2040, 2040S, 2140, 1350, 1550, 1750, 1850, 2250, 2450, 2650, 2850, 5300, 5400, 5500 More
To fit as: John Deere 840, 940, 1040, 1140, 1640, 1840, 2040, 2040S, 2...
€143,97 €118,98 €132,45 €109,46
You save 8%
Stop cable without stop 2270 / 2100 mm John Deere 940-4955
To fit as: John Deere 840, 940, 1030, 1130, 1530, 1630, 1830, 2130, 3030, 3130, 1040, 1140, 1640, 1840, 2040, 2140, 3040, 3340, 3640, 4240, 4440, 1350... More
To fit as: John Deere 840, 940, 1030, 1130, 1530, 1630, 1830, 2130, 30...
€25,84 €21,35
Seal feed pump John Deere Engine 920-6359
To fit as: John Deere 820, 920, 1020, 1120, 2020, 2120, 3020, 3120, 830, 930, 1030, 1130, 1630, 1830, 2030, 2130, 3030, 3130, 840, 940, 1040, 1140, 18... More
To fit as: John Deere 820, 920, 1020, 1120, 2020, 2120, 3020, 3120, 83...
€2,11 €1,75
ZF Pivot pin Ø 50 mm, thickness 51 mm ZF front axle 4468056021
€305,49 €252,47 €281,05 €232,27
You save 8%
Non-return valve brake cylinder John Deere 830-3650, combine 952-985
Showing 241 - 288 of 371

John Deere 2040S parts for clutch, engine and steering

Keeping a John Deere 2040S at work means dealing with the jobs an older tractor brings: a clutch, an alternator, a weeping gasket. For this member of the John Deere 40 series, this page lists more than 350 parts from GRANIT, HELLA, LUK, MAHLE and VICTOR REINZ.

Clutch work

There are clutch plates, single clutch assemblies and internal plates, partly from LUK. Once the tractor is split, replace the clutch plate and pressure plate together. Splitting engine from gearbox is the costly part of the job, not the parts. Check the flywheel for heat spots and scoring and have it skimmed if needed, then use an alignment tool so the input shaft slides through the new plate without forcing.

Engine seals and electrics

For the engine there are gaskets, seals, O-rings and sealing rings, such as a seal for the feed pump, an O-ring for the oil pump and sealing rings for the injection nozzles. There is also a gasket for the lift housing. Always use new nozzle sealing rings, because a used one is already crushed and will not seal reliably a second time.

Alternators and starter motors come in several versions, so compare flange and pinion with the unit you removed. Relays and radiator hoses are available too.

Steering, driveshafts and linkage

Track rods cover the steering and universal joints the driveshafts. A universal joint that feels notchy in one position needs replacing, even if it does not rattle yet. Bushes for the lower link struts and tubes complete the picture.

After replacing a track rod, the toe-in will not be right on its own. Count the turns as you unscrew the old rod, screw the new one in the same amount, and have the toe-in checked afterwards. A radiator hose that feels soft or cracked with the engine cold should go, together with its clamps.

Bushes for the lower link struts wear oval over time. If the linkage knocks when you lift an implement, check the bushes before looking at anything more expensive.

Matching parts to the 2040S

The serial number is on the type plate. Many parts on this page also carry a John Deere reference number, which you will often find on the old part as well.

Other tractors from the 40 series with their own page are the John Deere 1640, John Deere 3640, John Deere 4040, John Deere 4240 and John Deere 4440. For the brand as a whole, see John Deere parts.
